Introduction: Road Bike Shift Indicator Using Scrap Packaging

By

I really don't like to cross-chain. It's never been a problem before, since I've always had a pretty good sense of what rear cog I'm in. But when I got a bike with a compact double after riding 12 years with a triple, it seems like I'm shifting the front so often that now it's hard to keep track of things. So I made a shift indicator using scrap plastic that's kind of inconspicuous, and you don't need to remove the cable to install it.

Warning - if you get frustrated fiddling around with small things until they're just right, don't even start this project. And, I'm the only one who ever handles my bike, so the fact that it's a bit fragile isn't a problem for me.

Step 1: What You'll Need

No, not the toothbrush - the toothbrush package (or whatever other small piece of clear plastic you can find). I used the toothbrush package because the right-angle bend was already formed permanently into it.

And a bit of duct tape, which I forgot to put in the picture.

Step 2: The Pointer

Shift into the biggest cog and pick a spot on the cable where you'll be able to see the pointer when you look down. It's going to move away from the fork as you change gears.
You need something that will attach securely enough to the cable, and be visible enough to see through the window. A piece of duct tape works well. Cut it about 1/4" wide and 1-1/2" long and wrap it tightly around the cable. Tweezers are helpful.

Step 3: The Window

Cut the window from the toothbrush package.
The window needs to be about 1-1/2" long, and wide enough to go out from the frame about 1/8" past the cable.
Stick it onto the down tube with double stick tape, referring to the pointer to position it.

Step 4: The Scale

I don't want an indicator line for every cog - I just want to know when I'm on the 2 smallest or 2 biggest cogs so I can avoid cross-chaining. Cut a thin strip of black electrical tape for each limit line and stick it on the top surface of the window. How did I come up with those angles? You want the lines to look horizontal (perpendicular to the cable) when you're looking down on them while riding. This is where you'll need to do some experimenting to find the right positions. Place the tape strips so that the pointer doesn't cross the lines until you've gone to the next-to-outside cog on each side.

Step 5: This Is About How It Looks When You're Riding.

It's on the third-smallest cog here.
