Introduction: HackRF Shielding Kit Installation
This is a tutorial on how to install the NooElec HackRF Shielding Kit.
Step 1: Step 1: Prepare Your Board, and Tools.
Tool selection notes: I used no-clean liquid flux for this build instead of the usual rosin flux, as it's way way easier to clean off of a board with small components, or extra small spaces it can collect in.
Also I used a wide, flat-head type soldering iron tip for maximum heat transference. With my rig, 750 degrees F melted the solder fast, and transferred enough heat to the shield body to create a good bond. No more than 4 to 5 seconds of heat per weld. There are some heat sensitive components close to the edge of the shield in a couple of places, be extra careful about heat in those areas, as you may accidentally unseat one of the small resistors or caps in the RF section.
I also prepped the board by wiping off any dust, and old flux with alcohol, or flux remover on a small cotton cloth, and then used my fiberglass abrasion pen to rough up the areas I was going to solder. After that I washed it again in flux remover to remove any dust from the abrasion process. This provides microscopic etches in the copper that makes for a tighter molecular bond with the solder.
Step 2: Step 2: Find a Good Placement for the Shield.
Before you solder anything, place the shield on the dashed copper lines, and decide how you are going to secure it to the board for soldering. I used a simple plastic spring-clamp.
Step 3: Step 3: Solder That Thing!!
Use a light clamp to secure the shielding frame to the PCB. If its too strong it will bend the frame. I used a small plastic clamp with rubber tips you can get at any hardware store.
Add flux to the tab you're going to solder. Using the wide flat screwdriver shaped tip for my iron, add a bit of solder to the tip, and press between the PCB and the shielding frame. You wanna heat the frame and the copper pad at the same time, so that the solder flows to both. I did it one tab at a time, and let it cool between tabs. I didn't wanna risk heat damage to the sensitive RF section. Also, for some of them due to clearance with other board components, I had to solder the tabs from the inside of the frame. See the pics.
Step 4: Step 4: PROFIT!
Solder the 2x10 pin female header to the P30 header mount, it should be labelled.
Clean the board with flux cleaner and a brush.
Plug it in, and test with SDR# if on Windows, GQRX if you're using linux!
Enjoy your decreased noise floor! :D
