Introduction: RGB LED Moodlight in 10 Minutes!

Here is my 2nd. Instructable. A very quick one! ;-)

I will show you how to build a nice 3-RGB-LED mood light in nearly 10 minutes.

What did you need?

- battery powered LED touch-light
- slow rainbow effect RGB LEDs with slow automatic color cycling (or fast if you like ;-)
- small screw driver (depends on your LED touch-light)
- soldering-iron

Step 1: Look What Is Inside the Touch-light

First I remove the batteries from the bottom side of the lamp.

With my fingernails I can grip between the upper silver and the lower black part and simply lifting it up.
Then the rest of the parts dissolve them self. Really cheap build lamp ;-).

On the 3rd picture you can see the small PCB with 3 white LEDs and in the switch in the middle.

Step 2: Heat Up the Iron

Now you should remove the 3 LEDs with your soldering iron.

Then replace the three LEDs with the rainbow LEDs.
Don't forget that the long legs of the LEDs are the anode pins. They have to connect to the positive voltage.

Step 3: Test and Rebuild

Now insert the batteries for a quick test and then rebuild the parts.

If you like it you can place the semitransparent paper between the reflector and the glass for a smoother light.

If you switch the light on all 3 LEDs starting with the same color. But with the time they drift to different colors because of their tolerances.

Thats it. Have fun with it!

PS: don't forget to switch off the soldering iron ;-)

Be the First to Share

    Recommendations

    • Make it Glow Contest

      Make it Glow Contest
    • First Time Author Contest

      First Time Author Contest
    • PCB Challenge

      PCB Challenge

    31 Discussions

    0
    Pineapple_D
    Pineapple_D

    11 years ago on Step 3

    I know this sounds stupid but how do you change the colour? do you press it or what???

    0
    WattSekunde
    WattSekunde

    Reply 11 years ago on Introduction

    The LEDs are automatic colour changing LEDs. Each of them has 3 LED chips inside red, green, blue and a control circuit chip. (You can see these chips on the first picture with the macro shot of one of those LEDs. under the lens you see the control chip and on the lower side you see the three LEDs. Thank you for your interest.

    0
    mnc
    mnc

    Reply 11 years ago on Step 3

    there is different kind of leds changes colour according to:
    • depends on time, (changes by it self)
    • electric way if you swap + and - it changes colour
    • according to watt/volt im not sure.
    0
    MilotisX
    MilotisX

    Reply 11 years ago on Introduction

    hey do you know the name of the second type you mentioned??

    0
    mnc
    mnc

    Reply 11 years ago on Introduction

    sorry I don't know, try to asking "low power colour changing led" or "two colour led"

    0
    cokecola
    cokecola

    10 years ago on Introduction

    The first image looks real cool, is that just a drinking glass over the top of the lite?

    0
    Dryank04
    Dryank04

    11 years ago on Introduction

    so is there a difference between a RGB slow flash LED and a RGB color cycling (slow)? i cant find one that says color cycling they all tend to say 'flash' but flash makes me think it wouldn't be a smooth transition to the other colors.

    0
    Questioneverything13
    Questioneverything13

    Reply 11 years ago on Introduction

    I got some slow flash rgb leds from ebay and they fade slowly from one colour to the next but the fast flash rgb leds I got at the same time flash real fast from one colour to the next and just give you a headache. Sureelectronics sell them in lots of 100 with 100 X 470ohm and 100 X 100ohm resistors but that is a lot of leds.

    0
    abbtech
    abbtech

    Reply 11 years ago on Introduction

    You can get them individually here (on sale right now also).
    http://alan-parekh.vstore.ca/product_info.php/products_id/88

    There is a video that demonstrates the RGB LED color cycling, fast flash and slow cycle in one device.

    0
    johnny q
    johnny q

    12 years ago on Introduction

    where do you get the touch light that you are starting with ? What type of store would sell one ? The raw light itself looks really neat, kinda like a crystal ball. I haven't tried any projects from here, but this one could be the first. I sure like it.

    0
    WattSekunde
    WattSekunde

    Reply 12 years ago on Introduction

    I found them in a "Baumarkt" here in Germany. Very cheap no name 3-Pack. You can buy similar from Amazon, etc. Search for Tap Lights. Thank you!

    0
    woodswalker
    woodswalker

    12 years ago on Step 2

    I'd like to build a small LED art piece from scratch using the drawing above. What voltage of battery are you using? (with no resistors I'm guessing it's 4.5?)

    0
    WattSekunde
    WattSekunde

    Reply 12 years ago on Introduction

    Yes, the lamp has 3x1.5V battery inside. But there is a resistor on the PCB. You can see only the shadow of it in the upper right side on the picture in step 3. The resistor has 10 Ohm and connects the red cable with the middle pin of the switch. Thank you for your interest.

    0
    didibemi
    didibemi

    12 years ago on Introduction

    really nice but i think you can buy that rings or others that have this device. they're cheaper. aushuashuashasuhash

    0
    prototype27
    prototype27

    12 years ago on Step 3

    Very cool! I actually use these all over the place as accent lights, but instead of diffusing with paper under the lens I just scuff it up a bit with sandpaper. Good job.
