Introduction: Cnc Machine

Step 1: Drawing the Machine

I started by creating the design of the machine on SolidWorks.

On the PDF i put all the measurements.



Step 2: Start Construction

After seeing all the measurements, I calculated the amount of iron that I would need to build the machine. It was something like 16 meters of square tube.



So I bought two bars of six meters square tube 20*20*2, one bar of 6 meters square tube 25*25*2 and one bar of 6 meters angle iron 25*25*3.



Then I started cutting and drilling holes in all parts according to the technical drawing.

after that i started welding the parts.





Step 3: Motors and Drivers

i bought on ebay one kit of stepper motors with driver and power supply.

The steppers are Nema 23 Stepper Motor 287oz-in



Step 4: Final Product

Overall, the machine is good, just not fast enough because i use a m8 screw as lead screw.

So the machine only can do 300 mm/m



Step 5: Some Stuff

stuff i made with the machine.

Instructables Design Competition

Participated in the
Instructables Design Competition

Be the First to Share

    Recommendations

    • Plywood Challenge

      Plywood Challenge
    • Plastic Contest

      Plastic Contest
    • Battery Powered Contest

      Battery Powered Contest

    16 Discussions

    0
    nunotec
    nunotec

    6 years ago on Introduction

    Would you like to reduce the backlash?

    It is very Easy , i think :) www.dumpster.com is a link with antiback lash solutions and cheap

    Otherway you can DIY with a pieces of HDPE High Density Poly Ethilene ( Polietileno de alta densidade , ex tábua de cortar pão)

    In a shop of specialized plastic materials you can take it very very cheap!!

    My Email

    nunotec@hotmail.com

    0
    nunotec
    nunotec

    6 years ago on Introduction

    VERY VERY GOOD PROJECT I WOULD LIKE TO BUILD IT

    IT SEEM YOU ARE PORTUGUESE , I AM TOO, I AM FROM OPORTO

    BEST REGARDS

    NUNO

    0
    R-A
    R-A

    7 years ago on Introduction

    This looks awesome!

    I'm quite curious, what kind of accuracy / precision do you get?
    and what depth can it cut?

    0
    speed_hack
    speed_hack

    Reply 7 years ago on Introduction

    It has a good precision, but have a little bit backslash. The depth of the cut depends of the bits, but i think 70mm it`s the max.

    0
    J,R,D, Ltd
    J,R,D, Ltd

    7 years ago on Introduction

    What is the coiled yellow line for? Is that compressed air or a vacuum?

    0
    kapriece
    kapriece

    7 years ago on Step 5

    how hard was it to tweak the software?

    0
    speed_hack
    speed_hack

    Reply 7 years ago on Introduction

    a little bit, i still have some problems with backlash but isn't a big deal

    0
    RTegelbeckers
    RTegelbeckers

    Reply 7 years ago on Introduction

    You can compensate for backlash in Mach 3. It works really well.

    0
    e.ma.niak
    e.ma.niak

    7 years ago on Introduction

    Im new at this, so before i start i want to know: How did u calibrated the CNC? (how does it know how big is 1cm...) And is there a difference between USB and Paralel control, i mean does the same software operate with both?

    0
    Atman8
    Atman8

    7 years ago on Introduction

    What do you think about the performance of the motors? I'm trying to decide what size to buy.

    0
    Brittond14
    Brittond14

    8 years ago on Step 5

    Good job brother. How heavy is your machine?

    0
    speed_hack
    speed_hack

    Reply 8 years ago on Step 5

    thanks bro. maybe 30 or 40 kg

    0
    speed_hack
    speed_hack

    8 years ago on Introduction

    Yes please, some tips are always welcome. My problem with these motors is that the faster they go more torque they loses.
    This motors are rated 8volts 1Amp
    sorry my english, some times i have to use google translate :P

    0
    speed_hack
    speed_hack

    8 years ago on Introduction

    For the motor couplers i'm using a piece of rubber pipe tied with zip ties.
    and the motor driver is a TB6550

    0
    pfred2
    pfred2

    Reply 8 years ago on Introduction

    Yay rubber hose FTW! If you'd like I could tell you how to tune your motor drivers up to get them to run better. I know about TB6560AHQ motor driver ICs because I made my own drivers with them. That made me to learn all about the things.

    0
    sleeping
    sleeping

    8 years ago on Introduction

    Can you show a picture of the motor couplers. What type of motor drivers are you using. Thanks
