Introduction: How to Use Segment 3642BH With SkiiiD
This project is an instruction of "how to use Segment 3642BH with Arduino via skiiiD
Before start, below is a basic tutorial for how to use skiiiD https://www.instructables.com/id/Getting-Started-With-SkiiiD-Editor/
Step 1: Launch SkiiiD
Launch skiiiD and select New button
Step 2: Select Arduino UNO
Select ① Arduino Uno and then click ② OK button
*This is Tutorial, and we use Arduino UNO. Other boards(Mega, Nano) have the same process.
Step 3: Add Component
Click '+' (Add Component Button) to search and select the component.
Step 4: Search or Find a Component
① Type 'RGBLed' on the search bar or find the Buzzer module on the list.
Step 5: Select Segment 3642BH
② Select Segment 3642BH Module
Step 6: Pin Indication and Configuration
then you can see ③ pin indication. (You can configure it.)
*This module has 4 pins to connect
skiiiD Editor automatically indicate pin setting *configuration available
[Default Pin Indication for Button Module] in case of Arduino UNO
CLK: 0
DIO: 1
VCC: 5V
GND: GND
After configuring pins ④ click ADD button on the right below side
Step 7: Check Added Module
⑤ Added Module has appeared on the right panel
Step 8: SkiiiD Code of Segment Module
skiiiD Code is intuitive function-based codes. This is based on skiiiD libraries
clear() - Clear display.
setColon() - Initialize colon on the center of the segment.
If 'mode' is equal to 0, colon is off.
If 'mode' is equal to 1, colon is on.
Default: off or 0.
setBrightness() - Set brightness of the segment.
The range of brightness is 0~7 and the default is 2(BRIGHTNESS_NORMAL).
displayNumber() - number': Display 4-digit positive number or 3-digit negative number.
Step 9: Contact and Feedback
We are working on components and boards libraries. Feel free to use it and feedback us, please. Below is contact methods
email: contact@skiiid.io
twitter: https://twitter.com/skiiiD_official
Youtube: https://www.youtube.com/channel/UCfS2RQL3m3hVoHkFo...
