Introduction: Rocket Bookshelf

An easy way to make a cool Rocket bookshelf using 123D Make and TechShop!. This tutorial only covers the creation of the file, not the actual how to cut out the Rocket. If you have access to a shopbot it couldnt be an easier task. Click here to find a ShopBot near you.

Step 1: 123d Make

123d Make is a free product that Autodesk released recently. You can download for free from , use your favorite design software or bank of models to get an .stl file and then open up 123d Make.

1) up to the upper left hand side click   File--> Open example-->Rocket. You can also import your own CAD file or browse the online Gallery that has ton's of models to pick from.

2) To toggle the view of your model use your right mouse button, to Zoom in and out use your scroll wheel.

3) Choose a Construction Option- for this project I choose to Radial slices.

Step 2: Entering New Sheet Materials

1) By the tab that says Manufacturing Settings, click on the pencil and this Screen will show up. To add a new Material click on the plus sign below. I have labeled mine Ply wood because I plan on making several projects with this lot of material. for units I kept it in inches and then entered in the following
Length- 96 in
Width - 48 in
Thickness-.72 in- (even though they say its 3/4 in ply its almost always a bit under)

2) Enter in your desired size, because of the way the model was created I wanted the bottom piece that held everything together to be one solid piece. So I started at 8 feet and tapped my way down to 6.2 before the warning sign on the bottom right of screen turned off saying that the piece would fit on one cut.

This is also a good way to figure how many sheets you have vs need. If size is not as important to you as amount of sheet material than you can use this to design down to the ideal size for the amount of lumber you have.

Step 3: Assembly

123d Make does some really cool stuff after you figure out what you want your finished piece to look like.

1) click on Assembly Steps- and use the scroll bar to figure out how you would assemble this beast.
2) when finished go ahead and choose "Get Plans" here you will sign in with your 123d login and then save out as .eps or svg. Both are great and open in multiple CAM software packages.

Step 4: Finishing Up.

At this Stage you have lots of options, if you are fortunate to live near a TechShop you can reserve some time on their ShopBot and cut this out after some rework on the CAM side in V-carve. If you don't ShopBot does this cool project showing you where the closest available ShopBot is called 100K garages.

My final version was done by some friends with a giant laser cutter, which brings me to good point, ... Make good friends.

Enjoy this Project, I did. )
