  • HackerBox 0065: Realtime

    Maybe you skipped Step 6 of the guide, specifically the part about setting up RTClib?

    That pad of C20 and the power connector post next to it are both on the same net of the PCB (GND) so it will work fine the way it is.

    View Instructable »
  • HackerBox 0065: Realtime

    Good job figuring out which line was open! Whenever I have issues like that, my first step is to go back and reflow all the solder joints. More often than I'd expect, that helps to get things moving.

    In addition to setting the RTC to output a 12hr value, you could also try something like:if (n>12) n -= 12;

    View Instructable »
  • HackerBox 0065: Realtime

    Did the previous steps work? If so, it's probably a library.

    Could be an open (cold solder joint) or a short (pants without legs) on the Blaster assembly. Check the 2x8 header as well as the two 1x15 ESP32 headers.

    View Instructable »
  • HackerBox 0065: Realtime

    We had a couple of cards where it helped to lower the access clock passed into the SD.begin function call. You can find "80000000" in the code and play around with knocking one or two zeros off of the end. For one of those cards, it seemed to work fine at the original speed after getting it to work at a lower speed. It is unclear why that happened, but we wanted to share it anyway.

    Yes! A Schematic diagram for the HUB75 Blaster PCB was added at Step 4 of the guide.

    View Instructable »
  • HackerBox 0065: Realtime

    That sounds very cool. Let us know when you get it working. Check out Step 6 (including the test_sd.ino sketch) for info about pin numbers to access the SD card.

    View Instructable »
  • HackerBox 0064: Scope

    There has never been an oscilloscope in HackerBoxes before. You definitely may have done a DSO138 on your own before. It was probably red. Correct? There are a bunch of different version out there.

    View Instructable »
  • HackerBox 0059: Tessellate

    That one is pin 1 (with pin 8 straight across from it). You are correct that isn't totally obvious. Some clues though:The 330 ohm resistor (orange orange brown stripes) is adjacent to, and connected to, those two pins (1 and 8). The 330 ohm resistor is shown in the schematic to connect between pin 1 and pin 8. Also the "unknown inductor" and 1uF cap are connected to the 1,2,3,4 side of the chip. While the other side of the chip only has connection to pin 8 (going over to the VCC header pin).

    View Instructable »
  • HackerBox 0059: Tessellate

    The pin numbers are shown in the image for Step 6. You can also google the LM393 chip to find a datasheet but the info you need is in that image. The pins for whichever MCU you are using just have to match the ones specified in the code.

    View Instructable »
  • HackerBox 0063: Samadhi

    Each HackerBox should have aspects that speak to a range of different ability levels, but the range is not infinite. Our goal is to meet a good number of members where they are and stretch them a bit beyond that - with different stretches each month. We don't want to entirely overwhelm someone who is a (hard working) beginner and we don't want to totally bore a seasoned wizard with spoon-fed everything. Yes, aspects of a box that will entertain someone with a lot of experience might be mostly unattainable for a beginner, but that beginner might enjoy digging deep on some other aspect of that same box, which might bore the more experienced user. Or the beginner might stick it out, ask for help, and see what they can pull off. Every aspect of every box will never speak the same meanin…

    see more »

    Each HackerBox should have aspects that speak to a range of different ability levels, but the range is not infinite. Our goal is to meet a good number of members where they are and stretch them a bit beyond that - with different stretches each month. We don't want to entirely overwhelm someone who is a (hard working) beginner and we don't want to totally bore a seasoned wizard with spoon-fed everything. Yes, aspects of a box that will entertain someone with a lot of experience might be mostly unattainable for a beginner, but that beginner might enjoy digging deep on some other aspect of that same box, which might bore the more experienced user. Or the beginner might stick it out, ask for help, and see what they can pull off. Every aspect of every box will never speak the same meaning for every member. That would be impossible. White belts and black belts can train in the same room, but they are working on different skills. That said, if even the more basic aspects are frustrating you and you do not wish to ask for help or struggle, there are a lot of other fun offerings out there that might fit your level and needs. For example, plenty of DIY electronics products are self-contained and provide more explicit hand-holding. Shop around. Check out all the different options from Adafruit. Every product is not for every consumer for all times, so figure out what works for you where you are right now, get to work, and have fun! You're always welcome to return to HackerBoxes when you're ready. We aren't going anywhere. However, if the most encouraging words you have for a (self described) n00b looking for new ideas are to simply discourage them, then you should definitely go somewhere. :)

    View Instructable »
