Introduction: Waterproofing a Capacitance Soil Moisture Sensor

About: Professor Colorado State University Department of Soil and Crop Sciences Fort Collins, Colorado, USA

Capacitive soil-moisture sensors are a great way to monitor soil water status in your potted plants, garden, or greenhouse using an Arduino, ESP32, or other microcontroller. They are superior to the resistance probes often used in DIY projects. See the video from Andreas Spiess for a good explanation of how they work. The capacitance sensors only cost about $1 each in bulk, however, they have exposed electronics and are not waterproof. A soil moisture sensor that can't get wet is not very useful. This instructable shows you how to waterproof your sensors using adhesive-lined heat shrink, a small set of supplies, and common tools.

Supplies


Parts:

  1. Capacitance soil moisture sensor, example from eBay, or from DFrobot
  2. Signal wire (at least 3 conductors), 22 -24 gauge; we used telephone wire from Lowes; it's solid core 4-conductor so one wire is not used.
  3. Adhesive-lined Polyolefin Heat-shrink tubing in three sizes: 1/4", 1/2" and 3/4" diam. with at least 3:1 shrink. Purchased on eBay for about 1$ per foot (example).
  4. Laquer or nail polish: we used Sally Hansen Hard as Nails from Target

Tools:

  1. Wire Cutter (flush style)
  2. Wire Stripper
  3. Heat Gun
  4. Soldering iron and solder
  5. Arduino or other microcontroller if you want to test the sensor before and after assembly

Note: The most unusual item in this build is the large diam. heat shrink tubing with adhesive. Heat shrink is readily available from many suppliers. It's also on eBay, so you can buy your heat shrink when you buy your soil moisture sensors. Again, it must be adhesive-lined and have a 3:1 shrink ratio.

Step 1: Get a Capacitance-based Soil Moisture Sensor and Test

On rare occasions, we have found batches of these sensors that are flawed (we got a bad order from Ali Express). I would run a simple test of the sensors with an Arduino before waterproofing. There are many tutorials on the web - here is an example.

Step 2: Remove the Connector

Remove the connector with a flush cutter. After the connector is removed, there will be three unused solder through-holes for attaching the signal wires (they cannot be seen until you remove the connector)

Step 3: Prep Signal Wire and Solder to Sensor

Prep signal wire and solder. Made sure to trim the wires on the back of the board flush with the PCB using your cutter. Clean the solder joint with rubbing alcohol.

Step 4: Apply Lacquer (nail Polish) to Exposed Circuits

Apply Sally Hansen's nail polish or a similar compound to exposed circuits on the front and back where the electronic components and traces are exposed. Do not apply to the whole sensor board, just the top inch or so with exposed electronics. Do this outdoors or in a well-ventilated room - allow 30 min to dry.

Step 5: File the Corners of the PCB Sensor With Sandpaper or a File

File the corners with sandpaper or a file. This prevents the sharp corner from piercing the heat shrink tubing

Step 6: Prep Your Heat-shrink Tubing

Cut three sectons of heat shrink tubing as follows.

1/4" diam. - 1.25 inches long

1/2" diam. - 0.75 inches long

3/4" diam. = 1.5 to 1.75 inches long (I used 1 5/8")

Step 7: Shrink the 1/4" Diameter Tubing First

Apply the 1/4 diameter tubing with the heat gun - as always - BE VERY CAREFUL WITH THE HEAT GUN. Get adult supervision if needed.

Step 8: Add the 1/2" Diameter Heat-shrink Tubing

Add the 1/2 tubing with the heat gun.

Step 9: Apply the 3/4" Diameter Heat-shrink Tubing

Last, apply the 3/4" diameter tubing. Make sure the adhesive is melted and seals all the joints. It's important that you get the tubing in the correct position or you won't get full coverage of the electronics. Using a gloved hand, you can apply pressure to the heat shrink while it's still warm to push the adhesive onto the PCB; this may improve the seal.

Step 10: Apply a Thin Layer of Nail Polish at the Sensor / Tubing Seam

Apply a thin layer of nail polish at the sensor / tubing seam to provide extra waterproofing protection.

Step 11: Complete Probes and Test Again

Test the probes again with your Arduino or other microcontroller. I submerged my sensors in a glass of water for several days while taking readings periodically to verify performance.
