  • ErikA45 commented on drmpf's instructable ESP8266 Using GPIO0/GPIO2/GPIO15 Pins6 weeks ago
    ESP8266 Using GPIO0/GPIO2/GPIO15 Pins

    Some progress! Your blink suggestion is excellent, I changed the program a bit to blink both GPIO 2 and 0, and now GPIO0 performs well.And then I discovered a defective component on the output stage of my development board.Conclusion: all works well, I made a mistake by not critically examining the fault symptoms. Thank you for your assistance!

    View Instructable »
  • ErikA45 commented on drmpf's instructable ESP8266 Using GPIO0/GPIO2/GPIO15 Pins6 weeks ago
    ESP8266 Using GPIO0/GPIO2/GPIO15 Pins

    Hi, I checked again, with another brand new ESP8266-12F, this time using following manual programming procedure: at power up tie GPIO0 to GND, then remove GND connection (release floating), and download program. Then restart with GPIO0 connected with 3k3 to +3.3V. The output remains low!So no oscillations, (as I had with a 10k pullup), but no reaction at all.Your suggestions:i. no it is not rebooting continually because the other outputs work as expectedii. this was prevented with the latest new ESP8266-12F chip, so now guaranteed no jeopardising of chip output circuitConclusion:1. 10k pullup causes oscillations when output is supposed to be low2. 3.3k pullup does not change the output state to anything but lowI am lost now.

    Yes, blink test is ok (uses GPIO2); I will do some more investigations and let you know

    View Instructable »
  • ErikA45 commented on drmpf's instructable ESP8266 Using GPIO0/GPIO2/GPIO15 Pins6 weeks ago
    ESP8266 Using GPIO0/GPIO2/GPIO15 Pins

    Just now tested a brand new ESP8266-12F: manual download (wire GPIO0 to 0V, start up and download). Same issue. And when removing any load or pull up from GPIO0 it just stays low!I thought there is an internal pullup to GPIO0?

    View Instructable »
  • ErikA45 commented on drmpf's instructable ESP8266 Using GPIO0/GPIO2/GPIO15 Pins6 weeks ago
    ESP8266 Using GPIO0/GPIO2/GPIO15 Pins

    Hi, thanks for taking the time for such a complete response.By now I suspect an auto-reset circuit that I use in combination with a FTDI serial interface. The DTR isgnal is used to get the ESP8266-12F automatically in proramming mode in the following hardware fashion:1. GPIO0: Schottky diode, cathode to DTR and 330pF to ground2. CH_PD: Schottky diode, cathode to 3.3V and 100nF to DTRReset to 3.3V over 10k.I will try and do programming the manual way on a new ESP8266-12F and report back here (as soon as I have time to do this).

    View Instructable »
  • ErikA45 commented on drmpf's instructable ESP8266 Using GPIO0/GPIO2/GPIO15 Pins7 weeks ago
    ESP8266 Using GPIO0/GPIO2/GPIO15 Pins

    I challenge you to show that GPIO0 can be used as an output and driven to LOW without issues. I tested several new ESP8266-12F and on every single one I get (70kHz) oscillations on its output. Even GPIO15 is working perfectly as an output.

    View Instructable »
  • ErikA45 commented on ErikA45's instructable ESP8266 Firmware Upgrade or Flashing4 months ago
    ESP8266 Firmware Upgrade or Flashing

    Hi, since this tutorial I have moved on to use the Arduino IDE to directly download compiled programs into ESP8266. I use the 12E or 12F versions.For downloading the same pin connections need to be used: GPIO0, and GPIO15 to GND on startup.I also started using DTR from the FTDI USB to serial converter to use the auto-reset feature. This way I can test code, and on the fly download again whatever whenever needed. Search for "ESP8266 auto reset".

    View Instructable »
  • Arduino Sleep and Wakeup Test With DS3231 RTC

    And how do you achieve that in your code?

    View Instructable »
  • Arduino Sleep and Wakeup Test With DS3231 RTC

    How do you get this back to sleep after the wake-up?

    View Instructable »
  • Arduino Sleep and Wakeup Test With DS3231 RTC

    Wrong: first seconds then minutes.RTC.setAlarm(ALM1_MATCH_MINUTES, 0, 18); //set your wake-up time herewhere the 18 and 0 are minutes and seconds respectively

    Wrong: when the Arduino wakes, no need to change anything; next time Arduino will wake again at 12:00 on Sunday.

    Correction to your code:RTC.setAlarm(ALM1_MATCH_MINUTES, 0, 18, 0, 0); //set your wake-up time herewhere first enter seconds, then minutes, then hours, then days. These must be entered if not you get compilation error.

    View Instructable »
  • ErikA45 commented on Nobilis's instructable GSM/GPRS Module DIY Kit9 months ago
    GSM/GPRS Module DIY Kit

    Great work! I had bought two of these modules but nowhere could I find an assembly guide. This blog did it for me: bookmarked!!

    Absolute care must be taken not to exceed 2.85V at the IO pins including RX and TX. If the external MCU operates at 3.3V then a series 220R resistor must be placed in series between RX and MCU_TXD and between TX and MCU_RXD.

    Why would you have to downloas "special" software? When a USB-to-UART converter is used, its drivers are available anyway.Serial interface: numerous other software is just as usefull or better htan Putty: Accessport, ttermpro, ..

    Nowhere does the M590 datasheet state you should place 4.7k between RX and TX. Page 18 shows a 4.7k connected between RX and VCC, and a series diode between RX and MCU_TXD with anode to RX.

    View Instructable »
  • Arduino Sleep and Wakeup Test With DS3231 RTC

    Hi, thank you for that! I will try that code.About not compiling using Atmega168, I found out that the library does not recognise the deep sleep function for Atmega168. This is sleep_mode_extended_standby not recognised by LowPower.h which is solved by https://github.com/rocketscream/Low-Power/issues/4...Atmega168P does use this extended standby, using above solution it does compile correctly for Atmega168P.

    Indeed, I checked the RTClibExtended.h he uses and yes: for the alarms it is seconds first. However, for setting the time it is year first. What a mess!

    View Instructable »
  • Arduino Sleep and Wakeup Test With DS3231 RTC

    1. how can this be set to trigger every hour?2. why does it not compile for Atmega168 but ok for Atmega 328?

    View Instructable »
  • ErikA45's instructable ESP8266 Firmware Upgrade or Flashing's weekly stats: 10 months ago
    • ESP8266 Firmware Upgrade or Flashing
      199 views
      16 favorites
      1 comments
  • Send Sensor Data (DHT11 & BMP180) to ThingSpeak With an Arduino, Using Cable or WiFi (ESP8266) or Use ESP8266 Alone (UPDATED AUGUST 2016)

    well, you have 2 programs, one that runs with Uno and Ethernet shield. And the other with Uno and ESP8266: that is what I am referring to here; the ESP8266 is by default set to communicate at 115200 baud (if you use a fairly recent firmware version).

    I would use here an Arduino Uno with ethernet shield. How can a NodeMCU be used with ethernet?

    ok, but that is in step 3 (with wifi). I was refering to step 2: Arduino with ethernet shield.

    Hi, I notice you set the hardware serial baudrate to 9600baud. But the ESP8266 does by default communicate with 11520baud. Now do you get it to work at 9600baud?

    View Instructable »
  • Send Sensor Data (DHT11 & BMP180) to ThingSpeak With an Arduino, Using Cable or WiFi (ESP8266) or Use ESP8266 Alone (UPDATED AUGUST 2016)

    I found that now in step 3; compiles perfect. Just need to test with Thingspeak now.I read you would now program ESP8266 for all this instead of combining with Arduino. Can you give some url's where I can find more beginners' info on that please?

    View Instructable »
  • Send Sensor Data (DHT11 & BMP180) to ThingSpeak With an Arduino, Using Cable or WiFi (ESP8266) or Use ESP8266 Alone (UPDATED AUGUST 2016)

    For this trial I loaded the wifi code in an Arduino Uno. Now I just have to figure out the sketch for use with analog inputs instead of the sensor modules. Will take some time but I will report back.

    Hi, thank you for your reply. I had wrongly loaded the wifi sketch into the ESP module. I know better now.

    View Instructable »
  • Send Sensor Data (DHT11 & BMP180) to ThingSpeak With an Arduino, Using Cable or WiFi (ESP8266) or Use ESP8266 Alone (UPDATED AUGUST 2016)

    Hi, re the ethernet code compilation error: the cause is the absence of the DHT11 and BMP085 modules. Is it possible to write code for a simple analog input to be read and transmitted? Thanks!

    View Instructable »
  • Send Sensor Data (DHT11 & BMP180) to ThingSpeak With an Arduino, Using Cable or WiFi (ESP8266) or Use ESP8266 Alone (UPDATED AUGUST 2016)

    Can the wireless sketch be used with a Node MCU 1.0 development board? I get a compiler error stating 'A1' was not declared in this scope.

    Loading the ethernet code in an Arduino Uno gives a general compiler error: exit status 1: what do I do wrong?

    View Instructable »
  • Reduce the Temperature of Solenoid Valve for Continuous Driving

    Interesting article. But the resistor calculation can be much simpler:1. measure current with coil in hot state (usually 30 to 50% lower than "cold" current)2. reduce voltage of the power supply until the coil drops out (usually 10% of nominal voltage).3. Multiply this voltage by at least factor 3 (safety margin); I would take this value, or at least half the nominal supply voltage: the "actual voltage"4. Measure the current at that "actual voltage"5. R = (difference between nominal and actual voltage) / actual current6. Power dissipation in resistor: P = R x (square of current); choose a resistor at least twice that value.

    View Instructable »
  • ErikA45 commented on davebodnar's instructable Fidget Spinner to Brushless Motor1 year ago
    Fidget Spinner to Brushless Motor

    Amazing what you do here: fantastic educational tool for tech high school kids; it shows some great principles of brushless motors in a very down-to-kids-world manner. I admire your work! Erik

    View Instructable »
  • How to unlock Digispark ATtiny85 and convert it to a Trinket

    Forgot to add this spaghetti-picture-underside.

    View Instructable »
  • How to unlock Digispark ATtiny85 and convert it to a Trinket

    I made an all-in-one plug-in board with HV programmer for Digispark (left) and regular ICSP programmer for Digispark (right) and ATmega328/168. I have room for a 5V-to-12V booster lower left to be added (item ordered and in transit). The capacitor for the reset is activated by a simple jumper. I added two tiny LED (from analog outputs 18 & 19): one that flashes at low intensity while waiting for character entry, and runs full light when in program mode, and one that runs full light when 12V is active. ..a bit of gadgetry but fun to see.Delay time for 12V kick-in in program adapted to 40usec. Fuses for Digispark adapted equally: see my previous note here.

    View Instructable »
  • ErikA45 commented on diy_bloke's instructable Simple and cheap Fuse Doctor for Attiny1 year ago
    Simple and cheap Fuse Doctor for Attiny

    ok I will as soon as I get to it.

    View Instructable »
  • How to unlock Digispark ATtiny85 and convert it to a Trinket

    I looked at this instruction, can you upload the "HV rescue Simple schematic.png": the resolution is too low for reading. Thks!

    How do you set the extended fuse with this program? Or don't you need a HV programmer for this fuse?

    I looked at this instruction; can you upload the "HV Rescue Simple schematic.png" with higher resolution? The current one is barely readable. Thks!

    View Instructable »
  • ErikA45 followed dmjlambert1 year ago
      • HV Rescue Simple
      • How to unlock Digispark ATtiny85 and convert it to a Trinket
      • Bluetooth Serial Adapter for Pro Mini
  • ErikA45 commented on diy_bloke's instructable Simple and cheap Fuse Doctor for Attiny1 year ago
    Simple and cheap Fuse Doctor for Attiny

    Hi diy_bloke, could you modify your program so that some status is visible on LED's? For example HV on, or programming done, or busy, ..?

    View Instructable »
  • How to unlock Digispark ATtiny85 and convert it to a Trinket

    Works well, except on two Digispark where I had the RSTDSBL set (pin5 as output, no reset). On one Digispark the program hangs 2 minutes at reading lfuse, then finalises ok. The other Digispark causes the program to hang after lfuse reading as E0.Strange thing is it works well on Digisparks where RSTDSBL is not set.What could be the reason?Erik

    Fuse settings are wrong if you want to emulate the Digispark settings without pin5 reset disabled. Lfuse needs to be E1 and Hfuse need to be DD. Efuse should be FE.

    You are right, your instructable says "..return to a trinket.", not "return to Digispark". I should have used the word "different".However, it would still be usefull for anyone wanting to use their Digispark with the USB downloader, that the fuse settings must be adapted in your program.

    I think I may have solved it: I increased "delayMicroseconds(20);" to 60: page 156 of the datasheets specifies between 20 and 60 microseconds delay between Vcc and Reset High..

    View Instructable »
  • ErikA45 commented on diy_bloke's instructable Using an I2C LCD on Attiny851 year ago
     Using an I2C LCD on Attiny85

    You probably have a point with issue in difference in libraries. Address, pins etc are ok but Arduino is not very selective in library usage, In my case I only have one single library for LiquidCrystal as downloaded from you but I would not be surprised there would be an issue. I have several other computers on which to experiment, amongst them a almost virgin one: I will try there too and post the result.

    View Instructable »
  • ErikA45 commented on diy_bloke's instructable Using an I2C LCD on Attiny851 year ago
     Using an I2C LCD on Attiny85

    Followed instructions, but LCD backlight flashes every 2 seconds for about 1/50 of a second, and first row all blocks. When I use LiquidCrystal_attiny (dated 21/03/2015) it works.

    View Instructable »
  • ErikA45 commented on diy_bloke's instructable Simple and cheap Fuse Doctor for Attiny1 year ago
    Simple and cheap Fuse Doctor for Attiny

    I wonder why SCK, MISO and MOSI from the Arduino Uno are not used?Erik$

    Hi, thks for your quick reply! I am confused: Arduino Uno SCK is on pin 13 (PB5), MISO is on pin 12 (PB4) and MOSI is on pin 11 (PB3).In your drawing ATtiny pin 5 (PB0, MOSI) goes to Arduino D9 (pin 9?), ATtiny pin 6 (PB1, MISO) goes to Arduino D10, ATtiny pin 7 (SCK, PB2) goes to Arduino D11 (MOSI), ATtiny pin 2 (PB3) goes to Arduino D12 (MISO).And in the sketch pin 5, 6, 7, 2 and 1 are respectively configured as SDI, SII, SDO, SCI and Reset.So my question:1. MISO, MOSI and SCK are not on the corresponding pins on the Arduino Uno: what do I miss?2. In high voltage programming it seems as if rather SDI, SII, SDO , SCI and Reset are used as variables: what is the difference with MISO and MOSI?Thks,have a great New Year!Erik

    Ah ok!! Now next question.I am in process of making a pcb to do both ISP and HV programming for all ATtiny MCU's, based on initial work by Kai Bader: https://github.com/kaibader/ISP-HVP-Shield/tree/ma...We agreed I could develop his unfinished project. But I am in need of someone to help me program this project.Goal: use HV serial programming on one pcb for ATtiny85/45/25/15/13, ATtiny84/44/24, ATtiny26/261/461/861, ATtiny2313/4313 and ATmega328/168.Question: is HV programming for all these MCU's possible, and what changes to my pcb would be needed to get this programmed (see attachment)Thks!!Erik

    View Instructable »
  • Ultrasonic Range Finder with an ATtiny85 (With Shield)

    Download link for the HC-SR0R Libraryis not working: can you provide a good link plse? Or can we use the regular HC-SR04 library from Arduino?

    View Instructable »
