LED With Cooler Heat Sink

LEDs are cool! But they tend to get hot and start flickering! We usually put Heat Sinks salvaged from old computers which can do a decent job, but they are not enough for High Power LEDs. So, I tried to sandwich a peltier chip between the computer heat sink and a 100 W LED module, and it worked!

There was something very interesting which happened, as I had tried using all the 12V adapters in series at home to power the circuit (including wi-fi and few other devices, and my folks were not very happy about it! ). After getting too hot, the peltier chip was sending back-emf which was stopping the fan. The trick here is to keep the power supply for peltier, LED and fan separate.

Here is my instructable for the project!

Step 1: Stuff You Need for This

1. LED module, I used a 100W one.

2. A heatsink and fan from an old computer.

3. Peltier chip, I used one with max. power rating of 92W.

4. Thermal paste

5. Wires

6. Clips for putting everything together

Step 2: Prepare the Heatsink Assembly

1.Put some Thermal paste on the heatsink and apply it with a metal strip evenly.

2. Repeat the process on all the surfaces, on both sides of the peltier and the metallic side of the LED module.

3. Place the LED on top of the cold side of peltier, and hot side on the heatsink in a way that peltier is sandwiched.

Step 3: Attach the Fan to Heatsink Assembly

1. Attach the fan to this assembly by clips or any other way possible.

2. Connect it to different power sources

Since I have made one already, and I am too lazy to solder all these together. I am just lighting my old one for the demo!

Comments

[qqqqqqqqqqqqqqqqq]

Wouldn't it be easier, cheaper and more efficient to use water cooling on your LED?

[Abhindas]

Water cooling needs a lot more space to start with, with peltier it can have a smaller form.

[Yonatan24]

Well, Using a peltier will probably make you need a power supply that can give at least 15AMPS, 100WLED+~5AMPpeltier= Expensive power supply...

[watkijam6]

use a computer power supply...buy used computer or find a throw-away

[steven4872]

"There was something very interesting which happened, as I had tried using all the 12V adapters in series at home to power the circuit (including wi-fi and few other devices, and my folks were not very happy about it! ). After getting too hot, the peltier chip was sending back-emf which was stopping the fan. The trick here is to keep the power supply for peltier, LED and fan separate."

Your lamp assembly draws about 200 watts. Wi-fi and a few other devices probably add at a minimum 30 additional watts. Most 12 volt adapter are not rated for that kind of power. The most powerful power supply I have is a 90 watt 20V power supply that powers my laptop. Most of the rest are typically rated at less than 20 watts.

You were probably overloading your power supply. Frequently overloading a power supply will cause it to fail. However if it doesn't fail it could also cause the power supply to generate a lot of EMF noise and voltage regulation problems,. Peltier chip running on stable DC power will not cause EMF. If you replaced your power supplies with one rated at the correct voltage, power, and current ratting you probably would not have had the EMF issue.

[Abhindas]

The total number of power supplies I used were five, three 12 V and two 20V supplies from laptops. For LED I used one Laptop and one 12V supply in series. For the peltier I used a similar configuration. And another 12V for the fan. This was after I tried putting everything in series and the fan would stop after a while and LED would also stop.

[ironsmiter]

the concept is awesome, and practical. even commercially viable.

the execution and planning, a bit more on the what NOT to do side.

32 volts into the led? and another 32 for the peltier(which are almost always 12 volt devices)? all likely with a shared ground(formerly fumctional power strip?)

interesting experiment, but a basic electrical circuit refresher is in order.

unless your devices were rated for and required those voltages and even then, each series supply would cap out at the lowest rating of the pair(12v1A plus 20v2A is equal to or less than a 32v1A supply).

kinda surprised you didn't fry your peltier junction, burn our some of the leds, and most surprising that you didn't blow a breaker or ground-fault switch with the power wiring hijinx

.

[Abhindas]

Thanks a lot for pointing that out, to be honest, this is probably the first time I am trying something electrical or electronics. I ll make sure of using a proper power supply for further experiments.

[steven4872]

Your led is 32 to 34 volts at 3.5amps. You powered thay with 20V and 12 power supply in series. It is generally not a good idea to wire two power supplies in series. If one power supply cannot supply the needed surrent its voltage may drop and more of the load may go to the other power supply. This might cause voltage oscillations. Your luckey you din'tblow the LED and power supplies. If you have to use two power supplies in series make sure the current output rating of each power supply exceeds the current the LED needs.

[Abhindas]

Thanks a lot, I am never going to repeat adding power sources to get a higher voltage.

[oldskoolhead]

then you would just need a 12v 10a supply for the peltier and fan

[oldskoolhead]

just get a meanwell
LPV-100-36 should power that led just fine

[Yonatan24]

I've heard that putting them in series is okay and putting them in parallel is bad, I guess I was wrong and right

[steven4872]

12V Peltier are common because many portable coolers are designed to plug into car 12VDC systems. Peltier arrays are available in voltages from as little as one volt to many volts. It all depends on how the individual peltiers are wired together inside the device. I have seen a 60W Peltier rated at 15V. For a 100 watt device 32 volts is a reasonable voltage.

While Peltier arays are quite small the high current needed results in large power supplies and thick wires. Using high voltage Peltiers can help reduce the size of the power supply and wires by reducing the needed current.

The same goes for the LED he used. If it was one led it would need about 3.5V and about 28 amps of current and very thick wires. But if you wire a bunch of smaller LEDS in a sereies parallel arrangement and then coat all of them with a single piece of phosphor you can get 32V requirement that would only need 3 amps and thinner wires..

[JuanF10]

1.Para mi es mejor utilizar el calor que arroja el chip LED para generar el voltaje de la alimentación para el ventilador por la celda de la cámara, seria interesante probar de esta manera para ver cómo funciona el peltier en modo generador termico.

.

[Budweiser143]

Would it be possible for you to add some images of how your using thhis LED, and its brightness?

[Abhindas]

I currently don't have a Lux meter, but as soon as I get my hands on one, I ll post it here. It was bright enough to not look straight into it.

[martonthenagy]

Use any digital camera that has ISO + Aperture settings, and Shutter speed readings.
http://www.conservationphysics.org/lightmtr/luxmtr...

It is not as good as a commercial product, but much better than nothing.

[Yonatan24]

I think I can tell you about how bright it is:

INCREDIBLY BRIGHT, I used 10X 10W LED's to make my "SpectrumLED- Variable Spectrum LED light" (picture below) Having 10X 10W are more efficient than one 100W LED

It can light up my whole room easily, Which might not mean anything to you, But it is just incredibly bright. My camera auto adjusts the brightness so it doesn't look as bright as it really is, But it is blindingly bright!

By the way I'm also uploading a full step-by-step Instructable of how to make "SpectrumLED" in a couple of days, In case you're interested...

[kennykaos]

I am trying to design a fan-less 100Watt led design for outdoor. Would a peltier be more reliable than a fan? I have a heat-sink with 4 direct contact heat-pipes on the way. I am going to back the voltage down until it will run cool without a fan (just heat sink) to see what it will do.12 hours on 12 off, I think the fan would be the weakest link, if I had to use one. I am thinking the peltier might be more reliable than a fan with no moving parts. I would like to use it between the chip and heat-sink.
