Introduction: Adafruit SI1145 UV/Visible Light/Infrared Sensor - Arduino and LCD
This project uses an Adafruit SI1145 UV/Visible Light/Infrared sensor to calculate the current UV rating. UV isn’t sensed directly. Rather, it is calculated as a function of the visible light and infrared readings. When I tested it outside, it was accurate based on the the UV reading from weather.com. I envisioned the project with a "steampunk" theme - a device that an airship captain would need when the UV exposure on the deck would require application or reapplication of sunblock.
Step 1: Gather Necessary Materials
- Arduino Uno and sync cord to USB port
- Computer to program Arduino
- Adafruit Library for the UV sensor (https://github.com/adafruit/Adafruit_SI1145_Library/)
- Liquid Crystal display library (https://github.com/arduino/Arduino/tree/master/libraries/LiquidCrystal)
- LCD display. I used: (https://smile.amazon.com/uxcell-Standard-Character-Backlight-Display/dp/B00EDMMTGY/ref=sr_1_1?ie=UTF8&qid=1481681388&sr=8-1&keywords=lcd+screen+arduino)
- Adafruit SI1145 sensor for UV/IR/visible light (https://www.adafruit.com/products/1777) B
- Male–to–male jumper cables
- 10k Potentiometer
- 220 ohm resistor
- Battery pack (8 AA batteries) 6 AA batteries
Step 2: Configuration of Hardware
Solder UV sensor
Connect Arduino to USB port on computer
Connect LCD display to Arduino
- LCD RS pin – digital pin 12
- LCD Enable pin – digital pin 11
- LCD D4 – digital pin 5
- LCD D5 pin – digital pin 4
- LCD D6 pin – digital pin 3
- LCD D7 pin – digital pin 2
Connect UV sensor module to Arduino. (Adafruit's page on the sensor includes a nice tutorial including wiring pics).
- VIN to power supply – 5V or 3V. I set the sensor to use 3.3V so that the 5V can be used by the LCD screen
- GND to ground.
- SCL on sensor to SCL on Arduino - pin A5.
- SDA on sensor to SDA on Arduino – pin A4.
Wire a 10k potentiometer to +5V and Ground with output to LCD pin 3
Wire a 220 ohm resister to power the backlight of the display, pin 15 to 5V and Pin 16 to Ground.
Step 3: Add Code to Arduino to Take UV Readings
The attached file includes the code for the Arduino which will initialize the sensor and take UV readings.
Step 4: Troubleshooting (if Necessary)
I used battery packs to power the Arduino because a 5V power adapter gave it too much power - the display became distorted.
You can view the initialization of the sensor from the serial display in the Arduino. A minor tweak in the code can allow you to check readings on the serial display as well. Change "lcd.print" to "serial.print."
