Blinking

The STM32 Black Pill, paired with the STM32CubeIDE, offers an excellent platform for learning embedded systems development. In this tutorial, we'll explore how to implement a sequence where three LEDs blink in various combinations. These combinations will include patterns such as 100, 010, 001, 110, and others, totaling nine distinct combinations. We'll achieve this using HAL (Hardware Abstraction Layer) programming, which simplifies low-level hardware access and configuration on STM32 microcontrollers. By following this tutorial, you'll gain hands-on experience in configuring GPIO pins, controlling LEDs, and creating custom sequences, laying a solid foundation for more complex embedded systems projects. Let's dive in and start blinking those LEDs in exciting patterns!

Supplies

1. STM32 Black Pill
2. Bread Board
3. Male-Male jumper connector cables
4. LED (3 nos.)
5. C Type cable

Step 1: Making a New Project File in STM 32CubeIDE

GOTO---->> File>New>STM32 Project

Step 2: Add Configuration to STM32 Board

Step 3: Configuring Your Board

Step 4: Configure Your Clock

Step 5: Open Main.c File

GOTO Project and find main.c file

Step 6: Goto While(1) in Main() and Add Your Code

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,0);

HAL_Delay(400);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,1);

HAL_Delay(400);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,0);

HAL_Delay(400);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,1);

HAL_Delay(400);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,0);

HAL_Delay(400);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,0);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,1);

HAL_Delay(400);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,0);

HAL_Delay(400);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_13,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_14,1);

HAL_GPIO_WritePin(GPIOC,GPIO_PIN_15,1);

HAL_Delay(400);

Step 7: Debug

Open and Click On Debug(1)

Step 8: Copy Path of .elf File Generated

Right click on Project and click on show in system explorer and copy the path

Step 9: Open STMCubeProgrammer and Connect to STM Board Via USB

Step 10: Go to Download Options

Step 11: Change Download Options and Click on "Start Automatic Mode"
