Made this for a 1st year engineering project. Took me 2 days. I switched the 555 with a 556 since it's just a dual package 555 timer. Worked out pretty well and It impressed a lot of classmates.
Yes, this picture was before I scraped the toner off of the board using steel wool. Underneath is the copper etch.
Programmer still is not working I tried using a null modem cable and still have no luck please help thanks...
What on/off switch did you use?
What On/off switch did you use? it looks like an on-off-on switch because there are 3 pins coming out of the switch
Can I just you a m/f null connector? Instead of replacing my female sub connector?
This is the one that I used: http://www.amazon.com/SUNKEE-Serial-Connector-RS-232-Adapter/dp/B00AYCTZFU. So are you saying I need to switch it with a Male sub connector and then use a null-modem cable to connect it?
The programmar is not working I followed the schematic exactly but the Program doesn't detect the pic
I finally made it. Still have to test it out though
Can I drill the holes now?Or do I need to do something else?
