Introduction: Wireless Robo-car Using 360° Servo Motor
smart car robot using 360 Degree continuous rotation servo motor.
Step 1: Components
Step 2: Making Steps
Step 3: Prototype
Step 4: Wireless Communication System -zigbee
Step 5: Program
#include <Servo.h>
///////////////////////////// KEYS /////////////////////////////
#define FWD_KEY 'W'
#define BWD_KEY 'S'
#define QUICK_L_KEY 'Q'
#define QUICK_R_KEY 'E'
#define TRNL_L_KEY 'A'
#define TRNL_R_KEY 'D'
#define STOP_KEY ' '
#define KEY_DLY 200
///////////////////////////////////////////////////////////////////
#define STOP_L 95
#define STOP_R 95
#define FWD_L 0
#define FWD_R 360
#define BWD_L 180
#define BWD_R 0
#define QTRNL_L STOP_L+5
#define QTRNL_R FWD_R
#define QTRNR_L FWD_L
#define QTRNR_R STOP_R-5
#define TRNL_L STOP_L
#define TRNL_R FWD_R
#define TRNR_L FWD_L
#define TRNR_R STOP_R
/////////////////////////////////////////////////////////////////////
Servo left_servo,right_servo; // create servo object to control a servo
unsigned char incomingByte=0;
unsigned int count=0;
int potpin = 0; // analog pin used to connect the potentiometer
int val; // variable to read the value from the analog pin
void setup()
{
Serial.begin(9600);
left_servo.attach(2); // attaches the servo on pin 9 to the servo object
right_servo.attach(3); // attaches the servo on pin 10 to the servo object
left_servo.write(STOP_L);
right_servo.write(STOP_R);
}
void loop()
{
if(Serial.available() > 0)
{
incomingByte =Serial.read();
}
if(incomingByte==FWD_KEY)
{
left_servo.write(FWD_L);
right_servo.write(FWD_R);
incomingByte='X';
count=0;
}
else if(incomingByte==BWD_KEY)
{
left_servo.write(BWD_L);
right_servo.write(BWD_R);
incomingByte='X';
count=0;
}
else if(incomingByte==QUICK_L_KEY)
{
left_servo.write(QTRNL_L);
right_servo.write(QTRNL_R);
incomingByte='X';
count=0;
}
else if(incomingByte==QUICK_R_KEY)
{
left_servo.write(QTRNR_L);
right_servo.write(QTRNR_L);
incomingByte='X';
count=0;
}
else if(incomingByte==TRNL_L_KEY)
{
left_servo.write(TRNL_L);
right_servo.write(TRNL_R);
incomingByte='X';
count=0;
}
else if(incomingByte==TRNL_R_KEY)
{
left_servo.write(TRNR_L);
right_servo.write(TRNR_R);
incomingByte='X';
count=0;
}
else if(incomingByte==STOP_KEY)
{
left_servo.write(STOP_L);
right_servo.write(STOP_R);
incomingByte=0;
count=0;
}
else if(incomingByte=='X')
{
if(++count>KEY_DLY)
{
left_servo.write(STOP_L);
right_servo.write(STOP_R);
count=0; incomingByte=0;
}
delay(1);
}
}
