Introduction: Home Automation With Arduino, Buttons ,LCD ,EEPROM AND Smart Phone

By
About: I love electronics .Arduino automation

Now we can control full home with smart Phone

Step 1: Hardware Required

for home automation you can add different things i choose switching or relay

In this project you will control switcher by mobile .if mobile is not present you can also operate with keypad

I also add lcd in the project to see the the present status of switches.

hardware required in this project

Android Mobile

jumper cables

16 * 2 LCD display

HC-06 Bluetooth Module

Arduino uno or MEGA

Bread Board

10k ohm varible for LCD

Relay Module

For making own relay Module

Relay

Transister

Resisters

PCB board

Step 2: Software Required

https://play.google.com/store/apps/details?id=com....

Download this app for home automation it can control 8 relay at a time

Its also have a timer.

To program on arduino use Arduino IDE which is available on

https://www.arduino.cc/en/Main/Software

Step 3: Programming for Bluetooth Module and Relay Module

this is the wiring sequence of relay module and relay module

This program is only for bluetooth and relay module

<p>#include <SoftwareSerial,h></p><p></p><p>SoftwareSerial mySerial(0, 1); // 1-RX, 0-TX - </p><p>int ch1 =  A0;
int ch2 =  A1;
int ch3 =  A2;
int ch4 =  A3;</p><p> void setup()
 {
 mySerial.begin(9600);</p><p>
 pinMode(ch1, OUTPUT);
 pinMode(ch2, OUTPUT);
 pinMode(ch3, OUTPUT);
 pinMode(ch4, OUTPUT);</p><p> }</p><p> void loop()
{</p><p> char caracter = mySerial.read();</p><p> //--------------------------------ch1---------------------
 if(caracter == 'A')
{
 digitalWrite(ch1,HIGH);
 </p><p>}</p><p>if(caracter == 'a')
{
 digitalWrite(ch1,LOW);

}
//---------------------------------ch1----------------------
//---------------------------------ch2---------------------
 if(caracter == 'B')
{
 digitalWrite(ch2,HIGH);</p><p>}</p><p>if(caracter == 'b')
{
 digitalWrite(ch2,LOW);

}
//---------------------------------ch2----------------------
//---------------------------------ch3---------------------
 if(caracter == 'C')
{
 digitalWrite(ch3,HIGH);</p><p>}</p><p>if(caracter == 'c')
{
 digitalWrite(ch3,LOW);

}
//---------------------------------ch3----------------------
//---------------------------------ch4---------------------
 if(caracter == 'D')
{
 digitalWrite(ch4,HIGH);

}</p><p>if(caracter == 'd')
{
 digitalWrite(ch4,LOW);

}
//---------------------------------ch4----------------------</p><p> delay(10);
}</p>

Attachments

Step 4: Now Adding LCD With Arduino

* LCD RS pin to digital pin 12
* LCD Enable pin to digital pin 11

* LCD D4 pin to digital pin 5

* LCD D5 pin to digital pin 4

* LCD D6 pin to digital pin 3

* LCD D7 pin to digital pin 2

* LCD R/W pin to ground

* 10K resistor:

* ends to +5V and ground

* wiper to LCD VO pin (pin 3)

<p>#include <SoftwareSerial.h><br> SoftwareSerial mySerial(0, 1);
#include <LiquidCrystal.h>

int ch1 =  A0;
int ch2 =  A1;
int ch3 =  A2;
int ch4 =  A3;
LiquidCrystal lcd(12, 11, 5, 4, 3, 2);;//(rs, enable, d4, d5, d6, d7) </p><p> void setup()
 {
 mySerial.begin(9600);</p><p>
 pinMode(ch1, OUTPUT);
 pinMode(ch2, OUTPUT);
 pinMode(ch3, OUTPUT);
 pinMode(ch4, OUTPUT);</p><p>lcd.begin(16, 2);</p><p> }</p><p> void loop()
{</p><p> char caracter = mySerial.read();</p><p> //--------------------------------ch1---------------------
 if(caracter == 'A')
{
 digitalWrite(ch1,HIGH);
 lcd.setCursor(0, 0);
 lcd.print("r1 ON");</p><p>}</p><p>if(caracter == 'a')
{
 digitalWrite(ch1,LOW);
 lcd.setCursor(0, 0);
 lcd.print("r1 OFF");
}
//---------------------------------ch1----------------------
//---------------------------------ch2---------------------
 if(caracter == 'B')
{
 digitalWrite(ch2,HIGH);
 lcd.setCursor(8, 0);
 lcd.print("r2 ON");
}</p><p>if(caracter == 'b')
{
 digitalWrite(ch2,LOW);
  lcd.setCursor(8, 0);
 lcd.print("r2 OFF");
}
//---------------------------------ch2----------------------
//---------------------------------ch3---------------------
 if(caracter == 'C')
{
 digitalWrite(ch3,HIGH);
  lcd.setCursor(0, 1);
 lcd.print("r3 ON");
}</p><p>if(caracter == 'c')
{
 digitalWrite(ch3,LOW);
  lcd.setCursor(0, 1);
 lcd.print("r3 OFF");
}
//---------------------------------ch3----------------------
//---------------------------------ch4---------------------
 if(caracter == 'D')
{
 digitalWrite(ch4,HIGH);
  lcd.setCursor(8, 1);
 lcd.print("r4 ON");
}</p><p>if(caracter == 'd')
{
 digitalWrite(ch4,LOW);
  lcd.setCursor(8, 1);
 lcd.print("r4 OFF");
}
//---------------------------------ch4----------------------</p><p> delay(10);
}</p>

Attachments

Step 5: Adding Push Button in the Project

Now we are adding Buttons

i use four button you can use it according to requirement

<p>#include <SoftwareSerial.h> //</p><p> SoftwareSerial mySerial(0, 1); // 1-RX, 0-TX -
#include <LiquidCrystal.h></p><p>int ch1 =  A0;
int ch2 =  A1;
int ch3 =  A2;
int ch4 =  A3;
LiquidCrystal lcd(12, 11, 5, 4, 3, 2);;//(rs, enable, d4, d5, d6, d7)
int switchPin[] = {6,7,8,9};
 void setup()
 {
 mySerial.begin(9600);</p><p>
 pinMode(ch1, OUTPUT);
 pinMode(ch2, OUTPUT);
 pinMode(ch3, OUTPUT);
 pinMode(ch4, OUTPUT);</p><p>lcd.begin(16, 2);</p><p>pinMode(switchPin[0], INPUT);
  digitalWrite(switchPin[0], HIGH);
  pinMode(switchPin[1], INPUT);
  digitalWrite(switchPin[1], HIGH);
  pinMode(switchPin[2], INPUT);
  digitalWrite(switchPin[2], HIGH);
  pinMode(switchPin[3], INPUT);
  digitalWrite(switchPin[3], HIGH);
   pinMode(switchPin[4], INPUT);
  digitalWrite(switchPin[4], HIGH);
 }</p><p> void loop()
{</p><p> char caracter = mySerial.read();</p><p> //--------------------------------ch1---------------------
 if(caracter == 'A')
{
 digitalWrite(ch1,HIGH);
 lcd.setCursor(0, 0);
 lcd.print("r1  ON");</p><p>}</p><p>if(caracter == 'a')
{
 digitalWrite(ch1,LOW);
 lcd.setCursor(0, 0);
 lcd.print("r1 OFF");
}
//---------------------------------ch1----------------------
//---------------------------------ch2---------------------
 if(caracter == 'B')
{
 digitalWrite(ch2,HIGH);
 lcd.setCursor(8, 0);
 lcd.print("r2  ON");
}</p><p>if(caracter == 'b')
{
 digitalWrite(ch2,LOW);
  lcd.setCursor(8, 0);
 lcd.print("r2 OFF");
}
//---------------------------------ch2----------------------
//---------------------------------ch3---------------------
 if(caracter == 'C')
{
 digitalWrite(ch3,HIGH);
  lcd.setCursor(0, 1);
 lcd.print("r3  ON");
}</p><p>if(caracter == 'c')
{
 digitalWrite(ch3,LOW);
  lcd.setCursor(0, 1);
 lcd.print("r3 OFF");
}
//---------------------------------ch3----------------------
//---------------------------------ch4---------------------
 if(caracter == 'D')
{
 digitalWrite(ch4,HIGH);
  lcd.setCursor(8, 1);
 lcd.print("r4  ON");
}</p><p>if(caracter == 'd')
{
 digitalWrite(ch4,LOW);
  lcd.setCursor(8, 1);
 lcd.print("r4 OFF");
}
//---------------------------------ch4----------------------
if (digitalRead(switchPin[0]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch1, HIGH) ;
      lcd.setCursor(0, 0);
 lcd.print("r1  ON");
  }
  if (digitalRead(switchPin[0]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch1, LOW) ;
       lcd.setCursor(0, 0);
 lcd.print("r1 OFF");
  }
   if (digitalRead(switchPin[1]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch2, HIGH) ;
       lcd.setCursor(8, 0);
 lcd.print("r2  ON");
  }
  if (digitalRead(switchPin[1]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch2, LOW) ;
        lcd.setCursor(8, 0);
 lcd.print("r2 OFF");
  }
  if (digitalRead(switchPin[2]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch3, HIGH) ;
 lcd.setCursor(0, 1);
 lcd.print("r3  ON");
  }
  if (digitalRead(switchPin[2]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch3, LOW) ;
         lcd.setCursor(0, 1);
 lcd.print("r3 OFF");
  }
   if (digitalRead(switchPin[3]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch4, HIGH) ;
        lcd.setCursor(8, 1);
 lcd.print("r4  ON");// toggle running variable

  }
  if (digitalRead(switchPin[3]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch4, LOW) ;
          lcd.setCursor(8, 1);
 lcd.print("r4 OFF");
  }</p><p> delay(0);
}</p>

Attachments

Step 6: Now We Are Using EEPROM to Save Last Status of Switches

Using EEPROM

I am adding internal EEPROM to save the last status

If the device go out of power and again connected

it load the last status of switches

those switches which are on before power off now they are still on

<p>#include <SoftwareSerial.h> //</p><p> SoftwareSerial mySerial(1, 0); // 1-RX, 0-TX -
#include <LiquidCrystal.h></p><p>#include <EEPROM.h></p><p>int ch1 =  A0;
int ch2 =  A1;
int ch3 =  A2;
int ch4 =  A3;
LiquidCrystal lcd(12, 11, 5, 4, 3, 2);;//(rs, enable, d4, d5, d6, d7)
int switchPin[] = {6,7,8,9};
 void setup()
 {
 mySerial.begin(9600);</p><p>
 pinMode(ch1, OUTPUT);
 pinMode(ch2, OUTPUT);
 pinMode(ch3, OUTPUT);
 pinMode(ch4, OUTPUT);</p><p>lcd.begin(16, 2);</p><p>pinMode(switchPin[0], INPUT);
  digitalWrite(switchPin[0], HIGH);
  pinMode(switchPin[1], INPUT);
  digitalWrite(switchPin[1], HIGH);
  pinMode(switchPin[2], INPUT);
  digitalWrite(switchPin[2], HIGH);
  pinMode(switchPin[3], INPUT);
  digitalWrite(switchPin[3], HIGH);
   pinMode(switchPin[4], INPUT);
  digitalWrite(switchPin[4], HIGH);</p><p>  if (EEPROM.read(0) == 1)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch1, HIGH) ;
       lcd.setCursor(0, 0);
 lcd.print("r1  ON");
        // toggle running variable
          // indicate via LED
  }
  if (EEPROM.read(0) == 0)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch1, LOW) ;
       lcd.setCursor(0, 0);
 lcd.print("r1 OFF");
        // toggle running variable
          // indicate via LED
  }
  if (EEPROM.read(1) == 1)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch2, HIGH) ;
       lcd.setCursor(8, 0);
 lcd.print("r2  ON");
        // toggle running variable
          // indicate via LED
  }
  if (EEPROM.read(1) == 0)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch2, LOW) ;
        lcd.setCursor(8, 0);
 lcd.print("r2 OFF");
        // toggle running variable
          // indicate via LED
  }
  if (EEPROM.read(2) == 1)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch3, HIGH) ;
       lcd.setCursor(0, 1);
 lcd.print("r3  ON");
        // toggle running variable
          // indicate via LED
  }
  if (EEPROM.read(2) == 0)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch3, LOW) ;
       lcd.setCursor(0, 1);
 lcd.print("r3 OFF");
        // toggle running variable
          // indicate via LED
  }
  if (EEPROM.read(3) == 1)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch4, HIGH) ;
       lcd.setCursor(8, 1);
 lcd.print("r4  ON");
        // toggle running variable
          // indicate via LED
  }
  if (EEPROM.read(3) == 0)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch4, LOW) ;
       lcd.setCursor(8, 1);
 lcd.print("r3 OFF");
        // toggle running variable
          // indicate via LED
  }
 }
 </p><p> void loop()
{</p><p> char caracter = mySerial.read();</p><p> //--------------------------------ch1---------------------
 if(caracter == 'A')
{
 digitalWrite(ch1,HIGH);
 lcd.setCursor(0, 0);
 lcd.print("r1  ON");
EEPROM.write(0, 1);
}</p><p>if(caracter == 'a')
{
 digitalWrite(ch1,LOW);
 lcd.setCursor(0, 0);
 lcd.print("r1 OFF");
 EEPROM.write(0, 0);
}
//---------------------------------ch1----------------------
//---------------------------------ch2---------------------
 if(caracter == 'B')
{
 digitalWrite(ch2,HIGH);
 lcd.setCursor(8, 0);
 lcd.print("r2  ON");
 EEPROM.write(1, 1);
}</p><p>if(caracter == 'b')
{
 digitalWrite(ch2,LOW);
  lcd.setCursor(8, 0);
 lcd.print("r2 OFF");
 EEPROM.write(1, 0);
}
//---------------------------------ch2----------------------
//---------------------------------ch3---------------------
 if(caracter == 'C')
{
 digitalWrite(ch3,HIGH);
  lcd.setCursor(0, 1);
 lcd.print("r3  ON");
 EEPROM.write(2, 1);
}</p><p>if(caracter == 'c')
{
 digitalWrite(ch3,LOW);
  lcd.setCursor(0, 1);
 lcd.print("r3 OFF");
 EEPROM.write(2, 0);
}
//---------------------------------ch3----------------------
//---------------------------------ch4---------------------
 if(caracter == 'D')
{
 digitalWrite(ch4,HIGH);
  lcd.setCursor(8, 1);
 lcd.print("r4  ON");
 EEPROM.write(3, 1);
}</p><p>if(caracter == 'd')
{
 digitalWrite(ch4,LOW);
  lcd.setCursor(8, 1);
 lcd.print("r4 OFF");
 EEPROM.write(3, 0);
}
//---------------------------------ch4----------------------
if (digitalRead(switchPin[0]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch1, HIGH) ;
      lcd.setCursor(0, 0);
 lcd.print("r1  ON");
 EEPROM.write(0, 1);
  }
  if (digitalRead(switchPin[0]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch1, LOW) ;
       lcd.setCursor(0, 0);
 lcd.print("r1 OFF");
 EEPROM.write(0, 0);
  }
   if (digitalRead(switchPin[1]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch2, HIGH) ;
       lcd.setCursor(8, 0);
 lcd.print("r2  ON");
  EEPROM.write(1, 1);
  }
  if (digitalRead(switchPin[1]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch2, LOW) ;
        lcd.setCursor(8, 0);
 lcd.print("r2 OFF");
 EEPROM.write(1, 0);
  }
  if (digitalRead(switchPin[2]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch3, HIGH) ;
 lcd.setCursor(0, 1);
 lcd.print("r3  ON");
 EEPROM.write(2, 1);
  }
  if (digitalRead(switchPin[2]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch3, LOW) ;
         lcd.setCursor(0, 1);
 lcd.print("r3 OFF");
  EEPROM.write(2, 0);
  }
   if (digitalRead(switchPin[3]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
       digitalWrite(ch4, HIGH) ;
        lcd.setCursor(8, 1);
 lcd.print("r4  ON");// toggle running variable
        EEPROM.write(3, 1);
  }
  if (digitalRead(switchPin[3]) == LOW)
  {  // switch is pressed - pullup keeps pin high normally
        digitalWrite(ch4, LOW) ;
          lcd.setCursor(8, 1);
 lcd.print("r4 OFF");
  EEPROM.write(3, 0);
  }</p><p> delay(0);
}</p>

Attachments

Step 7: Adding Sensers in the Project

If you want to add senser i think Arduino MEGA is Better because it has more pins than uno

if you want to use Arduino UNO Than use Shields

Automation Contest 2016

Participated in the
Automation Contest 2016

1 Person Made This Project!

Recommendations

Arduino Powered Painting Robot
Arduino Powered Painting Robot by Technovation in Arduino
76 5.9K
Zoom Control Box
Zoom Control Box by p_leriche in Gadgets
2 216 17K
Battery Powered Lamp That Turns on Through the Use of Magnets!
Battery Powered Lamp That Turns on Through the Use of Magnets! by Studio Petek in LEDs
84 9.5K
ROTARY CNC BOTTLE PLOTTER
ROTARY CNC BOTTLE PLOTTER by tuenhidiy in Arduino
130 17K

  • Battery Powered Contest

    Battery Powered Contest

  • Plywood Challenge

    Plywood Challenge

  • Plastic Contest

    Plastic Contest

28 Discussions

0
Mutali
Mutali

9 months ago

Please sent me code for epom that idont want led display

0
parisa2000
parisa2000

1 year ago

hi, can you launched sensor fluxgate flc100 magnetometr with ardunio and conected to pc wiht bleuthos? thack you very much

0
seekeru
seekeru

Question 2 years ago

hi there, i have done similar project but my lcd going crazy showing weird character when i switch on ac supply..what should i do to overcome this problem..very thank you for all helps..

0
urena43
urena43

Question 2 years ago

Hello, first of all, thank you for this interesting project. What could be the reason why the Bluetooth app doesn't make anything? I followed the instructions step by step, I don't know, is necessary to do something in the android app? Thanks a lot...

0
IvanR1
IvanR1

4 years ago

Interesting, thanks!

0
awaiskhawar
awaiskhawar

Reply 4 years ago

Thanks for feedback

0
Gul asfand
Gul asfand

Reply 3 years ago

Lcd can not show any character ,if upload the code . what i do ?

0
awaiskhawar
awaiskhawar

Reply 3 years ago

Add step 4,5 or 6 code.

Or
Contact me on whatsapp
+923065090466

0
PrashantM38
PrashantM38

4 years ago

I was able to do it with HC-05 Bluetooth. Renaming the Default Name of bluetooth would have helped in this (which i did ...research)..Thanks

0
awaiskhawar
awaiskhawar

Reply 4 years ago

yes you can use it hc-05 in slave mode

0
Saliksheraz
Saliksheraz

4 years ago

O Great bro thanks really amazing it is I will insha Allah try it after my test for nust

0
M. TahaA
M. TahaA

4 years ago

Good work bro ! Keep it up (Y)

0
qwaqar8
qwaqar8

4 years ago

Let's plan it on a large scale

0
Shah SaudK
Shah SaudK

4 years ago

Well done good job

0
awaiskhawar
awaiskhawar

Reply 4 years ago

Thanks man

0
HubertC
HubertC

4 years ago

Thanks

0
HubertC
HubertC

4 years ago

I do not believe the first one works because the <p></p> does not register with the arduino.

0
awaiskhawar
awaiskhawar

Reply 4 years ago

See down .ino file is available go and download from there

When i paste program from pc
Then this will appear
