Introduction: LED Desklamp Conversion

While clearing my store, i found  my old desk lamp, non working desk lamp. Despite repairing, i rather convert it to LED which is better brightness and energy efficient too.

Step 1: Disassemble the Lamp

The parts of desk lamp when dismantled.

Step 2: PCB Design and Stickering Techniques

The circuit and LED arrangement are made using PCB software.From the software using P-Cut machine the layout of circuit are made

Step 3: Board Preparation

After submerge the board into the ferric chloride acid, the remaining sticker are removed to reveal the copper trace

Step 4: LED Board Preparation

The board are stick with chrome sticker as reflector and and drilled for LED

Step 5: LED Soldering

The LED used here are piranha type from ebay. just about MYR 0.25 each.

Step 6: LED Board Mounting and Finishing

The completed LED board wire soldered and mounted using copper stand to the plastic body.

Step 7: Power Supply

All components used as power supply for the LED lamp.
Just a simple LM7805 voltage regulator circuit.
after all components soldered and tested, the board and transformer are mounted back into the base.

*transformer used here are salvaged from old radio. Heavy transformer makes the lamp more stable

Step 8: Assembly

All arm and lamp parts are assembled as original condition with proper wire dressing.

Step 9: Circuit Board Set-up

the power supply board and power transformer are screwed and mounted properly with proper arrangement for cover.

Step 10: Testing and Finishing

Excess silver shining sticker removed, and the lamp are tested
Ready to light...
