Introduction: Tello Drone Python Programming, Face Tracking From Drone Camera! Using Python Module OpenCV and PyGame!

By
About: My name is Muhammad Irsyad Yunus. I like to build many related Arduino project from multiple hardware. Instagram account: @techwithbob Don't Forget To Follow For More DIY Content And Tech Development!

In this tutorial, I will show you how you can program a face tracking drone through the use of Python programming languages with OpenCV library.

Supplies

Gather The Required Material:

Hardware:

Option:

Tello Drone (1x Battery, 1x Drone, 8x Propeller, No Multiple Battery Charger)

Tello Drone Boost Combo Pack (3x Battery, 1x Drone, 8x Propeller, 1x Multiple Battery Charger)

Amazon:

Ebay:

Software:

  • Any IDE that support Python
  • Python Programming Language

Required Python Version:

  • <3.10 And >3.7
  • Flexible Python IDE

Required Python Library:

Attachments

Step 1: Create Python Virtual Environment (Optional)

Setting Up Virtual Environment On Python:

If you already set up the virtual environment on your computer, just skip this step and move on to step 2.

Windows:

For windows, please refer to this link to set up the virtual environment.

Linux:

First install the required module virtualenv in the system.

pip install virtualenv


Create a folder for your project.

 mkdir projectA
 cd projectA


Setup the virtual environment with the given python version that you currently use.

Syntax:

 python<version> -m venv <virtual-environment-name>

Example:

 python3 -m venv .venv


Activate that virtual environment.

Syntax:

source <virtual-environment-name>/bin/activate

Example:

source .venv/bin/activate


Note!

To deactivate the virtual environment just enter the command:

deactivate

Step 2: Install the Required Python Module

Installing the Python Module:

  • opencv-python
pip install opencv-python
  • pygame
pip install pygame


  • numpy
pip install numpy
  • djitellopy
pip install djitellopy

Step 3: Programming

Firstly, create the drone controller python scripts and name it "controller.py" or what ever name you want.

You can also look up in my first tello tutorial.

Write this lines of codes in the "controller.py":

import pygame
def init():
#initialize pygame library
    pygame.init()
#Set Control Display as 400x400 pixel
    windows = pygame.display.set_mode((400,400))
if __name__ == '__main__':
    init()
    while True:
        main()


Secondly, create the facial recognition python scripts and name it "main.py" or what ever name you want.

Write this lines of codes in the "main.py" (with explanation):

import cv2 #import opencv library
import numpy as np #import numpy library
from djitellopy import tello #import djitellopy library
import time #import time library

me = tello.Tello() #initialise the djitello module classes on variable
me.connect() #establish wifi connection to the tello drone
print(me.get_battery()) #print the battery available on the tello drone

me.streamon() #start streaming the tello drone camera

w, h = 540, 360 #initialise the display dimension for the camera
MAX_STATE = 5

fbRange = [15 * 1000, 20 * 1000] #the range area of the detected face for forward and backward movement

#Range of threshold values of the detected face center point in y-axis
udRange = [(h/2)-30, (h/2)] # MIN DOWN, MAX UP
udMax = [(h/2), (h/2)+30]
udMin = [(h/2)-30, (h/2)-60]
udMotion = [0, -10, 10, -30, 30] # neutral, min, max, MIN , MAX

#Range of thresholds values of the detected face center point in x-axis
lrRange = [(w/2)-30, (w/2)+30] # MIN DOWN, MAX UP
lrMax = [(w/2)+30, (w/2)+60]
lrMin = [(w/2)-30 , (w/2)-60]
lrMotion = [0, 8, -8, 16, -16] #motion for left and right movement variables

#pid tuning controller
pid = [0.5, 0.5, 0]

pError = 0 #initial error value of PID

def findFace(img):

  faceCascade = cv2.CascadeClassifier("haarcascades/haarcascade_frontalface_default.xml") # the file location for frontal face detection.

  imgGray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)

  faces = faceCascade.detectMultiScale(imgGray, 1.2, 5)

  myFaceListC = []

  myFaceListArea = []

  for (x, y, w, h) in faces:

  cv2.rectangle(img, (x, y), (x + w, y + h), (0, 0, 255), 2)

  cx = x + w // 2

  cy = y + h // 2

  area = w * h

  cv2.circle(img, (cx, cy), 5, (0, 255, 0), cv2.FILLED)

  myFaceListC.append([cx, cy])

  myFaceListArea.append(area)

  if len(myFaceListArea) != 0:

  i = myFaceListArea.index(max(myFaceListArea))

  return img, [myFaceListC[i], myFaceListArea[i]]

  else:

  return img, [[0, 0], 0]

  def trackFace( info, w, pid, pError):
  global x, y, area

  area = info[1]

  x, y = info[0]

  fb, ud , lr = 0, 0, 0

  error = x - w // 2

  speed = pid[0] * error + pid[1] * (error - pError)

  speed = int(np.clip(speed, -100, 100))

  udState = [y > udRange[0] and y < udRange[1], y >= udMax[0], y <= udMin[0] and area != 0, y >= udMax[1], y <= udMin[1] and area != 0]
  lrState = [x > lrRange[0] and x < lrRange[1], x >= lrMax[0], x <= lrMin[0] and area != 0, x >= lrMax[1], x <= lrMin[1] and area != 0]

  if area > fbRange[0] and area < fbRange[1]:

  fb = 0

  elif area >= fbRange[1]:

  fb = -20

  elif area <= fbRange[0] and area != 0:

  fb = 20

  for index in range(MAX_STATE): #up down
  if (udState[index]):
  ud = udMotion[index]

  for index in range(MAX_STATE): #left right
  if (lrState[index]):
  lr = lrMotion[index]

  ######################################
  if x == 0:

  speed = 0

  error = 0

  #print(speed, fb)

  me.send_rc_control(lr, fb, ud, speed)

  return error

  #cap = cv2.VideoCapture(1)

  me.takeoff()
  me.send_rc_control(0, 0, 15, 0)
  time.sleep(1.5)

while True:

  #_, img = cap.read()

  img = me.get_frame_read().frame

  img = cv2.resize(img, (w, h))

  img, info = findFace(img)

  pError = trackFace( info, w, pid, pError)

  #print("Center", info[0], "Area", info[1])

  cv2.imshow("Output", img)

  if cv2.waitKey(1) & 0xFF == ord('q'):

  me.land()
  me.streamoff()

  break

cv2.destroyAllWindows()
exit()

Attachments

Step 4: Tello Drone Connection

  1. Turn On The Tello Drone From The Left Side
  2. Wait Until it Blink Yellow
  3. Find The Tello Wifi Connection On Your Computer/Devices
  4. Connect Your Device To Tello Wifi Connection

Step 5: Execute the Python Scripts

After The Tello Wifi Connection Connected, Click Run Program If You Are On VSCode Or Execute The Program In Your Own IDE.


Step 6: YouTube Tutorial

There will be a full YouTube tutorial for Tello Drone Programming On My YouTube Channel. Don't forget to leave a follow to stay updated! Thank you.
