Introduction: Tito - Arduino UNO 3d Printed Robot

About: Product Design Engineer & maker, roboticist, 3D modeling professional and 3D printing enthusiast. Creator and Founder of Otto DIY, a project that follows my passion for robotics, toys, open source hardwar…

Tito is a Biped dancing DIY robot, derivative from Zowi and Bob, basically has been adapted to an standard Arduino UNO board with easier connections and supports. It was the first iteration for Otto DIY (


Arduino UNO board or compatible (in my case a DFRduino UNO)



Futaba servo S3003 x4

HC-SR04 Ultrasound sensor

Powerbank (optional)

Nut M3 x20

Screw M3 x20

3D printed Head

3D printed Base3D printed Leg x23D printed Foot R3D printed Foot L

Tools: 3D printer, Allen key and screwdriver

Step 1: 3D Print Parts

3D .stl files here: Find a way to 3D print the parts, they are designed for no supports, so it is very easy to print with 20% infill and 0.2mm resolution.

Since is Tito is completely opensource you can find there the 3D model design files.

Step 2: ​Pre Assemble

There is many was to build Tito, but one recommendation is before the connect the servos is to assemble the servo disk pieces to the legs, then put the servos in the body and the feet..

Step 3: Wiring

Connect the servo motors in 2,3,4,5 digital outputs refer to the same wiring of other Ottos, HC-SR04 Ultrasound sensor (trig for pin 8 and echo for pin 9).

For more details just use the same connections used in Otto DIY robot

Step 4: ​Test the Position of the Servos

In the picture the cables are disconnected but the idea here is to upload a code to the Arduino UNO board that will put the all servos in 90 degrees and then match the right angle for the crank discs in the body and the feet. Tito should be in a position like the photo. then you can fix all the servos with the screw axis.

Step 5: ​Assemble Arduino UNO Board

This design make it easy to fix any Arduino Uno compatible board (in my case a DFRduino UNO) in the head part, you can use up to 4 screws.

Step 6: ​Final Assembly

If all connections are secured you can close the head part and fix it to the body using the lateral screws.

Step 7: Coding With Blocks

Just connect your USB cable to Arduino UNO and upload the codes from our Otto Blockly software. There are many examples for the robot like walk different directions, ultrasound, raise, tilt and dance.
