Raspberry Pi Multi-Room Audio (Mobile/Tablet/PC Controlled) : 7 Steps (with Pictures)

I have been lurking on Instructables for a few years but have never posted one myself. Now I have bought a home of my own it's time to undergo some projects and share them with the community.

In my first project I'm going to show you how I setup multi-room audio that can be controlled by any device with a web browser or an app on your Android and/or iOS device.

I apologise for the lack of/poor quality photos.

I have borrowed some of this information and thrown in some things from my own experience. Some credit goes to the author of this tutorial http://www.raspberrypi.org/phpBB3/viewtopic.php?f=38&t=25778
To tackle this instructable you should have an understanding of networking, intermediate to expert computer skills and maybe some linux experience too. If you run into something you don't understand just remember google is your friend.

Equipment you will need

• Computer (mac/win/linux to act as your Logitech Media Server)
• Home network (wireless if you can't run a cable to the Pi)
• Raspberry Pi (I've used 1 per room however I will add a multi-DAC tutorial once I complete it myself)
• SD card 2GB or larger
• AC Adaptor (I used a USB wall charger for mobile phones check here http://elinux.org/RPi_VerifiedPeripherals#Power_adapters)
• Micro USB cable
• USB wireless adaptor (MAKE SURE IT IS COMPATIBLE OUT OF THE BOX! http://elinux.org/RPi_USB_Wi-Fi_Adapters)
• Powered USB Hub (for extra usb devices or multi DAC at a later date)
• HDMI cable or HDMI to DVI cable (depending on your monitor)
• DAC (digital to analogue converter, 1 per room)
• Amplifier (unless your DAC is also amplified)
• Speakers

Step 1: Logitech Media Server

First of all we need to setup your Logitech account and install the Logitech Media Server on the computer contains your music collection. This computer should always be on when you want to play music. The LMS and instructions can be found at http://www.mysqueezebox.com/download

Once installed setup your library

Also login to your squeezebox account otherwise you cannot see your music on the player.

You can also download the Squeezebox app for your iOS or Android device also remember to login to your Logitech account inside the app.
https://play.google.com/store/apps/details?id=com.logitech.squeezeboxremote&hl=en
https://itunes.apple.com/au/app/logitech-squeezebox-controller/id431302899?mt=8

Step 2: Raspberry Pi Setup

Now we'll setup the Raspberry Pi, to do this you'll need to have Raspbian installed. You can buy a Pi with Raspbian pre-installed or you can use a 2GB or larger SD card that you already have.

I am using an SD card I already have. Plug the SD card into your computer and download the latest Raspbian http://downloads.raspberrypi.org/raspbian_latest

I'm using windows so I unzipped the file and used win32diskimager (http://sourceforge.net/projects/win32diskimager) to write the Raspbian image to the SD card.

If you are still not sure there is a tutorial here http://elinux.org/RPi_Easy_SD_Card_Setup

Ok now we have Raspbian installed it's time to get our Pi up and running, plug in your SD card, Wi-Fi dongle, USB keyboard, Ethernet cable to your router, HDMI to your monitor and lastly the micro USB cable to the power socket. The first time you boot up you'll end up with the configuration tool on the screen.

Things you need to change are:
• Expand the filesystem so Raspbian utilises the entire SD card
• Change your password
• Set your language, region and time zone

Now the advanced options:
• Change your hostname so you can recognise your Pi on the network.
• Enable SSH so you can access your PI from a computer on your network.
• Select finish which might restart your Pi.

If you are in the US or Australia like me you will want to change the keyboard layout to US.
To do this you’ll need to change a file entering the command:

_{sudo nano /etc/default/keyboard}

Use the arrow keys to move the cursor and change the gb to us.
Now save the file by pressing ctrl + X and Y to save changes

Now to update your Pi, type the following commands:

_{sudo apt-get update
sudo apt-get upgrade}

Press y to download larger updates.

Step 3: Wi-Fi

If you just want to use Ethernet you can skip this step.

To get your Wi-Fi dongle working you may need to edit the wpa_supplicant.conf file by typing

_{sudo nano /etc/wpa_supplicant/wpa_supplicant.conf}

Then make it look like this:

ctrl_interface=/var/run/wpa_supplicant
network={
    proto=RSN
    scan_ssid=1
    key_mgmt=WPA-PSK
    pairwise=CCMP TKIP
    group=CCMP TKIP
    ssid="your network ID in quote marks"
    psk="your network password in quote marks"
}

To save the file press ctrl + x and Y to save

Restart the Pi by entering:

_{Sudo reboot}

You should be able to see if your Wi-Fi dongle has an IP address with the command

_{Sudo ifconfig}

You should get something like this

wlan0     Link encap:Ethernet HWaddr 64:66:b3:06:43:1b
          inet addr:10.0.0.75 Bcast:10.0.0.255 Mask:255.255.255.0
          UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
          RX packets:912384 errors:0 dropped:121692 overruns:0 frame:0
          TX packets:706463 errors:0 dropped:0 overruns:0 carrier:0
          collisions:0 txqueuelen:1000
          RX bytes:694114055 (661.9 MiB) TX bytes:71017681 (67.7 MiB)

Step 4: Static IP and SSH

Next I usually give my Pi a static IP by adjusting the LAN settings on my router.
Giving your Pi a static IP address makes it easier to remember the address when we connect via SSH.

I am not going into this because every router is different.
I suggest using google to search for “your routers model number” static IP.

Now the network is up and running either wired or wireless I like to use a SSH client like PuTTY to control the Pi.
That way I can copy and paste code if I’m feeling too lazy to type it out.
To copy use ctrl + c as usual but to paste into PuTTY click the right mouse button.
This will also free up a USB port for your DAC if you are using a USB Wi-Fi adaptor.
Download and run PuTTY then type in the IP address of your Pi and press open.

Login as pi and the password is whatever you changed it to in the initial setup.

Step 5: Audio Setup

Now we can check if the DAC is recognised and set the volume. Enter the command

_{sudo alsamixer}

Now press F6 to select your DAC and use the up arrow to set the volume to maximum.

Now press Esc to exit and use the following command to save your changes

_{sudo alsactl store}

We’ll need to install some extra sound libraries to play different music formats

_{sudo apt-get install libfaad2
sudo apt-get install libflac-dev}

Step 6: Installing Squeezelite

The next step is to install Squeezelite on the Pi so we’ll create a squeezelite "work" directory

_{mkdir squeezelite
cd squeezelite}

Now get squeezelite:

_{wget http://squeezelite.googlecode.com/files/squeezelite-armv6hf}

Move it to the usr directory, and make it executable:

_{sudo mv squeezelite-armv6hf /usr/bin
cd /usr/bin
sudo chmod u+x squeezelite-armv6hf}

Because I am using a USB DAC, I had to tell squeezelite which sound device to use.
First list all the devices:

_{squeezelite-armv6hf -l}

The result:
_{Output devices:
null                           - Discard all samples (playback) or generate zero samples (capture)
default:CARD=ALSA              - bcm2835 ALSA, bcm2835 ALSA - Default Audio Device
sysdefault:CARD=ALSA           - bcm2835 ALSA, bcm2835 ALSA - Default Audio Device
default:CARD=DAC               - USB Audio DAC, USB Audio - Default Audio Device
sysdefault:CARD=DAC            - USB Audio DAC, USB Audio - Default Audio Device
front:CARD=DAC,DEV=0           - USB Audio DAC, USB Audio - Front speakers
surround40:CARD=DAC,DEV=0      - USB Audio DAC, USB Audio - 4.0 Surround output to Front and Rear speakers
surround41:CARD=DAC,DEV=0      - USB Audio DAC, USB Audio - 4.1 Surround output to Front, Rear and Subwoofer speakers
surround50:CARD=DAC,DEV=0      - USB Audio DAC, USB Audio - 5.0 Surround output to Front, Center and Rear speakers
surround51:CARD=DAC,DEV=0      - USB Audio DAC, USB Audio - 5.1 Surround output to Front, Center, Rear and Subwoofer speakers
surround71:CARD=DAC,DEV=0      - USB Audio DAC, USB Audio - 7.1 Surround output to Front, Center, Side, Rear and Woofer speakers
iec958:CARD=DAC,DEV=0          - USB Audio DAC, USB Audio - IEC958 (S/PDIF) Digital Audio Output}

I wanted to use only the front speakers, so I have to tell squeezelite to use "front:CARD=DAC,DEV=0".

Now to start Squeezelite enter

_{./squeezelite-armv6hf -o front:CARD=DAC,DEV=0}

At this point you should be able to see the player on your Logitech Media Server or Squeezebox App, woo hoo you did it!!!

Step 7: Run on Startup

Next we need to make sure Squeezelite runs on startup
I have borrowed the daemon start script to start Squeezelite from another tutorial, so use at your own risk!

Follow these commands to automate startup:

_{cd /home/pi/squeezelite
sudo wget http://www.gerrelt.nl/RaspberryPi/squeezelitehf.sh
sudo mv squeezelitehf.sh /etc/init.d/squeezelite
cd /etc/init.d
sudo chmod u+x squeezelite
sudo update-rc.d squeezelite defaults}

You will need to change a few lines to make sure it works properly and you know what room it’s in.

_{sudo nano squeezelite}

Search for "SL_NAME", you will find this line:
SL_NAME="Framboos"
Change the word "Framboos" to whatever you like, I’ve used Lounge on one and Outdoor on the other.

You need set the soundcard here too.
Search for this line
SL_SOUNDCARD="sysdefault:CARD=Set"
Change "sysdefault:CARD=Set" to the one you selected earlier (in my case I changed it to " front:CARD=DAC,DEV=0").

If you are using multiple players you will need to make sure the MAC address is different on each player. To do this uncomment (remove hash/pound sign) the line
#SL_MAC_ADDRESS="00:00:00:00:00:01"
I have used
SL_MAC_ADDRESS="01:01:01:01:01:01” for my lounge player
SL_MAC_ADDRESS="02:02:02:02:02:02” for my outdoor player

Save and close the script file by pressing ctrl + x and then Y to save.

This is how you test the script:

_{sudo ./squeezelite start}

The command prompt should return immediately. Now check if the squeezelite process is up:

_{ps -A |grep squeeze}

It should return something like this (the number will be different):

_{2324 ? 00:00:01 squeezelite-arm}

To stop squeezelite:

_{sudo ./squeezelite stop}

And that's it, if you reboot the pi

_{sudo reboot}

squeezelite should be started automatically.

Repeat steps 1 through 7 for any additional players.
