Introduction: Squaring a Vise on a Mill - Machine Like a Pro
Squaring a vise is an important step to complete before you start machining. If you work in a shared work space, it is always a good idea to check before starting your project. It's not that hard and after doing it a few times it will only take you a couple minutes.
Step 1: Tools You'll Need:
Dial Test Indicator (DTI)
R8 collet to hold the dial test indicator (typically 3/8")
Dead blow hammer
7/8" wrench
R8 collet to hold the dial test indicator (typically 3/8")
Dead blow hammer
7/8" wrench
Step 2: Clean All Surfaces and Align Vise by Eye
Ensure both the mill table and bottom of vise are clean and free of debris.
Using the channels (t-slots) on the mill table, align the back jaw (fixed) with the t-slots by eye.
Using the channels (t-slots) on the mill table, align the back jaw (fixed) with the t-slots by eye.
Step 3: Install Bolts...and Spacers If Needed
Our bolts are too long, so we need a spacer below the bolt to make it work. Install on both sides.
Step 4: Tighten and Create a Pivot Point
We need to create a pivot point on the vise for fine tuning. Tighten one bolt approximately "monkey tight" and leave the other bolt a little loose. Where is our pivot point on the vise above? Answer at bottom right.
Step 5: Low Gear Before Loading Dial Test Indicator
Put the mill in low gear. This prevents the spindle and our dial test indicator from rotating.
Step 6: Mount Dial Test Indicator
Use a lot of care with dial test indicators; they are very precise instruments and typically cost more than $100. If you drop the indicator or expose it to an excessive amount of shock, it won't be as accurate. A machinist is only as good as his measuring tools.
Step 7: Lower the Quill - Get Everything in Place
To square the vise, we position the dial test indicator on the fixed jaw and note the value on both sides. When both values are the same, BAM!, the vise is now square. You can continue being awesome.
It's easiest to lower the quill to position the dial test indicator on the fixed jaw. You could also raise the knee of the mill to bring the vise/table to the top (this would be a more rigid position and is recommended during milling operations), but this takes quite a few turns and isn't necessary.
Quiz: Is the quill locked or unlocked?
It's easiest to lower the quill to position the dial test indicator on the fixed jaw. You could also raise the knee of the mill to bring the vise/table to the top (this would be a more rigid position and is recommended during milling operations), but this takes quite a few turns and isn't necessary.
Quiz: Is the quill locked or unlocked?
Step 8: Find the Difference in the Picture
Is the quill locked or unlocked?
Step 9: Touch Indicator to Fixed Jaw
Move y-axis (bring the vise towards you) so indicator touches the fixed jaw. You only want to deflect the needle on the indicator a few thousandths.
Step 10: Reading the Dial Test Indicator
We are starting on the left side of the vise. You only want to deflect the needle on the indicator a few thousandths (a few big tick marks).
Big tick mark to big tick mark are thousandths (.001").
Small tick mark to big tick mark are half-thousandths (.0005").
This dial is reading, in machinist lingo, "a little more than ten and a half thousandths (.0105)." Remember that value.
Big tick mark to big tick mark are thousandths (.001").
Small tick mark to big tick mark are half-thousandths (.0005").
This dial is reading, in machinist lingo, "a little more than ten and a half thousandths (.0105)." Remember that value.
Step 11: Move Indicator to Other Side
Now that you're here, hit the back button and look at the needle on the dial. Where is it? Press forward and come back here.
Move the indicator to the right side of the vise.
The indicator is now on the right side of the vise and the needle shows about 9 thousandths. The difference between the left and right side is one and a half thousandths.
We need to adjust the vise so both values are the same.
Move the indicator to the right side of the vise.
The indicator is now on the right side of the vise and the needle shows about 9 thousandths. The difference between the left and right side is one and a half thousandths.
We need to adjust the vise so both values are the same.
Step 12: Fine Tuning the Vise
Using the numbers here:
Right Side = .009"
Left Side = .0105"
Left Side (minus) Right Side = .0015"
.0015" is the maximum amount we want to move the right side (towards us).
Lightly tap the vise with a rubber mallet (dead blow hammer) to rotate the vise towards you. Rotating it towards you increases the value on the indicator.
Right Side = .009"
Left Side = .0105"
Left Side (minus) Right Side = .0015"
.0015" is the maximum amount we want to move the right side (towards us).
Lightly tap the vise with a rubber mallet (dead blow hammer) to rotate the vise towards you. Rotating it towards you increases the value on the indicator.
Step 13: New Right Side Value
After lightly tapping with the dead blow hammer, here's the new value (.0105"). Let's check the other side!
Step 14: Left Side Value
Here on the other side (left) the indicator now shows 11.5 thousandths, it was 10.5 thousandths. Let's go back to the right side and slightly adjust.
Step 15: Right Side Tweak
Now I'm on the right side. Tap, tap, moving the vise towards me makes the value increase from 10.5 thousands to 11.4 thousandths.
I like to adjust the vise while reading the indicator only on one side. In this case we are measuring on the right side.
Let's go back to the left.
I like to adjust the vise while reading the indicator only on one side. In this case we are measuring on the right side.
Let's go back to the left.
Step 16: Final Left Side Value
BAM POW. 11.5 on left 11.4 thousandths on right.
Since this indicator is accurate to .0005" (half thousandth) as stamped on the dial, I'm calling it good.
It's time to tighten down the bolts and secure the vise to the table.
Since this indicator is accurate to .0005" (half thousandth) as stamped on the dial, I'm calling it good.
It's time to tighten down the bolts and secure the vise to the table.
Step 17: Tighten Bolts
Monkey tight, not gorilla tight my friend. There's no need to go freakishly tight on machine tools...especially when you have a long wrench that gives you a lot of torque.
It might be hard not to rotate the vise as you do this, so try to do it carefully.
It might be hard not to rotate the vise as you do this, so try to do it carefully.
Step 18: Final Check
Run the indicator across the vise as a final check. If it moved slightly while tightening and it's something you want to correct, you can give it a little tap while it's fully secured. This last ditch alignment is ok and will only move .0005". If it's still way off the mark, repeat the steps and get it aligned. Tightening a bolt to be a snug pivot point takes a little practice.
Step 19: Almost There
Unlock the quill, retract the it, and remove the dial test indicator and collet.
Step 20: The End
You are awesome. Now go make something great!
