Logic Gates Using Transistor

Introduction: Logic Gates Using Transistor

About: Arduino and electronics projects

Logic gates are the basic building blocks of any digital system.

Supplies

1. BJT BC547 (4)

2.1k ohm (4)

3. 470 ohms (2)

4. Push Button (4)

5. LED (2)

to buy all product use this link click here

and "SAVE5" coupon at checkout

Step 1: Theory

Transistor as switch

Step 2: AND Logic Gate Using BJT

Transistors are connected in series.

Connect one terminal of push-button to the base of the transistor and another to Vcc via a 1K resistor

Step 3: OR Gate Using BJT

Transistors are connected in parallel.

Connect one terminal of push-button to the base of the transistor and another to Vcc via a 1K resistor
