Open Source Server Room Monitor




Introduction: Open Source Server Room Monitor

About: I have a few sites... Check them out.

This server room environmental monitoring system is a low cost high performance device with the same onboard features as commercial devices costing hundreds of dollars more. In addition to a low cost platform we will provide low cost sensors for many important devices to insure your equipment stays safe and sound.

Full instructions are available at as well as several kits to create some very unique projects.

Step 1: Stuff You Will Need...

You will need a few parts for this build as follows:

Sprout Board:
Arduino Duemilanove: Trossen Robotics
Ethernet shield:
Rack Mount Chassis:
LCD Screen:
Audio Board:
Temperature / Humidity Board:
Power Supply:

Odds and ends, screws, glue, tools, etc...

Step 2: Putting It Togeather

Step 1:
The assembly of the sprout board is very simple and requires very little experience with soldering. There are a few places where adding components can get cramped, but if you take your time it will be very easy.

Step 2:
Mount your arduino, ethernet shield and lcd screen

Step 3:
Glue the chassis togeather

Step 4:
Mount the board on the chassis

Step 3: Add Accessories

Next plug in any sensors you want to. I am using a temp/humidity and sound sensors.

Step 4: Load Software and Do a Happy Dance!

So all we need to do is load our software and do a Happy Dance!

Use this link so anyone can download the pde that will test the system. This also is an excellent framework to customize your application.

Step 5: How to Use It

Pin Assignments

Analog I/O:
Analog 0 - CCD Light Sensor (CDS1)
Analog 1 - Accessory Terminal Block 1 (TA1)
Analog 2 - Accessory Terminal Block 2 (TA2)
Analog 3 - Onboard Accessories Socket 1 (Temperature sensor on external board J9)
Analog 4 - Onboard Accessories Socket 1 (Humidity sensor on external board J9)
Analog 5 - Onboard Accessories Socket 2 (Sound J10)

Digital I/O:
Digital 0 - Not used
Digital 1 - Serial Terminal (TS1)
Digital 2 - Onboard Switch (SW1)
Digital 3 - Onboard Peizo Speaker (SP1)
Digital 4 - LED 1 (LED 1)
Digital 5 - LED 2 (LED 2)
Digital 6 - Accessory Terminal Block 1 (DA1)
Digital 7 - Accessory Terminal Block 2 (DA2)
Digital 8 - Accessory Terminal Block 3 (DA3)
Digital 9 - Accessory Terminal Block 4 (DA4)
Digital 10 - Reserved For Additional Shield (Ethernet shield pins correspond)
Digital 11 - Reserved For Additional Shield (Ethernet shield pins correspond)
Digital 12 - Reserved For Additional Shield (Ethernet shield pins correspond)
Digital 13 - Reserved For Additional Shield (Ethernet shield pins correspond)

CWe have provided 6 headers that can be used for expanding the capabilities of the sprout board to add additional sensors, input devices or control external devices. On the left side we have 2 analog terminals and on the right we have 4 Digital terminals. These terminals all have a set of three sockets that all use the same configuration of 5V+ on the left, I/O in the center and Ground on the right. In addition the two analog ports can simply be configured as digital I/O as needed with the arduino pinmode.

We have added these jumpers to our board to allow for very flexible connection of additional circuits through the accessory terminals. This configuration allows for you to setup a 2 wire button for input, have the option of both 5v and GND on an external device, or even ground your floating analog pins for more constant signals.

Serial Header
We have added a serial header on this board to allow you to connect a LCD screen with ease. As you can see in the picture here we have our 3 terminal block mounted at the end of the board. From left to right we have 5V+, TX, Ground. If you choose to use a spark fun Serial LCD display this allows for the simplest and most user friendly addition you could ever want.

More Info:
You can find lots of great info on how to use a sprout board, how to connect sensors or have it control devices at
