Introduction: Make Your Own PCBs With JLCPCB

About: EE Educator, Pink Floyd fan, father, human,from Earth

It's easy to design your own PCBs and have them made in about a week. I'll show you how in this instructable.

Step 1: Design Your Circuit on a Breadboard

The first step in making your own PCBs is to design and test the circuit on a breadboard. This gives you the flexibility to move things around and switch components until it works just right.

Step 2: Use Layout Software to Draw the Schematic

Now that your circuit works you need to draw the schematic. I used EasyEda because it's cloud based and free but you can use any that you like.

Step 3: Drag Components

Drag your components in the design area. Most layout software has thousands of components to choose from.

Step 4: Make Connections

After your components are on the board, use the track tool to draw in the connections. Don't forget to add power and ground!

Step 5: Switch to PCB Mode

When you switch into PCB mode, the software will bring all your components so you can lay them out.

Step 6: Drag and Drop

Drag and drop your parts where you want them on the PCB.

Step 7: Lay Tracks

Lay your tracks on the bottom and top layers to interconnect your components.

Step 8: Final Touches

Dont forget to add labels on the silkscreen layer and other touches like mounting holes.

Step 9: Download

Download your gerber files from the layout software. You will need to send them to the PCB manufacturer to have your boards made.

Step 10: Go to JLCPCB

Go to JCLPCB.com and upload your files. Select any options you want. You can get 10 pcb's for just $2 plus shipping.

Step 11: Upload

Upload your gerber files and pay for your order.

Step 12: Wait About 7 Days

In about 7 days your new PCBs will arrive!

Step 13: Solder It Up!

Solder up all of your components.

Step 14: Test It Out

Test out your design. You just made your own circuit on a PCB!

Step 15: Watch My Videos for the Full Build

You can see the full build of this circuit along with hundreds of other electronic videos on my YouTube channel: learnelectronics.

How to design your own PCBs - Part 1

How to design your own PCBs - Part 2
