This is just an idea I had a while back. Instead of using springs for a set of scales I thought permanent magnets might do the trick. Unfortunately I didnt think about the properties of magnets, the magnetic field is not uniform and therefore the scale won't go up in even intervals, instead it seems to be an exponential or inverse relationship. But i though I would still publish it since it is somewhat interesting and later on in this instructable I'll tell you how you could get around the exponential problem.

Step 1: Materials

You need:
1) Meccano pieces
2) two permanent magnets preferably with holes (easy to attach to meccano frame)
3)graph paper
5)A set of coins (find out how much they weigh)
6) plastic lid
7) thin wire and string
8) a sheet of cardboard or plastic

Step 2: Put It Together

Put it together so it looks similar to mine in the pics, of course it it can be completely different. Play around with it so you get the largest angle possible from your magnets.

Step 3: Write Measurements Onto Graph Paper

to make the scale on your graph paper it is handy to know that the average thumbtack weighs 0.25 grams and find out how much your countries coins weigh. Luckily here in New Zealand the new set of coins have just come out, and they are of a handy size. the 10cent weighs 3.3g, the 20cent weighs 4g and the 50cent weighs5g. Using these known weights draw up your scale by putting the known weights into the tray on your scale, mark the interval on your graph paper and keep doing this with more weights. I used coins aswell as thumbtacks to check wether they weigh the same amount and to make sure that the scale will be correct. Once you have marked all the intervals on the graph paper your set of scales is finished. mine was very sensitive up to one gram and then the interval rapidly decreased until the magnets touched, just after 10g.

Step 4: Improvements

I talked earlier about improving the set of scales so that the scale isnt of the exponential type. I had the idea that by using a solenoid a uniform magnetic field can be established. The repulsion force will be the same throughout the middle of the solenoid except for the ends. Another benefit of using a solenoid is that a variable power supply can be used to change the magnetic field strength of the solenoid and therefore the scales could be made more or less sensitive. The bad quality picture may help to explain it
