Introduction: PVC Recorder

About: Will Bosworth, developing projects for HowToons @ SquidLabs.

Always wanted to make your own recorder? me too. check out this tasty musical instrument.
steps 1-7 = photo instructable
step 8 = video instructable

Step 1: Parts Layout

+The PVC Recorder uses 3/4" diameter, 1/16" wall PVC. Pipe length is variable. A foot length is a good place to start.

+ about an inch of 7/8" or 15/16" dowel rod.

+ a saw, a drill, a file, tinsnips.

Step 2: Piece 1, Pvc Jaws

cut a small length of pvc, about 1" long. Then use the snips and cut once along the length of pipe.

Step 3: Piece 2, Wood Stopper

cut a pice of dowel rod the same length as the pvc-jaws (piece 1)

Step 4: Piece 3, Pipe

with the longer piece of pvc, snip out a ~ .25" x 1.25" rectangle out of and end of the pipe. The length of the cut should be the length of the wood stopper + ~.25".

flatten out any hanging edges with a file.

Step 5: Assemble the Three Pieces. Debugging Tips.

put the woodstopper inside the end of the long pvc tube, on the side with the gap.

put the pvc-jaws over the end of the pvc with the woodstopper. Push the woodstopper and pvc-jaws around so that a proper gap is in place.

Blow into the recorder. It should sound like a recorder.



The recorder might not work on the first toot. If so, mess with the placement of the wood-stopper and pvc jaw on the long pipe - The air hole size is crucial for a working wind instrument. tinker and test!

Also, use a file to smooth (don't "round") the edges of the wood stopper and pvc. Smoother surfaces make for better air flow over the surfaces.

If the woodstopper is moving around too much inside the pvc tube, stick some duct tape on the stopper to widen the stopper.

in my experience, tinkering just to get sound shouldn't take more than a few minutes.

Step 6: Add Holes

drill some holes in the long pvc pipe to add notes to the pvc recorder. You can do alot of reading and measuring and get western notes, or you can drill haphazardly and get cool stuff.

Step 7: Play It!


Step 8: VIDEO HowTo


Be the First to Share

    Recommendations

    • Digital Fabrication Student Design Challenge

      Digital Fabrication Student Design Challenge
    • Colors of the Rainbow Contest

      Colors of the Rainbow Contest
    • Chocolate Challenge

      Chocolate Challenge

    31 Comments

    0
    kmm0931
    kmm0931

    9 years ago on Introduction

    I am a music appreciation teacher, and I brought this project to my classroom. It was awesome!! It cost under $20 for 45 students to do the project. We employed physics to understand how wind through a column creates sound, and used mathematical calculations to figure out where to drill the holes to get certain pitches. Thanks so much for an easy, "fool-proof" project that helped my students understand how science and math affect music! They loved it! Thanks!

    0
    Dill Jill
    Dill Jill

    Reply 2 years ago

    Hi do you remember what formulas you used to calculate the hole placements

    0
    kshission
    kshission

    8 years ago

    I am on my school's Science Olympiad team and I attempted to make this for the sounds of music event. I am having trouble getting a sound out of it though. Otherwise, your instructions were very helpful.

    0
    Dill Jill
    Dill Jill

    Reply 2 years ago

    lmao same thing here, do you remember how you found the correct lengths for western notes

    0
    stubbsonic
    stubbsonic

    9 years ago on Step 8

    I'm wondering if it would be possible to make a much larger version of this and create a very low bass sound. I imagine that the holes would probably not be easily worked out without a fair amount of trial & error. Perhaps a "slide whistle" type of approach to vary the length will work better.

    0
    sngai
    sngai

    Reply 8 years ago on Introduction

    See the instructable I just posted.

    0
    stubbsonic
    stubbsonic

    Reply 8 years ago on Introduction

    THANK YOU!!! That is really cool. I'm also very interested in the pipe organ you made. Thanks for thinking of me and posting this reply.

    Haha, I had an extra feet or 2 of PVC and found this Instructable, so I had my PVC and my Hack saw, and it turns out I have the EXACT SAME hack saw as you. I got it from Lowes, its pretty good for its size/price.

    0
    TheCheese9921
    TheCheese9921

    15 years ago

    HOW AM I SUPPOSED TO PLAY A RECORDER!!! lol Very cool Idea but there Is really no way to make sure the holes are in the right place to get the correct notes ****

    0
    Thinkenstein
    Thinkenstein

    Reply 11 years ago on Introduction

    What I usually do is make a few sacrificial flutes. If the holes you drill don't give you the right notes, cover them with tape and drill again near them until you get it right. Take the measurements from that and then do the final flute holes in an un-butchered piece of pipe. Once you get it right, you can make any number of copies following the same measurements, since the PVC pipe diameters are so uniform. That's one advantage of PVC over bamboo, say, every section of which is not uniform.

    0
    MrSalvador
    MrSalvador

    12 years ago on Step 8

    "You can do alot of reading and measuring and get western notes, or you can drill haphazardly and get cool stuff." Awesome instructable, cant wait to make it :D

    0
    Mr.NHRA
    Mr.NHRA

    13 years ago on Step 8

    I have made a pvc saxophone but i can't get any of the pitches. i have to cover all of the holes to make any sound can you help?

    0
    schaude
    schaude

    13 years ago on Introduction

    for a proper tuning you can also follow the instructions on this excellent site. there are several basic tunings possible depending on the overall measurement of the whistle. best wishes from rhine and moselle rivers!
