Music Synced LED Lamp (using Arduino and Sound Sensor)

5,385

37

3

Introduction: Music Synced LED Lamp (using Arduino and Sound Sensor)

About: Student | Electronics | Love Programming | Foodie | There is always more to learn | Positive Vibes Always |

The Music Synced LED Lamp blinks the LEDs according to the beats of the music.

Step 1: Components Required

1. Arduino Board

2. Different colour LEDs

3. Sound Sensor

4. Breadboard

5. Resistors (100 ohm, 220 ohm)

6. Connecting wires

7. Butter paper

Step 2: Make the Following Connections

  1. Connect LEDs onto breadboard.
  2. The Negative of LEDs should be grounded using the 100 ohm or 220 ohm resistors
    (Negatife of LED -> Resistor -> GND)
  3. The Positive of LED should be connected to the digital pins of the Arduino board.
  4. Connect Ground of breadboard to GND on Arduino board.

Sound Sensor connections:

  1. GND pin of Sound Sensor to GND pin on Arduino board.
  2. VCC pin of Sound Sensor to VCC pin on Arduino board.
  3. OUT pin of Sound Sensor to digital pin 2 on Arduino board.

Step 3: Upload the Code Onto Arduino Board

Step 4: Video Demonstration

Play the Music and enjoy the Music Synced LED Lamp.

Be the First to Share

    Recommendations

    • Raspberry Pi Contest

      Raspberry Pi Contest
    • Anything Goes Contest 2021

      Anything Goes Contest 2021
    • One Board Contest

      One Board Contest

    3 Comments

    0
    TomD249
    TomD249

    Question 3 years ago on Introduction

    Can the sound sensor be replaced with a direct connection to the output?

    0
    rishabh8721
    rishabh8721

    Answer 3 years ago

    Hi Tom, I had made a circuit which takes input via AUX port and lit led strip sync with the music. I had used MSGEQ7 seven-band audio spectrum analyzer chip which you can order from aliexpress. Also, you can check

    full circuit and directions to make it. You can use an AUX splitter to give audio input to both i.e. your speakers and led circuit.

    0
    xprobes
    xprobes

    3 years ago

    well keep in mind e resistence ..... of the devices... must keep track to be in proper circuit
