Introduction: PLC Programming WPLSoft & ISPSoft Simulator

By https://www.facebook.com/mohamed
About: Electrical engineer multitask & love self study.

#WPLSoft & #ISPSoft simulator steps

Supplies

#WPLSoft #ISPSoft #plc programming #simulator

Step 1: ISPSoft Simulator

ISPSoft simulator need to install COMMGR to run a simulator

1- open Commgr add driver (#DVP simulator) and start it follow image steps 1 to 5.

2 open ispsoft select communication settings from tools menu image step 6.

3 choose the driver name image step 7.

4 click on online mode then run step 8 then 9.



Step 2: WPLSoft Simulator

After programing you can simulate your program click on the below

simulator button 1 on image. to choose a simulator as a communication

Online mode button 2 on image. to start test and simulate your program

Step 3: WPLSoft Ladder Monitoring

to view the input output state you can select (ladder monitoring) or (stop ladder monitoring)

Step 4: WPLSoft Run Mode

to run the PLC and push an X0 input click the below

run button 3 on image. (put PlC ON Run Mode)

set on 4 on image. (active the input)

set off 5 on image. (de-active the input)
