Introduction: Dc Motor With H Bridge

By

We first have to install Proteus software for doing this project.

components required are:

BC547 transistors

DC motor (active)

Push buttons

Battery

Step 1: Connect the Circuit

Connect the circuit as per the circuit diagram.

Then run the Proteus software.

WORKING:

If we press the first button then the motor moves in clockwise direction and if we press the button 2 then the motor moves in anti clockwise direction.
