Introduction: Sega Master System FM Modification
In this instructable set, I will detail the stages of installing the FM sound board onto your Sega Master System pcb.
The things you will need for the job:
- FM sound board kit - I got mine from the source itself, Tim Worthington at http://etim.net.au/shop/shop.php?crn=202
- Wire splicer
- Soldering iron
- Solder (solder flux is also recommended)
- Solder pump
- Dremel or any type of tool for metal cutting and hole drilling
The job will require basic soldering skill. be sure you know how to hold a soldering iron and use it.
Step 1: The Kit Preparation
The new kit is more DIY than the old one in terms of you will need to solder the black pin connector to the PCB by yourself (the idea is to use smaller envelopes and save some money on shipping).
The kit consists of the PCB itself, a black pin connector (female), a toggle switch and a switch wire harness.
First of all, prepare your kit for the implementation:
Place the black female connector alligned with the holes on your PCB. Solder the tips of the female connector to the PCB (the usage of solder flux is recommended).
Step 2: Prepare the Connection Wire
Splice the wire and reviel the red, white and GND leads.
Step 3: Opening You Master System
Basically open all the screws to enable the Master System PCB removal from the case.
Step 4: Locate C49 Capacitor
Locate the C49 capacitor on your board. I got to see it after I've removed the metal heat sink that was attached to the voltage regulator.
Please note that the C49 is the component to be replaced on my NTSC Master System. If you got other version of Sega Master System, reffer to http://etim.net.au/smsfm/smsfm.html
Step 5: Remove C49 Capacitor
I've used a solder sucktion pump to clear all the solder from it's legs and removed it.
Step 6: Placing the Wire Leads
Place the white and red as described in the pic. the GND will be soldered to the metal case of the RF module.
Step 7: Fitting the Metal Shield to the FM PCB
Since the FM PCB sticks out, a modification for the metal sheild needs to be done.
I've used the Dremel multi tool for the job.
Step 8: Make a Hole for the Switch
The hole should be drilled on the right area of the upper case.
