Introduction: LED Test Module


Header Connector PS1B50 http://www.signal.com.tr/pdf/cat/2-78.pdf

LM317T Voltage Regulator http://www.signal.com.tr/

1pcs    x   1uF/50V E-Cap.
1pcs    x   10uF/50V E-Cap.
2pcs    x   1N4007 Diode
1pcs    x   200R 1/2W resistor
1pcs    x   5Kohm Potentiometers
1pcs    x   100nF/50V Film Cap.
1pcs    x   9V Battery
1pcs    x   Battery Strap
1pcs    x   Printed Circuit Board
2pcs    x   Cable Strips
1mt      x   Wire




Step 1:


Mounting Big Parts

Step 2:

Ready

Step 3:

Please watch embed video
