Citroen C4 Grand Picasso Exclusive Battery Swap

10,353

2

9

Introduction: Citroen C4 Grand Picasso Exclusive Battery Swap

Engine compartment showing the battery and parts surrounding it.

You should only need 10mm socket on 1/4” inch ratchet plus extension set as well as a flat blade
screwdriver for the plugs etc. and an Allen key for the electrics bracket and finally maybe a lever to help get the back battery clamp loose.

Step 1: Lead Cover Removal

First off remove this cover from the positive terminal. Use a flat

blade screwdriver to open the two clips at either side of the terminal, lift a little and then slide it off towards you. Unclip the lead by simply lifting the lever then move it out of the way.

Step 2: Remove the Multi Plugs

The two plugs are held in place by a “tag”.Press it down with a

small driver and lift up the white cover fully to let the plug come out and then gently take it out. Two to do and move out of the way.

Step 3: Remove Cable

Press the tag down and the cable and holder will be able to be

moved out of the way. Ie. pull towards you and move under the plate out of the way.

Step 4: Electrics Removal

Remove the two bolts holding the electrics in front of the battery.

The bracket has a “tag” on it and when the bolts are out, move the unit to the left to unclip the tag.You should then be able to lift the unit and put it out of the way.

Step 5: Unit Moved Out of the Way

Moved

Step 6: Remove the Steadying Bracket

Remove the steadying bracket for the electrics at the left of the

battery using an Allen key to take out the bolt and sliding the bracket towards you to slip it out of the holder. This will allow easier access to the battery.

Step 7: Remove Battery Retaining Bracket

Remove the two bolts holding the battery retaining bracket. Note

the arrowed slot where the electrics bracket goes back in.

Step 8: Finally

You can now pull the battery forward enough to get at the rear terminal and unbolt it with a 10mm

socket and extension. It can be a little tight and need some fiddling. The battery can now be removed.

After refitting, the date and time needed to be set but that was all.
