Introduction: How to Phase Your Speakers

About: I am an AV and IT guy... I have been involved with sound and lighting since I was 7 yrs old. I currently do Information Technology work for a living, and professional sound as a side job. Although I do both …

In this instructable I will cover phasing of speakers.  This is designed to be just a introduction to phasing, some phasing techniques are very advanced, however, I will show you what I think is the easiest way to think about phasing.

Step 1: What Is Phasing?

Many people might ask: "What is phasing?".  That can be very difficult to explain, but I will do my best.  When you produce artificial sound from multiple sources, you always run the risk of being out of phase.  What I mean by out of phase is this: one source is "contradicting" what the other source is doing.  When a speaker produces sound, it is vibrating back and forth.  When you phase a speaker, the idea is to have both speakers moving in the same direction.

Step 2: When Do You Need to Phase?

Let's determine if you even need to phase your speakers.  There are a three questions you need to ask yourself.

1.  What were these speakers meant to do?  (Pro Audio, Stereo system, Surround Sound, etc.)
2.  What was the amplifier meant to do?  (Pro Audio, Stereo system, Surround Sound, Powered Speakers, etc.)
3.  What orientation was the system designed to be used in?  (Facing each other, same direction, surround, etc.)

If you are using the system in the way it was designed, then you do not need to phase the speakers.  But if you have a system that was designed to be used with the speakers facing each other and they are now facing the same direction, or you have a system that was designed to be used with the speakers facing the same direction and they are now facing each other, you need to phase them.

Step 3: How to Reverse the Phase

Now that you have determined if you need to phase, the next part is easy.  This is how we phase a speaker.  Normally on a straight phase, the marked wire would always be in the positive jack of both the speaker and the amp.  With a reversed phase, the marked wire should be reversed on either the amp or the speaker.  (Not both.)   In this way you are reversing the polarity so that when the speaker would normally move out, it moves in; and when the speaker would normally move in, it would move out.

Step 4: Copyright

Please note that I do claim copyright to the information. I did not use any specific sources when compiling this information, all of this is from my personal experience.

You may quote parts of this information for educational purposes. Under no circumstances will you sell this information.

I do not own the copyright to any of the images, however, as far as I have been able to find, I have the right to use them in this instructable. If there is any question about whether or not I have the right to use these images, please contact me. I have no intention of stealing anyone's intellectual property.

Use of this information implies that you agree to these copyright terms.

© 2011

1 Person Made This Project!

Recommendations

  • Jewelry Challenge

    Jewelry Challenge
  • Raspberry Pi Contest

    Raspberry Pi Contest
  • One Board Contest

    One Board Contest

26 Comments

0
mlwmlw99
mlwmlw99

8 years ago on Step 4

Phasing can also be used to simulate surround sound (pretty well, I might add). Your receiver needs to have two pair of speaker outputs. Hook up your front speakers properly phased (i.e., receiver+ to speaker+ and receiver- to speaker-). Get a pair of cheap rear speakers (matched properly ohm-wise to your front speakers so volume output matches). Hook up the rear speakers to the second speaker terminals on your receiver. However, hook up these rear speakers as follows: receiver+ to speaker+ but speaker- to speaker-. In other words the left and right rear speakers have their + going to the L and R receiver+ but their - going to each other. This will only produce sound from the rear speakers that is common to both left and right channels. It gives a very nice and subtle spatial effect to your music. Depending on the front and rear speakers, it might take a cheap volume control for the rear speakers so that their volume is more background than foreground. Some receivers might have a fader control that will accomplish this also. IMHO, the sound is more pleasing than some of the spatial effects that are built-in to many receivers out there today.

0
thegeeke
thegeeke

Reply 8 years ago on Step 4

Nice! I never thought about doing it that way, but you're right, it would sound pretty decent. Thanks for sharing!

0
noingwhat
noingwhat

10 years ago on Step 2

When you spoke about the speakers facing each other or facing the same direction, should there be a difference with phasing them? I know that if you have two speakers facing the same direction, they should move in sync with each other, but if the speakers were facing each other, would that still hold true?

D<<<< >>>>>C
or
D<<<< <<<<

0
Dantonton485
Dantonton485

Reply 12 months ago

No if you intend to create a situation where the speakers face each other you’re will need to wire them out of phase so that the speakers move in phase. Phase is the motion of the speaker cone in relation to its terminals and the signal it receives and the driver/speaker.

0
thegeeke
thegeeke

Reply 10 years ago on Step 2

No, think about it this way: when they are facing the same direction and are moving in sync (phased the same way), when both diaphrams push out, it pushes the sound in the direction that the speakers are pointing. When they are facing each other and phased the same, they are still pushing the sound in the direction they are facing, so the sound from one speaker is doing the oppisite of the sound from the other speaker since they are facing each other. Remember that a speaker produces sound by moving the diaphram in and out very rapidly. I like to take a snapshot in my mind of the diaphrams with a positive charge and visualize if the sound is moving in the same direction. I also have the ability to visulize how sound waves will interact with each other... but that's just something that I learned from experimenting, I never had someone teach me how to do that.

0
Dantonton485
Dantonton485

12 months ago

As far as the copyright issue I agree with others I don’t think what your presenting here meets the standards of copyright. The information your presenting has been published in many text books and other publications that have been copyrighted. If anything your infringing on those publishers by claiming this information is yours. Though you may not have literally copied the ideas word for word from publications it does not matter. I do believe this is based on your experience in working as you state but that does not matter. You acquired the knowledge in a different way but these principals have been well established probably prior to your birth. The basic concepts of phase alignment that you present have been published previously in the 1940-50’s

0
Dantonton485
Dantonton485

12 months ago on Step 4

I believe your Step 2 diagram is wrong. When two speakers are connected in series the phase of the second speaker will be out of phase if the minus terminal of the first speaker is connected to the positive terminal of the second speaker and the negative speaker terminal of the second speaker is connected to the amplifier. In your diagram the second speaker in the series circuit is connected to the negative terminal at least you have it labeled that way. When you reverse the polarity of the second speaker in a series connection you can correct the phase so both speakers are in phase. The speaker according to your labels indicate that the speaker would actually play in phase in the series arrangement yet your arrows for the second speakers incorrectly show the second speaker out of phase. In order for your diagram to be correct (showing out of phase)you would need to reverse the + and minus labels of the second speaker which is what I think you meant to do. Also you should show an example of a series circuit with two speakers with phase correction (reversing connection of the terminals) and show the parallel circuit in another area. Basically as you know all parallel circuits are in phase it is only the series connection that we need to be concerned with phase assuming we are not talking about the more complex matter of inverse phase alignment cause by 2nd order crossover networks applied. As you know introducing a 2nd order 12 db crossover filter in a parallel circuit will cause a 180 degree phase alignment issue so often the second driver in a 12 db 2nd order filter should be connected in reverse polarity to correct for the phase misalignment of the filter.

0
AndersM15
AndersM15

1 year ago on Step 4

You don't own the copyright.
https://www.autodesk.com/company/legal-notices-tra...
15. License
. By uploading, emailing, posting, publishing or
otherwise transmitting content to any Forum or submitting any content to
Autodesk (each, a “Submission”), you acknowledge that such Submission
is non-confidential and automatically grant (or warrant that the owner
of such rights has expressly granted) to Autodesk a perpetual,
royalty-free, fully paid-up, irrevocable, nonexclusive, sublicenseable
(through multiple tiers) right and license to use, reproduce, modify,
adapt, publish, perform and display (whether publicly or otherwise),
transmit and distribute such Submission in any form, medium, or
technology now known or later developed. In addition, you warrant that
all so-called moral rights in the content have been waived. For each
Submission, you represent and warrant that you have all rights necessary
for you to grant the licenses granted in this section, and that such
Submission, and your provision thereof to and through the Site, comply
with all applicable laws, rules and regulations.

Not to mention that there's a Creative Commons notice at the top right by the publishing date

0
jorricks
jorricks

8 years ago on Introduction

Anything is possible, if you don't care who gets the credit.
— Harry Truman

0
DGerman
DGerman

8 years ago on Introduction

It appears that the figure in step 2 shows a single source ( for example the left channel) connecting 2 speakers in series (upper image) or parallel (lower image). Shouldn't it show 2 sources?

0
thegeeke
thegeeke

Reply 8 years ago on Introduction

Not necessarily. Basically that figure is showing a Mono setup, which is what you would use in most professional audio setups. Stereo (two audio channels) is what you would use in a home theater setting, or in professional audio if you need to pan a track or channel to a specific side of a room for some reason. (For instance: making thunder sound like it's moving from one side of the room to another.)

0
sspence
sspence

8 years ago on Step 4

You can't copyright common knowledge. You didn't invent the process of phasing. Sound engineers have been doing this for decades. I phased my speakers back in the 70's when I was 13.

0
thegeeke
thegeeke

Reply 8 years ago on Step 4

I'm not copyrighting the process of phasing, merely the way that I presented it. If you want to create an adaptation of how I presented it, fine. If you want to create your own presentation on how to phase your speakers, fine. But if you copy me word for word, then we have a problem. That is all that I claim copyright to.

0
jj.inc
jj.inc

9 years ago on Step 4

Well this is special, you should share some useful information because I have found out more from googleing your instructible subjects than what you have provided. Did you know sound isn't really just a sin wave. A pure note will appear as a sin, but it will actually zig-zag, even a tuning fork will, which is what this image is of

0
thegeeke
thegeeke

Reply 9 years ago on Step 4

Yes... I did know that... But almost all sound can be created from or reduced to a sine wave at some point. (And it is sine wave... Not sin wave... The wave didn't do anything bad!)

I really don't understand why that would affect phasing though. The concept is still the same, and it is still necessarry. If there is something you think I missed, please let me know... I am more than happy to add it. The purpose of my instructables is to provide the basic information that professionals like myself use day to day in a way that someone who knows nothing about sound can understand.

0
e5frog
e5frog

10 years ago on Step 4

Copyright to what? How to connect your speaker the way you are supposed to? There's a + and - on the speaker and a + and - on the speaker output... Doesn't seem that hard to me...

0
thegeeke
thegeeke

Reply 10 years ago on Step 4

Forgive me for asking, but did you actually read what I published?  I didn't publish how to connect your speakers, I published how to phase your speakers.  There is a difference.  Connecting your speakers is involved in phasing your speakers, and by phasing your speakers you will connect them.  However, it is not as simple as connecting + to + and - to -.  I claim copyright to the information I provided in this instructable.  If you don't agree with what I wrote, then you wouldn't want to steal it, so you don't have to worry.  However, anyone who knows even the basics of sound will tell you that phasing is necessary if you want good sound.

I am not required to provide this information to anyone, but I don't see anyone else posting about how to phase on this site, so I figured I would.  I make up to $200 an hour doing professional audio and home theater design. Phasing is just one of the basics of my craft.  When you can "shape" sound, and make $200 an hour doing it, then if you still disagree with what I say in this instructable, then we can talk.

Every time I publish an instructable, people ask me why I put the copyright step in.  However, they ask me because I choose what my license agreement is when I publish the instructable, not because they think it shouldn't be copyrighted.  The reason I use redundancy, is that I never noticed the license link on the side of the page before I published an instructable, and I want to absolutely clear on what my terms are.

If you did read my whole instructable, and you didn't understand it, I will be happy to explain to you in more detail.  However, I sincerely doubt that you read the whole thing.

-thegeeke

0
rimar2000
rimar2000

10 years ago on Introduction

The phasing is a need, your instructable is good, but the image in step 2 is wrong, or at least ambiguous. And the image in step 3 is incomprehensible. Pardon, this is my thinking.

0
thegeeke
thegeeke

Reply 10 years ago on Introduction

I appreciate constructive criticism, and do not easily take offense. I'm glad that you like my instructable aside from the two pictures. Thank you for your advice, and I will attempt to find some better pictures. :)
