Introduction: Line Follower Using Arduino | Easy DIY Project
In this tutorial, We will be making a line follower using Arduino
Parts Needed:
Chasis: BO Motors and Wheels: https://amzn.to/2Yjh9I7 L298n motor Driver: https://amzn.to/2IWNMWF IR sensor: https://amzn.to/2FFtFu3 Arduino Uno: https://amzn.to/2FyTrjF Jumpers: Mini BreadBoard:
Step 1: Building the Chassis
Connect the wires to the motors. Then attach the motors to the chassis using Zip ties. Attach the wheels to it.
Now the body is complete.
Step 2: Build the Motor Circuit:
Here we are using an L298N motor driver module which is a dual H-Bridge driver. It can Drive 2 motors bi-directionally or 4 motors uni-directionally.
Connect the motors to the driver.
Connect the power source to the power pins of the driver.
Step 3: Connect the IR Sensors:
Here we are using IR sensors to detect the line.
The IR sensor module has an emitter and a receiver. The IR light is absorbed by black surfaces and reflected by white surfaces. This helps us to follow the black line.
Connect 3 jumpers to the IR sensors.
One for data and the rest two for power.
Step 4: Arduino Connection:
Connect the input pis of the motor driver to the digital pins of the Arduino. Assign them using the code. Do the same for the IR sensors.
Step 5: The Build Is Complete(CODE):
Link to the code: https://github.com/sairushan/Line-follower
Upload the code and enjoy!!
