Mandalorian Helmet on 3d Printer

Introduction: Mandalorian Helmet on 3d Printer

About: Hello, bro!)) I'm an engineer, geek, a fan of Tony Stark. And I want to make people's lives better. Therefore, I investigate and invent. This is my YouTube channel https://www.youtube.com/channel/UCr2Rv1l9KrNx…

Hey)))
This is my first instruction. I want to show how I made a Mandalorian helmet. Now everyone can buy a 3D printer. They are not have big price. But not everyone can buy a large printer. With the print area as a human head. I am such a person. I have an old printer prusha i3. The dimensions of his table are 200mm * 200mm. And I can't print a whole helmet.

I will show you my technique.

Supplies

  • 3d printer
  • 3d programm (fusion 360)
  • your hands
  • your brains

Step 1: Split Body

I see no reason to tell how I modeled a helmet. Therefore, skip this moment. Imagine that we already have a helmet ready.

Tool Split Body.

We cut our helmet into the required number of parts.

Step 2: Sketch and Extrude

On the verge of our part, create a new sketch.

In this sketch, draw holes with a diameter of 2 mm.

Close the sketch.
Select the Extrude Tool.

And extrude out our circles.

This operation must be done with all faces of the parts! Save every detail as a stl file!

Step 3: Print

Open your program slicer.

Import stl detail.

Put it on the edge so as not to print support.

Print the part.

Step 4: Hole Cleaning

After printing, check all openings.

Some holes may need to be cleaned.

I use a drill or a mill.

Step 5: Assembly

Take pieces of plastic for the printer. The plastic should be 1.75mm in diameter.

Insert these pieces into the holes of the part.

Lubricate the edge part the with abs juice(abs plastic + .acetone).

Connect the parts together.

Do these operations with all joints of your model.

Step 6: Finish!

Be the First to Share

    Recommendations

    • Lamps and Lighting Contest

      Lamps and Lighting Contest
    • Retro Tech Challenge

      Retro Tech Challenge
    • Back to School: Student Design Challenge

      Back to School: Student Design Challenge

    4 Comments

    0
    PINTARTE12
    PINTARTE12

    Question 7 months ago

    Hello, great project , can you please let me know how many hours do you need to print the helmet? Thanks

    0
    SKUPERDIY
    SKUPERDIY

    Reply 7 months ago

    Hi,bro. I think i printed this helmet about 24 hours.

    0
    sgt.slaughter45
    sgt.slaughter45

    1 year ago

    I love this, but my one question is, what did you do to put a visor in(given you ever did put one in) and what would you recommend?

    0
    SKUPERDIY
    SKUPERDIY

    Reply 1 year ago

    Use a sheet of PET plastic. And glue the tint film for the car on it.
