Introduction: Contact Less(Smart ) Room Controller
I teach 7th grade student. On behalf of my student Harsha and her brother im writing this instructable. In this COVID-19 situation we created a Smart Home Controller which I'm using now in my home, in which i have used IR sensor and made it Contact-less. This Room controller can be controlled using IR Sensors or we can even control using our Mobile(using Blynk App).
All step by step details are provided below.
Step 1: Required Parts
1)NodeMCU - 1 ( https://amzn.to/35hyEi0 )
2)2-CH Relay Module- 1 ( https://amzn.to/2ZhZtz7 )
3)IR Sensors - 2 ( https://amzn.to/2ZiLn0f )
4)Connectors -Few ( https://amzn.to/2Fcqddp )
5)Hi-Link 12v or 5v Power Supply - 1 (https://amzn.to/2FcpjNT ) - 5v
6)7805 Voltage Regulator - 1 ( https://amzn.to/3bA5YSK )
7)220uf capacitor - 1
8)22uf capacitor - 1
Step 2: Circuit Diagram
Connect all the components as per circuit diagram.
NodeMCU Relay Connections:
NodeMCU D0- Relay Signal pin 1(input pin)
NodeMCU D6- Relay Signal pin 2(input pin)
NodeMCU IR Sensors Connections:
NodeMCU D4- Sensor-1 Signal pin (output pin)
NodeMCU D5- Sensor-2 Signal pin (output pin)
All (NodeMCU ,Relay Module and Sensors) Vcc to 7805 Output pin(last pin)
All (NodeMCU ,Relay Module and Sensors)Gnd's to 7805 Gnd pin (middle pin)
Hi-Link Vo+ to 7805 Input pin (first pin) through capacitor +ve
Hi-Link Vo- to 7805 Gnd pin(middle pin) through capacitor -ve
Step 3: Arduino Code
Download the libraries from below links
WifiUdp ( https://bit.ly/3k0fzoC )
ESP8266mDNS ( https://bit.ly/3k1xmf9 )
ArduinoOTA ( https://bit.ly/3bB9SuB )
BlynkTimer ( https://bit.ly/333lJxC )
thanks to techiesms for code reference.
Step 4: Blynk App Setup
Step1: Download Blynk App from playstore/appstore
Step2: Signup with your email id
Step3: Click on +New Project
Step4: Give your project a name
Step5: Select board to NodeMCU
Step6: Select Connection type to Wifi and click on submit
Step7: Verification code will be sent to your mail
Step8: Click on + button on top(android users) or click on screen(iphone users) and add a button to screen
Step9: Click on the button
Step10: Give your button a name
Step11: Select output to virutal pin v12 and slide from push to switch
Step12: Add another button and select output to virtual pin v13
Step13: Click on play button on top
Step 5: Add Wifi Credentials and Auth Code to Code
Step1: Copy the auth token form your mail and paste it in the code.
Step2: Give your wifi ssid in you code
Step3: Give your wifi password in your code
(reference in above pics)
Step 6: Upload
Step1: Connect your NodeMCU to your pc.
Step2: Open code in Arduino IDE and make necessary changes (auth token, ssid and password).
Step3: Click on tools and go to boards and select nodemcu1.0.
note: If you don't have nodemcu boards on your arduino ide please see this video (
Step4: Click on upload.
Step 7: Final Output
I have drilled holes in my switch board and kept all the circuit inside.
For Indication I've remover led's on relay board and added a 5 mm led and fixed in the switch board.
Feel free to ask me if you have any doubts in this instructable.
