Solar Powered Charger for 18650 Lithium Ion Cells

Introduction: Solar Powered Charger for 18650 Lithium Ion Cells

Charging Lithium Ion batteries is a tricky affair and too with solar power because Lithium-ion batteries are dangerous and require controlled charging environments. Otherwise, it may lead to explosion also. Here, I am going to build a 18650 Lithium-ion battery charger harnessing solar energy. Solar energy is abundant on earth surface. We will be using solar panels to convert solar radiation into electricity and use it to charge 18650 cells.

The setup can be used to power any electronic projects or devices such as projects which are installed in remote areas and it is uneconomical to power via other means. This setup can be used for an emergency purpose also if there is no power from the grid due to natural calamities such as flood etc.

Step 1: Get the Requirements

This project is made using cheap materials that can be sourced easily including Solar Panels, Lithium battery etc. The materials used in this project are as follows:

From Amazon:

Step 2: Connect the Battery to the TP4056 Protection Circuit

  1. Put the 18650 battery into the holder and solder wires across its connecting leads.
  2. Connect the +ve and -ve of the battery to the B+ pad and B- pad of the TP4056 circuit. TP4056 in a charger IC to charge 18650 batteries safely.
  3. The load can be connected to the OUT+ and OUT- of the circuit board.

Step 3: Charge the Battery Using Solar Power

TP4056 can be given charging power directly via micro USB but since we want it solar powered we have to add solar panels to it.

  1. Connect solar panels in parallel as much as you want. Here I am using 2.
  2. Connect the + and - from the solar panel to the IN+ and IN- of the TP4056 board. TP4056 has built-in overdischarge/overcurrent protection to protect the battery. It automatically cuts off the load if any anomaly is detected.

Step 4: Connecting the Load

One can power lighting load such as LEDs directly from the OUT of the TP4056 board. But for sophisticated electronic equipment which requires stable 5v power, we use MT3608 circuit. Connect the circuit as shown in the picture and adjust the output voltage as per the requirement of the load by rotating the potentiometer screw.

Now, you can give power to any electronic circuit by using this circuit. Harness the energy of the sun!

Be the First to Share

    Recommendations

    • 3D Printed Student Design Challenge

      3D Printed Student Design Challenge
    • Made with Math Contest

      Made with Math Contest
    • Edible Art Challenge

      Edible Art Challenge

    10 Comments

    0
    Matty icep
    Matty icep

    Question 1 year ago

    Should there be a diode connected to the solar panel to prevent reverse current for when the sun is not shown or is it unnecessary because of the 18650 charger prevents this?

    0
    xrtekk
    xrtekk

    Answer 4 months ago

    Definitely! Even though someone said that there is no need to this project; consider that: You want your solar panel to last; so YES; add a (easy to replace) diode (so it can be easily replaced when burnt; to prevent damaged solar panels due to current going back (which increases temperature on the solar panel if current goes back).

    Note: This is specially important if the project is adapted for a 12v with 18650 batteries. The 12v Power going back to the solar panel will greatly increase the heat in the panel and it will likely melt or burn.
    Yes: I’ve done such noob mistake; but added a diode to solve the problem.

    0
    chimeranzl
    chimeranzl

    Answer 1 year ago

    No need, panel is too small for to be concerned about reverse current.

    0
    CameronM37
    CameronM37

    6 months ago

    One concern I have with this circuit is that it looks like you can have a load and a charge on the TP4065 at the same time. This is dangerous because the TP4065 is not smart enough to know that the load exists and will give it a false sense of charge state and potentially overcharge the 18650 cell. This can result in fire or explosion.

    If you introduce a DPST switch such that the battery can either be charged OR the load can be connected, you will avoid this scenario.

    Other than this concern, this is a very cool instructable!!! Bravo!

    0
    plbenn
    plbenn

    10 months ago

    I have built this and it is working successfully but now I've seen a recommendation for a similar charging module which I will implement. The TP4056 module and the one pictured are both rated at 5v input. A 6v solar panel will supply more than 6v. The recommendation is to use a step down buck converter between the solar panel and regulator so that the regulator is only getting 5v at the input.

    0
    rohantatkare
    rohantatkare

    1 year ago

    A nice project to be used in rural areas !!!

    0
    FlyingGuy99
    FlyingGuy99

    2 years ago

    Just a question:

    Your picture is showing parallel wiring which serves to increase the amperage (not the voltage). However, in the instruction text you mention "Connect solar panels in series as much as you want". I think you really meant to say "Connect solar panels in parallel as much as you want", is that correct?

    0
    bishaldutta
    bishaldutta

    Reply 2 years ago

    That was an unintended mistake. Corrected. Thanks for pointing out.

    0
    bishaldutta
    bishaldutta

    Reply 3 years ago

    Thank you!
