LilCubey - a 3d Printable MATX Acrylic Cube Pc Case

This is a nice-looking, 3d printable pc case designed to stand out. The sharp corners and plexiglas give it a modern, futuristic and eye-catching appearance. Another great thing about the design is it only need a 180 x 180mm bed to be printed.

The airflow is also designed optimaly where the gpu and cpu manage to stay cool even on the most intense benchmarks.

Pc case features:

310mm GPU

205mm CPU Cooler / Single fan AIO

5 x 120mm Fans

SFX PSU

MicroATX/MiniITX

1 Slot for SATA SSD

Also alternatively to the writen guide with images below I recommend checking out this assembly video

Supplies

For the tools you need:

1. Soldering iron
2. Screw driver
3. Hot glue gun
4. Drill

For the materials:

1. 3-5 kg of filament (any color)
2. Pack of m3 heated inserts
3. Pack of m3 screws
4. Pack of PC screws
5. 3 plexi glas sheets (336 x 336 x 4)
6. 16mm button

Step 1: Printing

3d printing the parts!

I personally used PETG and 15% infill, but higher infill will also work great.

These are all the parts you need to print:

(You can also check out the thingiverse)

Step 2: DownParts

Assembling the pc case!

You need 7 heat inserts for this step.

Just Insert the heat inserts like on the images.

Step 3: DownParts Assembly

First insert 1234Connector

Second slide in 3 and 2DownPart

Third, connect parts by inserting 4 LilConnectors

Step 4: MotherboardPieces

You need 7 heat inserts for the parts.

Insert the heat inserts exactly like on the images.

Step 5: MotherboardPieces Assembly

First slide through 6 and 5 MotherboardPiece

Second put MotherboardPieceAttacher into parts

Third, slide in 7 and 8MotherboardPiece

Fourth, insert 4 LilConnectors

Step 6: Sata SSD

If your planning to use a SATA SSD, i recomend sliding it in and screwing it in.

Step 7: BackParts

You need 11 heat inserts for this

Just some normal heat inserting like before

Step 8: BackParts Assembly

First slide in 9 and 10 BackPart

Second, slide in BackPartConnector

Third, insert the 16 mm button into the hole on 11BackPart

Fourth, slide in the 11 and 12 BackPart and insert 4 LilConnectors

Step 9: FrontPanels

You need 10 heat inserts for these parts

Nothing unusual, just heat inserting

Step 10: FrontPanels Assembly

You will need12 m3 8mm screws with12nuts

Before screwing in, screw in a nut fully into the screw. Then screw into pc case. Do that for all parts.

Step 11: MotherboardIoParts

You need9 m3 8mm screws with9 nuts

First take your SFX Power Supply, 18IoMotherboardPart and screw it in

Second, take the newly screwed in IoMotherboardPart and insert it into the pc case and screw it in

Third, take 19IoMotherboardPart and screw it in

Step 12: Front Fans

You'll need4 120mm fans +8 fan screws for this

Place in the 120mm fans and screw it in only where the image shows

Step 13: Motherboard Part

You need6 Standoffs + Motherboard screws and your motherboard (with cpu fan, ram and etc obviously installed in)

First Screw in the standoffs

Second insert and screw in the motherboard using as many motherboard screws you need

Third, Dont forget the Io Shield!

Step 14: MotherboardPiece

You need 4 heat inserts

Insert all heat inserts Into 21MotherboardPiece

Step 15: MotherboardIoParts Assembly

You need2 m3 8mm screws, 2 nuts, 1 120mm fan/AIOcpu cooler fan, screws for the fan/AIO and3 LilConnectors

First screw in 20MotherboardIoPart

Second put in3 LilConnectors into where shown

Third install your fan/AIO with whatever screws you need

Step 16: TopMbnBackConnectors

You'll need4 m3 8mm screws,2 LilConnectors and 2heat inserts

First screw in 20TopMbnBackConnector

Second screw in 21TopMbnBackConnector

Third insert2 LilConnectors

Fourth insert2Heat inserts as shown

Step 17: LongThings

You need 2 heat inserts and 2 LilConnectors

First take 24Longthing and insert in2 heat inserts

Second position 24 and 25Longthing and attach2 LilConnectors

Step 18: ExtraFrontConnectors

You need2 ExtraFrontConnectors and4fan screws

Place the ExtraFrontConnectors and screw it in with the fan screws

Step 19: 24 and 25LongThing

You need 4 m3 8mm screws

Grab 24 and 25LongThing, place it and screw it in

Step 20: GPU

You'll need2heat inserts, a GPU and2 m3 screws (any lenght that works)

First insert in2 heat inserts (or more depending on your setup)

Second, inserts in your beautiful GPU

Third, Screw in the GPU with the m3 screws

Step 21: 1 Heat Insert

You only need1 heat inserts for this

Just insert the 1 heat insert

Step 22: PlexiPlugA

You'll need 8 m3 8mmscrews and nuts

Place the Plexiplug'sA and then screw in

Step 23: PlexiPlugB

You'll need 8 heat inserts

First place the PlexiPlug'sB in

Second place the PlexiPlug'sB in

Third, add4 heat inserts

Fourth, add4 heat inserts

Step 24: Plexi Glas Drilling

For the pc case to be complete 3 336 x 336 mm plexi panels are needed. Each with 4 holes on the corners.

You need to drill4 holes per plexi glas as show on the images on every corner.

Step 25: PlexiPlugC

You need12 m3 6mm screws with nuts

First attach PlexiPlug'sC onto the pc case and screw it in. Do the exact same for all other panels.

Step 26: PlexiPlugD

I recomend using hot glue for this.

Attach the PlexiPlugs'D onto the PlexiPlug's and use some hot glue in beetween

Step 27: FINISH!

Now you've completed your cool-looking pc case, go ahead and enjoy it!
