Hey everyone! I'm proud to present my latest project; a full sized, playable, arcade-style K'nex pinball machine! It took around four months to complete and way too long to film. Feel free to ask any questions and I hope you enjoy it as much as I enjoyed building it! Comment and subscribe!
A couple notes:
There are three main "features" of the machine. There are two holes in the floor leading to lifts. The first path shown in the video is one of these holes, and it leads to a chain lift. Out of the lift, the ball drops into a flipper and onto a tubed path which winds its way around the entire machine, then back into the middle of the machine where it gets slightly more complicated.
Another feature is next to the left flipper. The ball drops underneath the machine, and a lift carries it all the way back to the top, where it drops onto the red/green track.
The last feature, which I spent the most time on, is the other hole in the floor. The mill lift carries the ball to the top, and the ball then drops into a holder. A second ball is required to release the first one, and both are carried up the back by two small chain lifts. Once they drop off, they both descend the entire machine, going through a double loop, then another single loop to reach the table. An interesting note about this feature is that one motor powers all three lifts. There's a picture showing the gearbox that transmits power to the two small chain lifts.
