Introduction: Laser Pen Sound Visualiser

About: Composer, Sound Designer And All Round Noise Maker. I use both field recordings and synthesis to explore the act of play through improvisation and interactivity. My installation art sits somewhere between col…

In this guide you will discover how to make your own sound visualiser with simple resources. Allowing you to see a visual representation of sound, music or whatever you can plug into a speaker!

PLEASE NOTE - This guide does use a laser pen which can cause serious eye damage if used improperly, so please use with care.

Supplies

  • Laser Pen
  • Speaker
  • Sound Source (e.g phone, laptop etc.)
  • Cling film
  • Rubber Band
  • Mirror fragment (mirror ball, old CD)
  • Double sided tape

Step 1: Building the Visualiser

Begin by wrapping the clingfilm over your speaker to create a seal. Depending on the size/shape of your speaker you may need to place it into a bowl and wrap the cling film over the bowl.If you don't have clingfilm you can use a balloon, swimming cap - anything stretchy that will create a seal. I used a rubber band to keep the clingfilm in place, you could however use a cable tie as an alternative.

For the reflective element (which we shine the laser onto) I used fragments from a cheap mirrorball and stuck them on with double sided tape. However, you can also use the mirror section from a blank CD/DVD.

Where you place the mirror fragments is important to the shape of the projection, so try and place it as centrally as possible. But don't be afraid to experiment with different placements once all setup.

Step 2: Getting Setup

Plug your sound source into your speaker, for my video I was sending sound from my computer with a 3.5mm cable into my speaker.

How you arrange your laser and speaker will affect where the projection ends up in your room. At this point it is incredibly important you are careful with the laser and avoid your eyes. Depending on the strength of your laser it could cause serious damage.

You will need something to hold the laser pen in place, I use a set of 'third hands' to hold mine, however you could quite easily balance it on some books and tape it down. In my experiments I found that the more acute the angle is the more round your projected shapes will be. As the angle between the laser and speaker surface gets more obtuse the projection stretches into a thin line with not much horizontal movement.

Step 3: Seeing the Sound

Once the pen and speaker are setup as you like, you can begin playing the sound and et voila - you're visualising sound!

In my experiments I found lower/bassier sounds 'visualised' better - however volume also made a big difference as louder sounds 'excited' the clingfilm, and therefore the mirror, more. This is because more air is moving and pushing the cling film back and forth.

To make my music video I simply turned off all the lights and used my phone to film. You may notice it looks different in footage to in person, and this is to do with cameras working different to human eyes.

For a better explanation of this, scientist Steve Mould has a fantastic video where he explains what's happening.

Be the First to Share

    Recommendations

    • Lamps and Lighting Contest

      Lamps and Lighting Contest
    • Tinkercad Student Design Contest

      Tinkercad Student Design Contest
    • Plastic Challenge

      Plastic Challenge

    5 Comments

    0
    NirL
    NirL

    1 year ago

    Nice project:) looks cool!
    I was wondering about a few things:
    1) why do you need the cling-film? Isn't it enough to just attach the mirror to the speaker? It's already shaking by itself, isn't it?
    2) In step 1 it looks like you did connect the mirrors to the speaker itself, but then at the 2nd step it looks like you covered it with the cling-film. At the mirror attached to the cling-film? (if not, I'm trying even harder to see why you need that part for the project)

    Thanks!

    0
    frazermerrick
    frazermerrick

    Reply 1 year ago

    Hi :)

    From my understanding, different parts of the speaker will move at different rates (as they make slightly different sounds). So by putting the mirror just in front of the speaker it means you've got more change of their being movement. However I'm not 100% certain, you could certainly experiment with it and see what works best. Be careful though, if you damage the speaker cone itself they're tricky to repair.

    In step 1 there clingfilm is still there, its just pulled really tight so it looks almost invisible! I hope that helps.

    0
    NirL
    NirL

    Reply 1 year ago

    Thanks!
    About what you said about different parts of the speaker making different sounds (just because it sounds like you might be interested):
    Each moving part in your speaker (or any other object) has its natural frequencies. When you plan music, or even a single tune, chances are that its not one of the natural frequencies of your speaker (or any of its moving parts). Since its not a natural frequency of the any of the moving parts, it will invoke many harmonics, and not a single tune, and since each moving part would have different natural frequencies, each of them would have different harmonics which makes them sound different! that's why playing the same note on a piano or a guitar sounds different, it's all in the harmonics!
    So the vibration of each of the parts would be mostly of the same as the sound you're trying to play, but also some harmonics that you didn't ask for (which makes them sounds differently).

    I know that didn't make too much sense but still :)
    good luck in your next project!
