Making Multiway Cables and Connectors

Introduction: Making Multiway Cables and Connectors

We casually buy and use multiway cables and connectors but this instructable is about making some of these cables ourselves.

I was about to write in another instructable about making cables when I realised I didn't remember ever reading about doing it anywhere, no one else said do it. This isn't about getting out the crimping pliers and studiously putting connectors on carefully pared wires, just a quick and simple method to come up with useful cables for use in a wide variety of electronics projects.

The pictures show some of the cables I've made.

  • The main reasons for making up multiway connectors are
  • The connections are made in the same order each time
  • Only one plug needs to be connected instead of many small ones
  • The connections are more secure as the connectors support each other
  • The likelihood of poor or disconnected wires is reduced
  • The variety of cables in a project is reduced
  • The reliability of connections is improved
  • It is simpler, neater and tidier, but that's just an aesthetic

Supplies

A selection of dupont connector housings, either single or dual in line

A selection of multi-way ribbon cables, 10, 20, 30cm in length, terminated with dupont connectors, male-male, male-female and female-female

A fine pointed tool with a tip less than 1mm across, a small slot head watch makers screwdriver is good

Step 1: The Connectors

The pictures are just to show what the connector housings look like and how they 'work' as they are very simple.

The housing is a rectangular plastic tube with a wide square end and a shaped round end. As supplied on basic cables they are a single tube, but are also sold as a multiway housing, with multiple tubes of the same shape in a single plastic piece.

The shaped round end helps to align male connectors with female connectors when being plugged together.

Halfway along the tube is a slot with a moulded plastic tongue which dips into the tube slightly.

When a metal connector is inserted into the tube through the square end, it is notch shaped so that when it passes the plastic tongue it pushes it out of the way, but once past, the tongue springs back (with a small clicking sound if you can hear it) and locks the metal connector in place.

To remove the metal connector from the housing, a small edged tool must be used to lift the tongue up away from the metal and pull the connector out. This isn't difficult but care must be taken to do this gently if the connector housing is to be reused and not broken.

There are many ways in which you could insert a connector into a housing but the way which works as described is with the open side of the connector crimp facing the plastic tongue. After a few tries this becomes very obvious as its the easiest way of inserting a connector, but a bit of trial and error and practise gets it perfect most of the time.

The housings are available in a variety of configurations, but apart from the most common configuration of singles, they come as a single row of connectors in one housing, or the more compact double row of connectors, typically up to 12 in a single line or 24 in two line in a double row. The PCB headers are similarly configured.

The pictures show a selection of connectors.

Step 2: The Cables

The cables don't need much introduction, but briefly they are sold as a ribbon cable terminated at both ends with a dupont connector. They come as a variety of pre-cut lengths, typically 10cm, 20cm or 30cm (occasionally longer) and have machine fitted metal connectors. The connectors on a cable are one of the three combinations, male-male, male-female or female-female.

The ribbon cable is easily separated into the required number of conductors by pulling it apart, and if multicoloured can make connection tracing much easier.

Step 3: Making the Multiway Cables

When you have a project which would benefit from a multiway cable, to make the cable, follow these steps.

1. Determine what connections are required on one end which will benefit from the multiway connection. Having blank or empty connections is ok.

2. Will these require male of female connectors. It is possible to mix them but can be awkward on a circuit board, this is the way to make keyed connector though where it can only e plugged together one way.

3. Decide on the connectors required on the other end of the wires. These may also be in multiway housings, may be singles or a different style of connector (male/female) from the first end or the other connectors at this end.

4. Select from the ribbon cables you have, the number of each type of wire you need. It's usually easier if they are contiguous wires and not separated, but not essential. Also consider the length, if they are better at different lengths then chose the appropriate length, the wires in the housing can be different lengths, it doesn't affect the consolidation.

5. Remove all the single housings from the ends of the wires to be connected to the first multiway housing(s)

6. In the logical sequence for your project, insert these ends into the first multiway housing(s)

7. Remove the single housings from the ends of the wires on the second end, but only the ones which will be going into a multiway housing, no need if they will be single anyway.

8. In the logical sequence for your project, insert the connectors into the second end multiway connectors.

9. Done.

Step 4: Examples

In the picture:

  1. Multiway male connector with a space. The space is a gap on an Arduino board and the cable is made to connect analogue input together, the other end is 5 single female connectors.
  2. Four way female to 2 x 2 way female
  3. 4 x 2 way male to 6 way plus 2 way female
  4. 4 way to 4 way female
  5. 4 way female to 4 x single female
  6. 4 way male to four way female
  7. 8 way female to 8 way female
  8. 8 way female to 5 way male and 3 way male
  9. 2 way female to 2 x single male
  10. 2 way female to 2 x single female
  11. 2 way female to 2 way female

Some of these may seem to be simple cables, but obtaining them off the shelf isn't always that easy, but making them was.
