Introduction: Lost Wax Casting
This is a brief outline of my lost wax casting technique. There are several ways to cast, this is just the way I do it as a one woman show! Also, this was my set up about 13 years ago and some things have changed - I have a slightly updated longer version here on my website.
You can view a lot of my finished work at BethCyr.com
I use all sorts of random tools for my wax working. Most importantly, my fingers (and finger nails), and I started out with a tiny needle in the end of a pencil and made a little denatured alcohol lamp out of a baby food jar. The wax I use most of the time is a soft brown wax. It's my favorite.
If you're interested in getting your own casting set up - check out my supply list!
Step 1: Wax Work 1
The beginning of one of my flowers
Step 2: Wax Work 2
Another flower ring, almost finished
Step 3: Wax Work 3
This flower is all sprued! Spruing allows the wax to melt out of the mold and for the metal to get to your piece! not having enough sprues or having them in the proper location can cause your piece to not turn out.
Step 4: Weighing Them Out
After all sprues have been attached its now time to weigh them. This if very important and is often forgotten. The weight of the wax is used to determine how much metal you will need for the casting. Because each metal has a unique specific gravity - you will need to know what number to multiply your wax weight by. For sterling, you can do it two ways - you can multiply by 10.4 and then add a half ozt (troy ounce) or you can simply multiply by 15. I usually do both to be on the safe side and figure something in the middle. For very small or very large, using the 10.4 plus half ozt is usually best.
Step 5: Attach to Sprue Base
After the waxes are weighed, its time to attach them to the sprue base or button.
Step 6: Place Flask on Base
Then the flask is lowered over the waxes. It is important that there is at least 1/4" of space between the edge of the flask and the waxes. Now believe me, I've pushed it and nothing bad has happened, but that doesn't mean that it won't. You can have a blow out where the hot molten metal breaks through because there was not enough investment. Same with the top of the flask, if the wax is too close to the top, the metal can break right through. And for vacuum casting, this could be very bad as the metal would most likely damage your casting table.
now you are ready to invest!
Step 7: Set Up for Investing
You need to know the size of your flask and how much investment you will need. For this sweet little flask, I only need a 1/2lb and 3.5oz of water. Measure the water out first and pour it in the rubber mixing bowl.
Step 8: Weigh Investment
Now weigh out the investment. Investment contains silica - so you should wear a dust mask if you don't have exhaust. I got this cute blue scale for very cheap - and its blue! no need to spend big bucks on an expensive scale - it just needs to work.
Step 9: Time It and Start Mixing!!
Set the timer for 8 minutes. This is the longest that your investment should be disturbed. Once it starts setting up, you don't want to be messing with it. I start the timer and then pour the investment in to the water. Mix for 3 minutes - right when it turns to 5 min, its time to vacuum.
Step 10: Vacuum Investment in Bowl
Now that you've mixed for 3 inutes, vacuum the investment for 2 min - this is the first step in vacuuming. Bubbles are good - this is the vacuum getting all the air out of the investment
Step 11: Pour Investment in Flask
Now, pour the investment in to the flask. Its a good idea to have tape around the top of your flask to keep the investment from bubbling over and making a huge mess. When pouring, pour down the edge of the flask, not directly on the waxes as it could cause the wax to move slightly and perhaps against another wax or too close to the edge.
Step 12: Vacuum Investment in Flask
Now for the vacuuming of the flask! If you are vacuuming more than one flask of the same size, make sure to mark them. I use a piece of chalk to write a number corresponding to the wax weights - the chalk doesn't burn off in the kiln so its easy to distinguish when getting them quickly. This removes air that might have been trapped around the waxes and still in the investment from pouring - vacuum for approx 1.5 minutes - don't go over your 8 minutes.
It bubbles up and over like an ancient tar pit! The rings were pretty small in this flask, so I didn't fill it up all the way to reduce the bubbling over.
If there was a little bit of investment left over, after the time is up, pour the little bit on top. With vacuum casting, you need to leave at least 1/8 of an inch at the top to aid in the suction during the casting. if doing centrifugal casting, it can go over the top of the flask.
now it needs to sit for about 10 - 15 undisturbed until it sets up, then it needs to sit for about 1.5 - 2 hours before you can start the burnout process in the kiln.
Step 13: In the Kiln!
Once the flask is ready - it goes in the kiln and starts the burnout process. Burnout times are anywhere from 5 - 12 hours. The 5 hour burnout is perfect for just doing a couple of small flasks. Since I'm just a small time operation and didn't have the extra $900 to spend on an automated system, I have to manually adjust the temperatures to make sure the burnout process moves along smoothly. Hour 1: 300 degrees, Hour 2: 700 degrees, Hour 3 and 4: 1350 degrees, Hour 5: 1000 degrees - and hold.
Step 14: Heat the Crucible
Once the kiln has been holding at 1000 degrees for an hour, its time to start heating up the crucible and the metal. Make sure the crucible is red hot before adding the metal.
When the metal has melted, give it a pinch of flux, a stir with a carbon stirring rod (and make sure to heat it up first or the metal will stick to it)
Step 16: Hands Free
Note the hands free set up I made with some nice fire bricks!
Step 17: Get the Flask Out of the Kiln
Now with my hands free, I can get the flask out of the kiln. Make sure to check to see that the pathways are clear - if burning out natural material, some ashes might be stuck. You can check it before you start melting the metal if you think there might be an issue you'd need to clear up, otherwise, a quick check on the way to the casting table is just fine. Also note the giant fireproof glove. I wish they made them in smaller sizes!
Step 18: Place Flask and Turn on Vacuum
Place the flask upside down on the casting table (same as investing table, just make sure the toggle switch is flipped to "Cast") with the holes facing up. Turn on the vacuum pump.
There is a small hole in the table that allows the vacuum to actually pull against the flask and create the suction needed to pull the metal in to the mold and every tiny detail of the mold - even fingerprints show up in the detail captured in the mold material. Pouring the metal in to the mold w/o the suction will result in loss of detail and loss of your piece. How do I know? I accidentally forgot to turn the vacuum on one time. The piece turned out, but much of the fine detail wasn't there. The vacuum is truly needed to get the metal where it needs to go - and fast!
Step 19: Start to Pour... and Pouring!
Position the crucible over the flask - make to always keep the torch on the metal. Removing the torch can cause oxygen to get in and that is bad. As you are pouring, keep the torch on the metal and pour quickly. Pouring too slowly or moving the torch can cause the metal to freeze up and your casting won't work
Step 20: Cool It...
Once the metal is poured, turn off the torch and the vacuum pump. Release the vacuum by flipping the toggle off of cast and move the flask away to let it cool. Wait until the metal is no longer red hot. I check it under a dark area of the table before quenching.
Step 21: Quench It!
Now that the metal has cooled a bit and is no longer red (generally 2 - 5 minutes) it is time to quench. Make sure the flask is completely under the water. You want it to all be bubbling completely underneath the surface of the water. If you have used cast in place stones or some alloys you don't want to quench when the metal is hot. You need to let some completely cool up to an hour so as to not crack the stones or cause the metal to be shocked. Regular sterling is fine to quench after a few minutes.
Step 22: Dirty Casting... Clean the Investment Off
I use a toothbrush to get the bulk of the investment off.
Soaking them in vinegar is a great inexpensive way to remove the investment and to clean the metal! I often leave them in there over night or longer depending on small detail areas. And its nice to have the metal clean already! It does take longer than an ultrasonic cleaner, but if you don't have the money or the space, vinegar works just fine.
And now its time to clean them up! removing the sprues, grinding, filing, sanding, adding texture to camouflage where the sprue had been, adding a patina, and the final polish all await your piece!
