Introduction: Smart Bike Motion Light and Display Using Blynk

Flashy LED decor lights that respond to your bike's motion. cable by foot
Once every month I ride with "Critical Mass" cycling group of 300+ riders roaming city at night. I want to pimp up my bicycle with unique colorful lights that react to how I ride for safety and attention.

Supplies

COMPONENTS AND SUPPLIES

Arduino 101 & Genuino 101 × 1
RobotGeek Relay × 1
Mfr 25frf52 10k sml
Resistor 10k ohm × 3
Omron b3f 1000 image 75px
SparkFun Pushbutton switch 12mm × 1
Neopixel strip
Openbuilds wire cable by foot
OpenBuilds Wire Cable - By the Foot

Step 1: APPS

1. BLYNK
2.Arduino IDE

Step 2: What It Does


Interactive bike motion lights controller and display

Colorful LED patterns flashes and scrolls responds to bikes motion
Color change over vibrating bumpy road. Waving and turning. Accelerating and braking.
Control light patterns using smartphone over Bluetooth. Display speed / distance Speedometer and tachometer display.
Tracking distance traveled / health exercise counter.
Safety night riding with added breaking light effect and headlights.

Step 3: How I Built It

Parts:

Arduino 101
push button
magnets
Reed switch
LCD display
LED
addressable LED lights strips
Relay
5V DC regulator
High power LED lights

Step 4: Operation (see Wiring Diagram):


Reed switch to count tire rotation to determine speed, distance and light effect.
Build in gyro and accelerator in Arduino 101 triggered light effect.
Break switch to trigger all strip lights to bright red to warn trailing motorists.
Using phone running Blynk GUI App connected to Arduino as optional display and controller.
App displays Speed graph, distance. Allow color and light effect selection.

Step 5: Break Switch Wiring

: I wired a continuous close circuit loop that when a break in the handle bar will break the circuit. Interrupt will trigger all strip lights to red to warn tailing riders.

Step 6: Reed Switch Wiring

I used the home security reed switch tied to the front wheel frame. Magnets secured to the wheel spool with groove cut into corners and sealed with duct tape.

Headlight Relay: Used a relay for powering the 12V high white LED head lights. Physical switch should suffice. But I want to control it via phone Arduino for other power devices. Such as musical horn.

Step 7: LED Light Strip Mounting:

To spread colored LED lights more evenly. I mounted the colored led strip under the bike central bar and wrap acrylic tube to spread lights. I used angled tube plastic cover leftover from windshield wiper blade packaging. The thin angled acrylic cover reflects the LED lights like mirror and creates illusion of multiple strips of light from a single strip, - a nice surprising effect.

Wire all switches to a wire harness and connected to the Arduino with the per-tested prototype.

Step 8: Blynk GUI APP:

Blynk GUI APP: Download Blynk app. Scan the QR code to obtain the Bike LED Display GUI. Press Bluetooth button.

Select Bike Display. Wait for Bluetooth connection.
Press back button to return to interface after establish BLE connection to Arduino.
Press Play button on upper right corner.
Wait for Speed and graph to update.
View, control color and light effects with the GUI app.

Step 9: Code

#include
#include
#include


#define DEBUG 1

#define NUM_LEDS 75 // Set to number of addressable RGB leds present

#define LED_DATAPIN 6
#define HEADLIGHT_PIN 8


//Comment out if not using BLYNK BLE display control app
#define USE_BLYNK_GUI_APP 1

// comment out following line if lcd display is not used
#define lcd_display 1

#ifdef lcd_display
#include
#include "rgb_lcd.h"
rgb_lcd lcd;
#endif

Adafruit_NeoPixel leds = Adafruit_NeoPixel(NUM_LEDS, LED_DATAPIN);
int InterframeDelay = 1; //ms

BLEPeripheral blePeripheral; // create peripheral instance

uint32_t BaseLedColor;
uint8_t ColorEffect = 0; // 0-9 shows different patterns. Default to 0 using Interactive display


//Blync Authentication Token
char auth[] = "8aca3456abe24c69ae883cf299b32128";
unsigned long gSPEED_VAL = 0;
float gSPEED_KPH = 0;
float gDISTANCE = 0;

#ifdef lcd_display
void printLCD( float velocity, float distance ) {
String outputMsg;
lcd.setCursor(0,0);
outputMsg = "SPEED: ";
outputMsg += String(velocity);
outputMsg += (" km ");
outputMsg += "\0";
lcd.print(outputMsg);

outputMsg = "DIST : ";
outputMsg += String(distance);
outputMsg += (" km ");
outputMsg += "\0";
lcd.setCursor(0,1);
lcd.print(outputMsg);
}

void turnOnRed(bool on) {
if (on)
lcd.setRGB(100,0,0);
else
lcd.setRGB(30,30,30);
}

void turnOnGreen(bool on) {
if (on)
lcd.setRGB(0,100,0);
else
lcd.setRGB(30,30,30);
}
#endif


void setup()
{
// Clear LEDs
LedSetup();
SpeedSetup();
OrientationSetup();

#ifdef lcd_display
lcd.begin(16, 2);
lcd.print("BIke LED");

lcd.setCursor(0,1);
lcd.print("Display ");
lcd.setRGB(100, 100, 100);
#endif

// Open serial port and tell the controller we're ready.
Serial.begin(9600);

pinMode(HEADLIGHT_PIN, OUTPUT); // use the LED on pin 13 as an output

#ifdef USE_BLYNK_GUI_APP
// set the local name peripheral advertises
blePeripheral.setLocalName("BikeDisplay");
blePeripheral.setDeviceName("BikeDisplay");
blePeripheral.setAppearance(384);

Blynk.begin(blePeripheral, auth);

// advertise the service
blePeripheral.begin();
Serial.println(("Bluetooth device active, waiting for connections..."));

#endif
}

void loop()
{
blePeripheral.poll();
Blynk.run();

// Read a command
SpeedLoop();

#ifdef lcd_display
printLCD(gSPEED_KPH, gDISTANCE);
#endif

if (ColorEffect > 0) {
ChangeColorEffect(ColorEffect);
} else {
MotionSensingLoop();
LedLoop();
}
}

#ifdef USE_BLYNK_GUI_APP
// Blynk library GUI communication code

BLYNK_CONNECTED() {
Blynk.syncAll();
#ifdef lcd_display
lcd.begin(0, 2);
lcd.print("GUI connected");
lcd.setRGB(0, 0, 100);
#endif
}

// Update speed to speed Widget
BLYNK_READ(V0) {
float speed_kmph = gSPEED_VAL;
Blynk.virtualWrite(V0, speed_kmph);
}

BLYNK_READ(V1) {
Blynk.virtualWrite(V1, gSPEED_VAL);
// Serial.println("=1=");
}

// turn Headlight Relay On / Off
BLYNK_READ(V2) {
bool lightOn = (digitalRead(HEADLIGHT_PIN) == HIGH);
// Toggle light
digitalWrite(HEADLIGHT_PIN,lightOn?HIGH:LOW);
}

//Read syle slider value
BLYNK_WRITE(V3) {
gSPEED_VAL = param.asInt();
Serial.print("= ");
Serial.println(gSPEED_VAL);

}

//Read syle slider value
BLYNK_WRITE(V4) {
int effectNum = param.asInt();
Serial.print("Effect ");
Serial.println(effectNum);
ChangeColorEffect(effectNum);
}


BLYNK_WRITE(V5) {
int r = param[0].asInt(); // get a RED channel value
int g = param[1].asInt(); // get a GREEN channel value
int b = param[2].asInt(); // get a BLUE channel value
if (DEBUG) {
Serial.println("RGB ");
Serial.print(r);
Serial.print(g);
Serial.print(b);
}
#ifdef lcd_display
lcd.setRGB(r,g,b);
#endif
BaseLedColor = leds.Color(r,g,b);
ColorEffect = 4;
}

#endif


/*************************************************************
Download latest Blynk library here:
https://github.com/blynkkk/blynk-library/releases/latest
Blynk is a platform with iOS and Android apps to control
Arduino, Raspberry Pi and the likes over the Internet.
You can easily build graphic interfaces for all your
projects by simply dragging and dropping widgets.
Downloads, docs, tutorials: http://www.blynk.cc
Sketch generator: http://examples.blynk.cc
Blynk community: http://community.blynk.cc
Social networks: https://www.fb.com/blynkapp
http://twitter.com/blynk_app
Blynk library is licensed under MIT license
This example code is in public domain.
*************************************************************
Note: This requires CurieBLE library

Warning: Bluetooth support is in beta!
*************************************************************/

Step 10: End
