Introduction: Servo Tutorial

Using an Arduino to control a servo motor with the use of two pushbuttons.

Step 1: Get the Appropriate Components

Please use the links provided if you need any of the components also check out the site for other great arduino goodies, they ship worldwide for free and there service is great. Plus you support me :)

Go to the site here.

Thanks for your support.

1) Arduino Link: Arduino Compatible Uno R3 Rev3 Development Board

2) Breadboard Link: Half-size 400-Pin Electronics DIY Breadboard or 830-Point Solderless Electronics DIY Breadboard

3) Push Buttons Link: DIP P4 Sqaure Switch Push Buttons (100-Pack)

4) Jumper Cables Link: Multicolored 40-Pin DuPont Breadboard Jumper Wires (20cm)

5) Two 10k Ohm Resistors Link: DIY Universal 1/4W 1% Metal Film Resistor (600PCS)

6) Servo Motor Link: Tower Pro SG90 9g Gear Steering Servo

Step 2: Connect the Power

Connect the GND and 5V

Step 3: Connect the Servo

Red to 5V

Brown/Black to GND

Orange to pin 9

Step 4: Connect the Buttons

One of the buttons to DIGITAL 2

The other to DIGITAL 4

Step 5: Check the Circuit

Make sure the circuit is correct

Step 6: The Code

I used the Sweep example from Arduino and altered it to work.

#include <Servo.h>

const int buttonPin = 2;

const int buttonPin2 = 5;

int buttonState = 0;

int buttonState2 = 0;

Servo servoA;

int position = 0;

void setup() {

servoA.attach(9);

pinMode(buttonPin, INPUT);

pinMode(buttonPin2,INPUT);

}

void loop() {

buttonState = digitalRead(buttonPin);

buttonState2 = digitalRead(buttonPin2);

if(buttonState ==HIGH && position < 180){

servoA.write(position++);

delay(5);

}

if(buttonState2 == HIGH && position > 3){

servoA.write(position--);

delay(5);

}

}

Step 7: Complete

2 People Made This Project!

Recommendations

  • Make it Glow Contest

    Make it Glow Contest
  • First Time Author Contest

    First Time Author Contest
  • PCB Challenge

    PCB Challenge

35 Discussions

0
ElliottWest25
ElliottWest25

3 years ago

I tried to get the code to work, but i keep getting this error:

"error compiling for board Arduino/genuino uno."

so I need some help on how to fix this. thanks!

0
Steve1062840
Steve1062840

Reply 1 year ago

Hi, this is a late reply, but if you have not found the solution here it is:
You should just change the "servo" in the #include to "Servo".
Good luck!

0
gavinkeeley
gavinkeeley

Reply 7 months ago

Thanks Steve1062840,
That include line has caused me a lot of hassle... Something to do with Instructables text to html conversion in its editor. I've gone in to the HTML now and edited it. Hope it's all good now.
Gavin

0
nkar9
nkar9

Question 1 year ago

Hello, when I press the pushbutton, it doesn't move the servo. I have already checked my wiring and I checked my code. What do you think it could be?

0
lazaroracingl
lazaroracingl

2 years ago

Hi everyone, I have a servo motor project and I would like some help, I'll see if I can explain;
- 2 servos, - 2 puch buttom; I want to control one of the servants and the other servant is controlled by the first one through the angle
I'll give you an example (when pressing the buttom the servo walks from ¨0 to 50¨ degrees after reaching the 50 degrees the other walks from ¨0 to 30¨ degrees when reaching the 30 degrees
when I reach 30 degrees the first servo continues from where it stopped and goes from ¨50 to 99¨ degrees I thank the help

0
gavinkeeley
gavinkeeley

Reply 2 years ago

Hi lazaroracingl,

What you are describing should be easy enough to achieve with a series of if and else if statements.

Something like the following should work (I haven't tested this code),

if(buttonState == HIGH){

if(position1 < 50){ //first stage

position1++;

}else if(position2 < 30 && position1 == 50){ //second stage

position2++;

}else if(postion2 == 30 && position1 < 99){ //third stage

position1++;

}

}

servoOne.write(position1);

servoTwo.write(position2);

delay(5);

Obviously, you'll have to fill in the missing code parts.

Good luck,

Gavin.

0
UlisesC17
UlisesC17

3 years ago

everything works excellent! Do you have any code to move 3 or more servos? Thank you!

0
gavinkeeley
gavinkeeley

Reply 2 years ago

Hi UlisesC17,

Sorry for the delayed response, I don't have access to three servos but I would imagine you just define more and more servos...

E.g.

Servo servoA;

Servo servoB;

...

Servo servoN;

Then later on in the code you will have to attach them to different pins

E.g

servoA.attach(9);

servoB.attach(10);

You will also have to declare variables to keep track of the individual positions etc.

Goodluck...

Regards

Gavin

0
AndreșC176
AndreșC176

3 years ago

My servo keeps rotating back to a some kind of initial position..any ideas why?

0
ElliottWest25
ElliottWest25

3 years ago

figured it out, i had to capitalize the S at the beginning

0
ElliottWest25
ElliottWest25

3 years ago

also, here's the entire message.

Arduino: 1.8.5 (Windows Store 1.8.10.0) (Windows 10), Board: "Arduino/Genuino Uno"

C:\Users\smell\Documents\Arduino\sketch_oct25a\sketch_oct25a.ino:1:19: fatal error: servo.h: No such file or directory

#include <servo.h>

^

compilation terminated.

exit status 1

Error compiling for board Arduino/Genuino Uno.

This report would have more information with

"Show verbose output during compilation"

option enabled in File -> Preferences.

0
chupo_cro
chupo_cro

3 years ago

In the first picture under the heading 'Step 5: Check the Circuit' the white wire is at the 6th position from the right, isn't that DIGITAL 5?

0
gavinkeeley
gavinkeeley

Reply 3 years ago

Hi Chupo_cro,


It does look that way in the photo, I have made the change in the code.

It doesn't really matter, you could make it anyone of the digital pins... Just change the number in the code accordingly.

Thanks for pointing this out.

Regards
Gavin

0
AmmarD2
AmmarD2

3 years ago

I am using a modified servo motor(TowerPro MG995) which allow me to rotate continuously. are this set up and codes still relevant for this servo? If not, what is the alternative? thx in advance

0
gavinkeeley
gavinkeeley

Reply 3 years ago

Hi Ammar, unfortunately the code will not work with a continuous rotation servo and there is no simple change to the code that will rectify it...

The following link discusses the topic in more depth.
https://forum.arduino.cc/index.php?topic=267166.0

Unfortunately I do not have a continuous rotation servo to figure it out with.

Regards
Gavin

0
TeresoM
TeresoM

3 years ago

Dear, Gavin, thanks for sharing. I have one doubt, however: what is the function of the "int position=0;" line?

Kind regards!

0
gavinkeeley
gavinkeeley

Reply 3 years ago

Hi TeresoM,

The function of that line is to set the position integer to zero. If you look further down in the code we set the servos position to that integer. So 0 will be the most it can go in the one direction and 180 will be the most it can go in the other. We then increase/decrease the value of this integer depending on which button is being pressed.

Sorry for the untimely response.

Regards

Gavin

0
ghorgex
ghorgex

4 years ago

Seems the servo runs too fast, how to reduce it?

0
gavinkeeley
gavinkeeley

Reply 3 years ago

Hi ghorgex,

To reduce the speed at which the servo rotates you can increase the value in the delay functions. i.e. Increase delay(5); to say delay(10); this will effectively halve the rotation speed.

Regards

Gavin

0
biddlejimmy
biddlejimmy

4 years ago

The code on this page will not verify. Get High was not declared in this scope. Can you help???
