Thermostat Based on Arduino

Introduction: Thermostat Based on Arduino

This time we are going to build a Thermostat based on Arduino, temperature sensor and relay.You can find on github

Step 1: Configuration

Whole configuration is stored in Config.h. You can change PINs controlling relays, reading temperature, thresholds or timings.

Step 2: Configuring Relays

Let's assume that we would like to have 3 relays:

  • ID:0, PIN: 1, Temperature setpoint: 20
  • ID:1, PIN: 10, Temperature setpoint: 30
  • ID:2, PIN: 11, Temperature setpoint: 40

First you have to make sure that PIN of your choice is not already taken. All pins can be find in Config.h, they are defined by variables starting with DIG_PIN.

You have to edit Config.h and configure PINs, thresholds and amount of relays. Obviously some properties already exists, so you have to just edit them.

<p>const static uint8_t DIG_PIN_RELAY_0 = 1;<br>const static uint8_t DIG_PIN_RELAY_1 = 10;
const static uint8_t DIG_PIN_RELAY_2 = 11;</p><p>const static uint8_t RELAYS_AMOUNT = 3;</p><p>const static int16_t RELAY_TEMP_SET_POINT_0 = 20;
const static int16_t RELAY_TEMP_SET_POINT_1 = 30;
const static int16_t RELAY_TEMP_SET_POINT_2 = 40;</p>

Now we have to setup relays and controller, this happens in RelayDriver.cpp

<p>initRelayHysteresisController(0, DIG_PIN_RELAY_0, RELAY_TEMP_SET_POINT_0);<br>initRelayHysteresisController(1, DIG_PIN_RELAY_1, RELAY_TEMP_SET_POINT_1);
initRelayHysteresisController(2, DIG_PIN_RELAY_2, RELAY_TEMP_SET_POINT_2);</p>

xxx

Step 3: Hysteresis Controller

It's the one chosen in example above, it has few additional configurations:

<p>const static uint32_t RELAY_DELAY_AFTER_SWITCH_MS = 300000; // 5 minutes<br>const static uint32_t RHC_RELAY_MIN_SWITCH_MS = 3600000;</p>

RELAY_DELAY_AFTER_SWITCH_MS gives wait time for switching next relay. Imagine that configuration from our example would start working in 40 degrees environment. This would result in enabling of all three relays at the same time. This could eventually lead to high power consumption - depending on what you are controlling, electric engine for example consumes more power during start. In our case switching relays has following flow: first relay goes, wait 5 minutes, second goes on, wait 5 minutes, third goes on.

RHC_RELAY_MIN_SWITCH_MS defines hysteresis, it's the minimum frequency for particular relay to change it's state. Once its on, it will remain on for alt least this period of time, ignoring temperature changes. This is quiet useful it you are controlling electric motors, since each switch has negative impact on live time.

Step 4: PID Controller

This is advanced topic. Implementing such controller is simple task, finding right amplitude settings is a different story.

In order to use PID controller you have to change initRelayHysteresisController(.....) to initRelayPiDController(....) and you need to find right settings for it. As usual you will find them in Config.h

I've implemented simple simulator in Java, so that it's possible to visualize the results. It can be found in folder: pidsimulator.
Below you can see simulations for two controllers PID a P. PID is not perfectly stable because I did not apply any sophisticated algorithm to find right values.

On both plots required temperature is set to 30 (blue). Current temperature indicates read line. Relay has two states ON and OFF. When it's enabled temperature drops by 1.5, when it's disabled it rises by 0.5.

Step 5: Message Bus

Different software modules have to communicate with each other, hopefully not both ways ;)

For example:

  • statistics module has to know when particular relay goes on and off,
  • pressing a button has to change display content and it also has to suspend services that would consume many CPU cycles, for example temperature reading from sensor,
  • after some time temperature reading has to be renewed,
  • and so on....

Every module is connected to Message Bus and can register for particular events, and can produce any events (first diagram).

On second diagram we can see event flow on pressing button.

Some components have some tasks than needs to be executed periodically. We could call their corresponding methods from main loop, since we have Message Bus it's only necessary to propagate right event (third diagram)

Step 6: Libs

Outside Contest 2017

Participated in the
Outside Contest 2017

Be the First to Share

    Recommendations

    • Game Design: Student Design Challenge

      Game Design: Student Design Challenge
    • For the Home Contest

      For the Home Contest
    • Make It Bridge

      Make It Bridge

    5 Comments

    0
    JonFromPA
    JonFromPA

    5 years ago

    Can you provide a link to the enclosure you used?

    0
    Col68
    Col68

    5 years ago

    Hello Maciej Miklas ,

    Very very big thank you for your instructables beautiful and very interesting, thank you for your sharing.

    With the help of Mr Keith on Instructables I managed to realize a thermostat, using LCD 1602 with buttons, relay 2 channels, module I2C, Dht22 and Uno.

    The code is simple it turns on and off the relays according to the instructions (temperature and humiditer) as the objective is to use this project with a fridge I really need to understand how and where to note his instructions to avoid frequent start of the fridge compressor.

    Another problem is that I do not really find a solution, after having finished assembling the thermostat on the fridge, turned on the thermostat, the relays open and close and so when we change the setpoint there is a car -reset to restart the program and the relays turn on and off again,

    at this time we have the compressor cable on the relay which also cuts and turns on the compressor, I think it's not good for the compressor.

    My question, Can we avoid this by using a piece of code to not change the state of the relays during the reset or can simply replace the 2-channel relays by SSR relays?

    Desolate to disturb you with my adventure, thank you,

    cordially.

    0
    Maciej Miklas
    Maciej Miklas

    Reply 5 years ago

    Are you using software from my instructable? In this case, every change of setpoint requires hardware restart (flushing), the relay would go off because Arduino needs to restart and it cust off power to digital out.

    You could extend software that you are using by adding two more buttons that would allow changes of setpoint during runtime, this would not require a restart and would solve your problem.

    Solution to frequent changes of realy state is quite easy: you need to add hysteresis, like one in this example: https://github.com/maciejmiklas/Thermostat/blob/ma...

    Define minimal time between switches, like 10 minutes, or you can use temperature instead of time. In case of temperature, let's assume that your setpoint is at 10 and temperature hysteresis is set to 3. A thermostat would go on by 13 and go off by 7. Without hysteresis it would go on by 11 and off by 10 and that results in frequent switches. The temperature is more stable (closer to 10), but... compressor will not last long.

    0
    Col68
    Col68

    Reply 5 years ago

    Hello Maciej, thank you for your explanation and your help, this is exactly what I needed to improve the project.

    I do not use the same software but I will work to understand and can integrate the software into the code. As i am amateur the work is slowing down because without help impossible to move forward, thankfully the honorable as you share to help the fans.

    Thank you very much for your help. I wish you a good weekend and happiness, soon, cordially.
