Introduction: ATMEGA2560 Standalone Using Arduino UNO

About: I'm an electronics hobbyist and an aviation enthusiast.

In this instructable we will learn how to bootload the ATMEGA2560 chip and how to upload Arduino Mega sketches to it.

Step 1: Getting Started...

I know that many of us (including me) want ATMEGA2560 in standalone mode for our projects, as it is far better than ATMEGA328. So, here is a simple & easiest way to get working ATMEGA2560 in standalone mode.

Let's get started...

Here is a pin diagram of ATMEGA2560 which will be useful further in this Instructable. The file is in PDF & svg format. Take a print of it.

Step 2: Parts Needed.

Arduino UNO board.

Atmega2560 SMD IC.

QFP-100 breakout board.

Male header pins.

10k resistor.

16MHz crystal.

22pf capacitors X 2

A LED.

Wires for connection.

Arduino IDE. (I have 1.6.8)

Step 3: Soldering ATMEGA2560 on to QFP-100 Board.

If you have a board with 2560 already soldered on, then it is fine, you may skip to the next step.

If you do not have a board with 2560 already soldered on (just like me), then watch the video How to solder SMD 100pin IC on to QFP-100 board. This will guide you on soldering steps.

Video credits to the respective owner.

Step 4: Bootloading 2560. Part I

Assuming that our ATMEGA2560 is empty, we will program the Arduino bootloader.

Start the Arduino IDE program. Connect just the Arduino UNO and load the File -> Examples -> ArduinoISP sketch. Select the Arduino UNO board under Tools and the default AVRISP mkII as programmer. Select the serial port and finally compile and upload the sketch as you would normally do.

After uploading is done, Disconnect the Arduino and proceed to connections as below: (Refer the pin diagram of 2560 IC provided in step 1)

UNO pins -> ATMEGA2560 pins

10 -> 30

11 -> 21

12 -> 22

13 -> 20

5v -> VCC (in my case pin 10)

GND -> GND (in my case pin 11)

connect the 16MHz crystal & 22pf capacitors to ATMEGA2560 as shown in diagram.

Also connect a 10k resistor between VCC and pin 30 of Atmega2560.

Step 5: Bootloading 2560. Part II

Once done with the connections, now find a file called "boards.txt" in your Arduino installation directory.

In my case, the path is "C:\Program Files (x86)\Arduino\hardware\arduino\avr".

Open it with a text editor (I used Notepad++) and locate to the ATMEGA2560 section. Find the line "mega.menu.cpu.atmega2560.bootloader.high_fuses=0xD8"

We have to replace the value of "0xD8" with "0xD9". This is so, because in stand-alone ATMEGA2560 chips, if the BOOTRST fuse is not set, the chip will be correctly programmed, but the programs will never run. So the line could look like this (we can keep the original line commented as I did.)

"mega.menu.cpu.atmega2560.bootloader.high_fuses=0xD9".

Save the changes and close the text editor.

Now we burn the bootloader. Connect the Arduino UNO board & open Arduino IDE, go to tools, and select as following:

Board: Arduino Mega 2560.

Processor: ATMEGA2560.

Programmer: Arduino as ISP.

Port: (respective arduinoUNO port).

And now from tools, click "Burn Bootloader". If everything is done correctly, the process will take some seconds and will finish with no errors.

Step 6: Programming Arduino Sketches to ATMEGA2560.

Now as we have done bootloading, we proceed with uploading a blink sketch to our 2560 chip.

Disconnect the Arduino from your computer.

Disconnect the previous connections we have made, except the connections of the crystal to 2560. Now connect as following:

UNO pins -> ATMEGA2560 pins

5v -> VCC

GND -> GND

reset -> 30

Rx -> 2

Tx -> 3

Now, REMOVE THE ATMEGA328 FROM UNO BOARD. Connect a LED accordingly

LED positive + to 22 of 2560 chip.

LED negative - to GND of 2560 chip.

Now connect arduino board, open Arduino IDE & open 'Blink' sketch from Files-> Examples-> Basics. In void setup & void loop, change output pin 13, to 50. (or copy the code attached) & upload the code with following settings in tools:

Board: Arduino Mega 2560.

Processor: ATMEGA2560.

Programmer: AVRISP mkll.

Port: (respective arduinoUNO port).

ARDUINO CODE:

void setup()

{
pinMode(50, OUTPUT);

}

void loop()

{

digitalWrite(50, HIGH);

delay(1000);

digitalWrite(50, LOW);

delay(1000);

}

The LED connected to 2560 chip should blink. Now you can upload your Arduino MEGA sketches & connect your own circuit keeping the crystal connection as it is & with above settings in tools. You may refer the pin diagram provided in step 1 or the datasheet of Atmega2560 for your circuits.

Best of luck...

Step 7: Tips and Problems.

Some people, reported having problems when using the same 5V power source from the Arduino. If you get problems about the programmer or board not responding, recheck the connections or try using another power source for the chip ( battery, another Arduino, etc. ).

The sketch still doesn't run after following the instructions. Please enable the verbose mode (enable the checkboxes in the Preferences dialog for compiling and uploading) in Arduino, and check again the fuse settings applied correctly. You'll see them in avrdude command output. If it doesn't show the correct fuse value, you either incorrectly edited the boards.txt file or you edited the wrong file.

3 People Made This Project!

Recommendations

  • Microcontroller Contest

    Microcontroller Contest
  • Automation Contest

    Automation Contest
  • Make it Glow Contest

    Make it Glow Contest

12 Comments

0
trieuvuquan
trieuvuquan

2 months ago on Introduction

hello, thanks for your very detailed instruction. I made it, but the bootloader only works once, right after burning bootloader I can program the blink as you indicated, but the next time I made a few changes to the code in the blink (such as delay time), it cannot connect any more. The log are below:
avrdude: stk500v2_ReceiveMessage(): timeout
avrdude: stk500v2_ReceiveMessage(): timeout
avrdude: stk500v2_ReceiveMessage(): timeout
avrdude: stk500v2_ReceiveMessage(): timeout
avrdude: stk500v2_ReceiveMessage(): timeout
avrdude: stk500v2_ReceiveMessage(): timeout
avrdude: stk500v2_getsync(): timeout communicating with programmer

I have changed the boards.txt, add crystal and the cap to the boards, but no luck. could you take a look and guide me what to do? Thanks in advance!

0
Silicon14
Silicon14

Reply 2 months ago

Seems some communication issue.. as your bootloader got programmed and you were able to program 2560 with blink.
Check your crystal & capacitors connection once again. Make sure the crystal and the capacitor are connected neatly and are tight. If you see in the very first image of this instructable (the one before the start of this instructable), you will see that I have put cap pin and crystal pin in only one hole of the red breedboard. (Zoom in to see)
Try to keep it as close as possible and make sure the connection between the 2560 and crystal circuit is good and is nor floating or loosely connected.


Hope this solves your problem

0
trieuvuquan
trieuvuquan

Reply 2 months ago

Thank you for your response, it seems that the problem lies in setting fuse bits to lock the bootloader, because if serial was used to program the chip, then the first time the chip got programmed, it will erase the chip and also the bootloader.

0
KevinL204
KevinL204

2 years ago

hey. thanks for the instruction. it is very useful actually, but mine is not working. i keep following the step you are in, but i only get this:

"avrdude: Version 6.3, compiled on Jan 17 2017 at 12:00:53

Copyright (c) 2000-2005 Brian Dean, http://www.bdmicro.com/

Copyright (c) 2007-2014 Joerg Wunsch

System wide configuration file is "C:\Users\KEVIN\AppData\Local\Arduino15\packages\arduino\tools\avrdude\6.3.0-arduino9/etc/avrdude.conf"

Using Port : COM15

Using Programmer : stk500v1

Overriding Baud Rate : 19200

AVR Part : ATmega2560

Chip Erase delay : 9000 us

PAGEL : PD7

BS2 : PA0

RESET disposition : dedicated

RETRY pulse : SCK

serial program mode : yes

parallel program mode : yes

Timeout : 200

StabDelay : 100

CmdexeDelay : 25

SyncLoops : 32

ByteDelay : 0

PollIndex : 3

PollValue : 0x53

Memory Detail :

Block Poll Page Polled

Memory Type Mode Delay Size Indx Paged Size Size #Pages MinW MaxW ReadBack

----------- ---- ----- ----- ---- ------ ------ ---- ------ ----- ----- ---------

eeprom 65 10 8 0 no 4096 8 0 9000 9000 0x00 0x00

flash 65 10 256 0 yes 262144 256 1024 4500 4500 0x00 0x00

lfuse 0 0 0 0 no 1 0 0 9000 9000 0x00 0x00

hfuse 0 0 0 0 no 1 0 0 9000 9000 0x00 0x00

efuse 0 0 0 0 no 1 0 0 9000 9000 0x00 0x00

lock 0 0 0 0 no 1 0 0 9000 9000 0x00 0x00

calibration 0 0 0 0 no 1 0 0 0 0 0x00 0x00

signature 0 0 0 0 no 3 0 0 0 0 0x00 0x00

Programmer Type : STK500

Description : Atmel STK500 Version 1.x firmware

Hardware Version: 2

Firmware Version: 1.18

Topcard : Unknown

Vtarget : 0.0 V

Varef : 0.0 V

Oscillator : Off

SCK period : 0.1 us

avrdude: AVR device initialized and ready to accept instructions

Reading | ################################################## | 100% 0.02s

avrdude: Device signature = 0x000000 (retrying)

Reading | ################################################## | 100% 0.02s

avrdude: Device signature = 0x000000 (retrying)

Error while burning bootloader.

Reading | ################################################## | 100% 0.02s

avrdude: Device signature = 0x000000

avrdude: Yikes! Invalid device signature.

Double check connections and try again, or use -F to override

this check.

avrdude done. Thank you."

can you help me solve this?

0
yogesYogi
yogesYogi

Reply 1 year ago

Hay dude i have same problem as you mention above.Are you get solution for this,if you have solution can u help me?

0
Silicon14
Silicon14

Reply 11 months ago

I got your problem..
This device signature issue is not new..
Can you tell me the exact number of your 2560 IC
like for me it is "ATMEGA2560 16U-TW"
The number after ATMEGA2560 if different, causes this issue..

I'm soo sorry for late reply

0
NischalM4
NischalM4

Reply 1 year ago

I got the same error. Reburn AVR ISP code to Arduino and try again.

0
Silicon14
Silicon14

Reply 11 months ago

I got your problem..
This device signature issue is not new..
Can you tell me the exact number of your 2560 IC
like for me it is "ATMEGA2560 16U-TW"
The number after ATMEGA2560 if different, causes this issue..

I'm soo sorry for late reply

0
rakeshonebrs
rakeshonebrs

1 year ago

Thank you very much sir for your guideline. I sucessfully upload bootloader into atmega2560 as your guidance. Problem start then after.I upload my program using empty (without chip)arduino board (RX,TX,RESET, VCC and GND) to atmega2560, upload done sucessfully. But after disconnect arduino board from stand alone atmega2560 when i give supply to it, it doesnt execute program.If i again connect arduino RX and TX to stand alone RX TX of atmega2560 program execute. If i disconnect arduino board again program not execute. Please tell me solution of it. Thank you

0
Silicon14
Silicon14

Reply 11 months ago

Hello,
First of all sorry for late reply..
Assuming you have kept the crystal connections as it is while uploading your program & settings as I told.
I understand your problem, it seems that you did not edit or incorrectly edited "boards.txt" file.. because if you incorrectly edit the file, your program will get uploded but never run.
Follow the "Step 5: Bootloading 2560. Part II"
this may solve your problem :)

0
ArshdeepM
ArshdeepM

Question 2 years ago on Step 7

Hello, thank you for such a useful instructable. I have one concern before i can go ahead and make this project. If i try to compile my program using arduino uno, then it will give errors as it would not have the defined analog pins on it. Such as A11, A12 etc, which i am using in my project. How would that work in this case?

0
Silicon14
Silicon14

Answer 2 years ago

Hello,

Go to Tools and in Boards option select ''Arduino Mega or mega 2560'' and again in tools select processor as ''Atmega 2560''. Now compile your code for Arduino Mega, you will get no errors for your pins.
