Low Cost IR Decoder




Introduction: Low Cost IR Decoder

Its just a IR Decoder that can decode the HEXADECIMAL IR signals from the TV remote for further use. like programming any TV remote etc.

Its made with Freeduino (not Arduino). Freeduino is a arduino compatible low cost micro controller. You can program using Arduino IDE (just like coding for Arduino UNO). Its based ob Atmega 328 chip.

Step 1: Items Used:

1. Freeduino Board (Any arduino board can do the work as well)

2. 16/2 LCD (Blue)

3. Jumper Cables

4. Female Header Pins.

5. IR Remote (For Testing)

6. Soldering Machine

7. An old CD/DVD to mount on.

Step 2: Connecting Headers to LCD

Solder your female header in the uper side on the LCD panel so that mounting on a CD will be easier.

Step 3: Connecting the LCD to Arduino

First of all..

Shot the following Terminals:

Vcc with Led +

Gnd with Led -

Vcc with R/W

42 ohm resister between Vee and DB4

(I have used the resistor instead of connecting a potentiometer. That will help in reducing the cable connection and reduce the cost but the LCD will bw glowing at full brightness..!!)

Connecting the Jumper Cables:

Arduino > LCD

5v > Vcc

Gnd > Gnd,R/W

Pin 7 > RS

Pin 6 > EN

Pin 5 > DB4

Pin 4 > DB5

Pin 3 > DB6

Pin 2 > DB7

Step 4: Connecting an IR Receiver

Connect the IR:

Vss to Pin 13

Gnd to Cnd (Arduino)

OUT to Pin 11

Step 5: Coding:



LiquidCrystal lcd(7,6, 5, 4, 3, 2);

int RECV_PIN = 11;

IRrecv irrecv(RECV_PIN);

decode_results results;

void setup()
{ Serial.begin(9600); pinMode(13,OUTPUT); digitalWrite(13,1); lcd.begin(16, 2); irrecv.enableIRIn(); // Start the receiver } // Dumps out the decode_results structure. // Call this after IRrecv::decode() // void * to work around compiler issue //void dump(void *v) { // decode_results *results = (decode_results *)v void dump(decode_results *results) { lcd.setCursor(0, 0); int count = results->rawlen; if (results->decode_type == UNKNOWN) { Serial.print("Unknown encoding: "); lcd.print("Unknown encoding: "); } else if (results->decode_type == NEC) { Serial.print("Decoded NEC: "); lcd.print("Decoded NEC: "); } else if (results->decode_type == SONY) { Serial.print("Decoded SONY: "); lcd.print("Decoded SONY: "); } else if (results->decode_type == RC5) { Serial.print("Decoded RC5: "); lcd.print("Decoded RC5: "); } else if (results->decode_type == RC6) { Serial.print("Decoded RC6: "); lcd.print("Decoded RC6: "); } else if (results->decode_type == PANASONIC) { Serial.print("Decoded PANASONIC - Address: "); Serial.print(results->panasonicAddress,HEX); Serial.print(" Value: "); } else if (results->decode_type == LG) { Serial.print("Decoded LG: "); lcd.print("Decoded LG: "); } else if (results->decode_type == JVC) { Serial.print("Decoded JVC: "); lcd.print("Decoded JVC: "); } lcd.setCursor(0, 1); Serial.print(results->value, HEX); lcd.print(results->value, HEX); Serial.print(" ("); Serial.print(results->bits, DEC); Serial.println(" bits)"); Serial.print("Raw ("); Serial.print(count, DEC); Serial.print("): ");

for (int i = 0; i < count; i++) { if ((i % 2) == 1) { Serial.print(results->rawbuf[i]*USECPERTICK, DEC); } else { Serial.print(-(int)results->rawbuf[i]*USECPERTICK, DEC); } Serial.print(" "); } Serial.println(""); }

void loop() { if (irrecv.decode(&results)) { Serial.println(results.value, HEX); dump(&results); irrecv.resume(); // Receive the next value } }

For this code to run you will be needing a IR Remote Library.

Jusr Goole it or you can download from here too.

Step 6: The Final Step:

Now with a dual sided tape, attach the LCD and the Arduino to the CD.. and Test with some remote and decode the signals..

2 People Made This Project!


  • Pets Challenge

    Pets Challenge
  • Stone Concrete Cement Contest

    Stone Concrete Cement Contest
  • Remote Control Contest

    Remote Control Contest



7 years ago on Introduction

an algorithm will be highly appreciated.


Reply 7 years ago on Introduction

There is a remote control Library available here.Please download.
I have used it in my freeduino project and it works fantastic!!!

This is the IRremote library for the Arduino.

To download from github (http://github.com/shirriff/Arduino-IRremote), click on the "Downloads" link in the upper right, click "Download as zip", and get a zip file. Unzip it and rename the directory shirriff-Arduino-IRremote-nnn to IRremote

To install, move the downloaded IRremote directory to:


where arduino-1.x is your Arduino installation directory

After installation you should have files such as:


For details on the library see the Wiki on github or the blog post http://arcfn.com/2009/08/multi-protocol-infrared-...

Copyright 2009-2012 Ken Shirriff


Reply 7 years ago on Introduction

sorry buddy.. it was just a small part of my home automation project...

No specific algorithms used.!!

Just coded as i wanted...
