Introduction: Microbit Tic Tac Toe Game
For this project, my co-worker - @descartez and I created an awesome tic tac toe game using the radio functionality of microbits. If you haven't heard of microbits before, they're an awesome microcontroller designed to teach kids programming. They have A TON of functionality including what we used for this project; the LED matrix, 2 buttons, and radio capability. The game works very simply, we have a 3x3 grid of worker mirco:bits that send a signal of either X or O to the master micro:bit who keeps track of all the win states and also resets the game. We were able to complete this project in less than 24 hours and displayed it during an event the next weekend where it was heavily used! And people seemed to really enjoy it! Obviously, as you follow along, you'll see where we had to cut some corners to get it done in time, but we think what we have so far is pretty rad. Show us your tic tac toe games, or any spots we could improve!
Step 1: Materials
- 10 microbit controllers (All together this costs around $150, which is a lot! However, in our experience there are lots of these around, so don't be afraid to reach out to your community of makers, techies, and students.)
- micropython IDE
- Drill with 1/4 in bit
- 4 pieces of 12x24" 1/8 plywood
- 3 6m 20mm bolts
- 1 6m 40mm bolt
- 4 6mm nuts
Step 2: Game Design
Step 1: Deciding the rules for Tic Tac Toe
Step 2: Code for the worker :bits
- Each worker :bit is given a coordinate.
(0,0) (0,1) (0,2)
(1,0) (1,1) (1,2)
(2,0) (2,1) (2,2)
- This coordinate is adjusted in the top line of code for the worker:bits.
- coord_x = 0
- coord_y = 0
Step 3: Code for the master micro:bit
- The master micro:bit knows a bunch of things.
- It knows all the win states
- It knows all the win states
- This is our workaround for pretty much all of the holes in the code, because we did this project so quickly. If there's a cat's game, the users are supposed to hit reset. Otherwise, we would have had to add in another chunk of code for all the Tie game states, and we just didn't have time to do that
Step 3: Designing the Enclosure
I knew in making this project that I wanted to be able to display this, and that I might not have access to power. This was both a blessing and a problem because it meant that each micro:bit was going to need a battery connected. The easiest solution was to put everything in a box. For this, I generated one using makercase.com. I designed it large enough that it could hold the micro:bits and their batteries, as well as have some written instructions.
I also knew I needed support for the micro:bits to not fall in, so I laser cut a smaller piece to fit behind the micro:bits. This piece is secured screws. The backplate and the sides were glued together, but the top was left detached and only secured with the screws, so that I could access the inside as needed. I used tape to hold the interior panel in place. And to tape them to the front plate so that they didn't fall in or down.
It was a bit tricky, but I got all of the microbits plugged in with their batteries and taped in. On 3 corners I used smalled 6m screws to secure the front panel and the interior panel together. On the last corner, I used a longer screw to screw all the way through the box to hold the lid on.
Step 4: Playtesting
This game was a hit at our weekend event! Kids and adults both seemed to really enjoy trying to work out what was happening, as well as, what components were used. This project only took us an evening to put together, and it was well worth it. Show us your designs, and let us know what tweaks you made!
