MVS RGB LED Sign

Introduction: MVS RGB LED Sign

https://github.com/Fireflaker/MVS-RGB-LED

I designed this PCB for my high school's robotics team. It is an RGB LED light sign that have 3 channels of color for each letter. The letters can flash, fade, stay on, and go in crazy mode. The effects of the animation can be changed with the rotary encoder. The cost is approximately 30usd if you build 10.

Step 1: Gerber Available Here

https://github.com/Fireflaker/MVS-RGB-LED/blob/master/MVS%20LED-20171130.zip

Step 2: It Is Useful As a Growth Lamp

(Poor onion)

The onion has died:(

Step 3: Code, Also Available on My Git

/* fade w/o pwm

Fades an LED that is not connected to a PWM pin This was modified from the Blink without Delay code The circuit: LED attached from pin 13 to ground. Note: on most Arduinos, there is already an LED on the board that's attached to pin 13, so no hardware is needed for this example. *

/ constants won't change. Used here to set pin numbers: const int b1 = 5; // the number of the LED pin const int g1 = 4; const int r1 = 6;

const int b2 = 7; // the number of the LED pin const int g2 = 8; const int r2 = 9;

const int b3 = 10; // the number of the LED pin const int g3 = 11; const int r3 = 12;

#include

// ---------------------------------------------------------------------------- // Button configuration (values for 1ms timer service calls) // #define ENC_BUTTONINTERVAL 10 // check button every x milliseconds, also debouce time #define ENC_DOUBLECLICKTIME 500 // second click within 600ms #define ENC_HOLDTIME 800 // report held button after 0.8s(modified 2017 10 18 allen.)

// ---------------------------------------------------------------------------- // Acceleration configuration (for 1000Hz calls to ::service()) // #define ENC_ACCEL_TOP 3072 // max. acceleration: *12 (val >> 8) #define ENC_ACCEL_INC 25 #define ENC_ACCEL_DEC 2

// ---------------------------------------------------------------------------- #include

ClickEncoder *encoder; int16_t last, value;

void timerIsr() { encoder->service(); }

#include int RECV_PIN = A3; decode_results results; IRrecv irrecv(RECV_PIN);

int TurnOn = 1;

int var = 1; int mode = 1;

int Acceptoff1 = 0; int Acceptoff2 = 0;

int change = 0; int Toggle = 0; int once = 0;

int PanEn1 = 1; int PanWait1 = 5; int PanOn1 = 10; int PanOff1 = 10;

int PanEn2 = 1; int PanWait2 = 5; int PanOn2 = 10; int PanOff2 = 10;

int TestEn = 0; int NowPanic = 0;

unsigned long time1 = millis(); unsigned long time2 = millis();

int rv1 = 1; int rv2 = 0; int rv3 = 1; int gv1 = 1; int gv2 = 1; int gv3 = 1; int bv1 = 0; int bv2 = 1; int bv3 = 0;

int rrv1 = 1;// randNumber = random(0, 1); int rrv2 = 0; int rrv3 = 1; int rgv1 = 1; int rgv2 = 1; int rgv3 = 1; int rbv1 = 0; int rbv2 = 1; int rbv3 = 0;

// Variables will change: int ledState = LOW; // ledState used to set the LED long previousMicros = 0; // will store the last time the blink cycle occured

// the follow variables is a long because the time, measured in microseconds, // will quickly become a bigger number than can be stored in an int. long intervalLength = 500; // f at which to blink (microseconds) long onInterval = 20; // on or HIGH interval length long currentInterval; // length of the current interval int fadeLength = 20; int fadeCount = 0; int intervalDirection = 1;

//for STROBE //unsigned long previousMillis = 0; //unsigned long interval = 1000;

void setup() {

Serial.begin(9600); encoder = new ClickEncoder(2, 3, A0, 4); //(R1,R2,Button,Steps Per Nutch) pinMode(2, INPUT_PULLUP); pinMode(3, INPUT_PULLUP); //Enc pinMode(A0, INPUT_PULLUP); //Button Timer1.initialize(1000); Timer1.attachInterrupt(timerIsr);

// set the digital pin as output: pinMode(g1, OUTPUT); pinMode(g2, OUTPUT); pinMode(g3, OUTPUT); pinMode(r1, OUTPUT); pinMode(r2, OUTPUT); pinMode(r3, OUTPUT); pinMode(b1, OUTPUT); pinMode(b2, OUTPUT); pinMode(b3, OUTPUT);

randomSeed(analogRead(A3));

attachInterrupt(digitalPinToInterrupt(2),BLINK,FALLING);

}

void BLINK(){ TurnOn=1; }

void loop() {

value += encoder->getValue(); //Rotory Encoder values generat

if (value != last) { change = value - last; Serial.print("Encoder change: "); Serial.println(change); last = value; Serial.print("Encoder Value: "); Serial.println(value); } else { change = 0;

}

if (irrecv.decode(&results)) { //IR controller Serial.println(results.value); irrecv.resume(); // Receive the next value if (results.value == 16720605 ) { //A off

irrecv.resume(); // Receive the next value }

else if (results.value == 16712445 ) { //A on

irrecv.resume(); // Receive the next value }

else if (results.value == 16769055 ) { //B off

irrecv.resume(); // Receive the next value }

else if (results.value == 16754775 ) { //B on

irrecv.resume(); // Receive the next value } else if (results.value == 16753245 ) { //PSU off

irrecv.resume(); // Receive the next value } else if (results.value == 16736925 ) { //PSU on

irrecv.resume(); // Receive the next value } else if (results.value == 16738455 ) { //Backlight off

irrecv.resume(); // Receive the next value } else if (results.value == 16750695 ) { //Backlight on

irrecv.resume(); // Receive the next value }

}

ClickEncoder::Button b = encoder->getButton(); //encoder controller if (b != ClickEncoder::Open) { Serial.print("Button: "); #define VERBOSECASE(label) case label: Serial.println(#label); break; switch (b) { //Ó÷¨ //case ClickEncoder::Pressed: //Serial.println("ClickEncoder::Pressed"); // break;

case ClickEncoder::Pressed: //ËƺõûÓã¡ Serial.println("ClickEncoder::Pressed"); break;

case ClickEncoder::Held:

Serial.println("ClickEncoder::Held");

if (change != 0) { // UNSURE &&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&&& change = 0; }

break; // Held Func End

case ClickEncoder::Released: Serial.println("ClickEncoder::Released");

Toggle++; if (Toggle > 1) { Toggle = 0; Serial.println("ON"); TurnOn = 1; } else { Serial.println("OFF"); TurnOn = 0; }

break;

case ClickEncoder::Clicked: var++; once++;

Serial.print(" ClickEncoder::Clicked"); break;

case ClickEncoder::DoubleClicked: mode++; Serial.println("ClickEncoder::DoubleClicked"); //5x Serial.print(" Acceleration is "); Serial.println((encoder->getAccelerationEnabled()) ? "enabled" : "disabled"); break; } }

//========================================================================================================================================= //========================================================================================================================================= switch (mode) { case 1://$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ MODE 1 set color switch (var) {

case 1: //=========================================================================================================================== Degit M

switch (value) { //------------------------------------------------------------------------------- Color1 case 1: rv1 = 0; gv1 = 0; bv1 = 0;

Serial.println("1,1"); break; //------------------------------------------------------------------------------- Color2 case 2: rv1 = 1; gv1 = 0; bv1 = 0; Serial.println("1,2"); break; //------------------------------------------------------------------------------- Color3 case 3: rv1 = 0; gv1 = 1; bv1 = 0;

Serial.println("1,1"); break; //------------------------------------------------------------------------------- Color4 case 4: rv1 = 0; gv1 = 0; bv1 = 1; Serial.println("1,2"); break; //------------------------------------------------------------------------------- Color5 case 5: rv1 = 1; gv1 = 1; bv1 = 0;

Serial.println("1,1"); break; //------------------------------------------------------------------------------- Color6 case 6: rv1 = 0; gv1 = 1; bv1 = 1; Serial.println("1,2"); break; //------------------------------------------------------------------------------- Color7 case 7: rv1 = 1; gv1 = 0; bv1 = 1;

Serial.println("1,1"); break;

//------------------------------------------------------------------------------- Colordefult default: Serial.println("1,def"); } break;

case 2: //============================================================================================================================= Degit V

switch (value) { //------------------------------------------------------------------------------- Color1 case 1: rv2 = 0; gv2 = 0; bv2 = 0;

Serial.println("2,1"); break; //------------------------------------------------------------------------------- Color2 case 2: rv2 = 1; gv2 = 0; bv2 = 0; Serial.println("2,2"); break; //------------------------------------------------------------------------------- Color3 case 3: rv2 = 0; gv2 = 1; bv2 = 0;

Serial.println("2,3"); break; //------------------------------------------------------------------------------- Color4 case 4: rv2 = 0; gv2 = 0; bv2 = 1; Serial.println("2,4"); break; //------------------------------------------------------------------------------- Color5 case 5: rv2 = 1; gv2 = 1; bv2 = 0;

Serial.println("2,5"); break; //------------------------------------------------------------------------------- Color6 case 6: rv2 = 0; gv2 = 1; bv2 = 1; Serial.println("2,6"); break; //------------------------------------------------------------------------------- Color7 case 7: rv2 = 1; gv2 = 0; bv2 = 1;

Serial.println("2,7"); break;

//------------------------------------------------------------------------------- Colordefult default: Serial.println("2,def"); } break;

case 3: //============================================================================================================================= Degit S

switch (value) { //------------------------------------------------------------------------------- Color1 case 1: rv3 = 0; gv3 = 0; bv3 = 0;

Serial.println("2,1"); break; //------------------------------------------------------------------------------- Color2 case 2: rv3 = 1; gv3 = 0; bv3 = 0; Serial.println("2,2"); break; //------------------------------------------------------------------------------- Color3 case 3: rv3 = 0; gv3 = 1; bv3 = 0;

Serial.println("2,3"); break; //------------------------------------------------------------------------------- Color4 case 4: rv3 = 0; gv3 = 0; bv3 = 1; Serial.println("2,4"); break; //------------------------------------------------------------------------------- Color5 case 5: rv3 = 1; gv3 = 1; bv3 = 0;

Serial.println("2,5"); break; //------------------------------------------------------------------------------- Color6 case 6: rv3 = 0; gv3 = 1; bv3 = 1; Serial.println("2,6"); break; //------------------------------------------------------------------------------- Color7 case 7: rv3 = 1; gv3 = 0; bv3 = 1;

Serial.println("2,7"); break;

//------------------------------------------------------------------------------- Colordefult default: Serial.println("2,def"); } break; } if (value > 7) { value = 1; // used to control color } if (value < 1) { value = 7; } digitalWrite(r1, rv1); digitalWrite(g1, gv1); digitalWrite(b1, bv1); digitalWrite(r2, rv2); digitalWrite(g2, gv2); digitalWrite(b2, bv2); digitalWrite(r3, rv3); digitalWrite(g3, gv3); digitalWrite(b3, bv3); break;//$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ END MODE 1 set color

case 2 ://$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ MODE 2 fade {

intervalLength = intervalLength + change * 5;

if (intervalLength < 200) { intervalLength = 200; } unsigned long currentMicros = micros();

currentInterval = currentMicros - previousMicros;

if (currentInterval <= onInterval) { ledState = HIGH; } else { ledState = LOW; }

if (currentInterval > intervalLength) { // save the last time you blinked the LED previousMicros = currentMicros; fadeCount++; if (fadeCount > fadeLength) { fadeCount = 0; onInterval += (intervalDirection * 20); if (onInterval <= 20 || onInterval >= intervalLength) { intervalDirection *= -1; // change the direction of the fade ( positive - brighter / negative - dimmer) } } }

// set the LED with the ledState of the variable: if (rv1 == 0) { digitalWrite(r1, ledState); } if (gv1 == 0) { digitalWrite(g1, ledState); } if (bv1 == 0) { digitalWrite(b1, ledState); } if (rv2 == 0) { digitalWrite(r2, ledState); } if (gv2 == 0) { digitalWrite(g2, ledState); } if (bv2 == 0) { digitalWrite(b2, ledState); } if (rv3 == 0) { digitalWrite(r3, ledState); } if (gv3 == 0) { digitalWrite(g3, ledState); } if (bv3 == 0) { digitalWrite(b3, ledState); }

} break;//$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ END MODE 2 fade

case 3://$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ MODE 3 strobe { intervalLength = intervalLength + change * 10;

if (intervalLength < 50) { intervalLength = 50; } unsigned long currentMicros = micros();

if (currentMicros - previousMicros > intervalLength * 1000) { previousMicros = currentMicros; if (ledState == LOW) ledState = HIGH; else ledState = LOW;

}

// set the LED with the ledState of the variable: if (rv1 == 0) { digitalWrite(r1, ledState); } if (gv1 == 0) { digitalWrite(g1, ledState); } if (bv1 == 0) { digitalWrite(b1, ledState); } if (rv2 == 0) { digitalWrite(r2, ledState); } if (gv2 == 0) { digitalWrite(g2, ledState); } if (bv2 == 0) { digitalWrite(b2, ledState); } if (rv3 == 0) { digitalWrite(r3, ledState); } if (gv3 == 0) { digitalWrite(g3, ledState); } if (bv3 == 0) { digitalWrite(b3, ledState); } }

break;//$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ END MODE 3 strobe

case 4://$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ MODE 4 randomColor { intervalLength = intervalLength + change * 10; delay(intervalLength/10);

digitalWrite(r1, random(4)); digitalWrite(g1, random(4)); digitalWrite(b1, random(4)); digitalWrite(r2, random(4)); digitalWrite(g2, random(4)); digitalWrite(b2, random(4)); digitalWrite(r3, random(4)); digitalWrite(g3, random(4)); digitalWrite(b3, random(4));

}

break;//$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$ END MODE 4 randomColor

} //========================================================================================================================================= "digit"Var END****************

//*********************************** Value Limits if (var > 4) { var = 1; } if (var < 1) { var = 4; }

if (mode > 4) { mode = 1; }

//*********************************** Value Limits END**************

while (TurnOn == 0) { rv1 = 1; gv1 = 1; bv1 = 1; rv2 = 1; gv2 = 1; bv2 = 1; rv3 = 1; gv3 = 1; bv3 = 1; digitalWrite(r1, rv1); digitalWrite(g1, gv1); digitalWrite(b1, bv1); digitalWrite(r2, rv2); digitalWrite(g2, gv2); digitalWrite(b2, bv2); digitalWrite(r3, rv3); digitalWrite(g3, gv3); digitalWrite(b3, bv3);

}

}
