The Family Bike




Introduction: The Family Bike

This project is not yet finished, but it's done for now. It has been over three years of working on it in many small amounts of time.
 The ingredients are an old Schwinn tandem, a generic BMX, some chain link fence top rail, metal conduit, steel mesh and an unknown amount of assorted bits and pieces of this, that and who knows what from my collection of scrap and junk.
All the tires and the two 26 inch wheels are from Worksman cycles.
The front wheel has a drum brake, the rear wheel has a three speed hub with a coaster brake.  The "sidecar" wheel is a 20 inch super-duper 48 spoke, triple wall rim BMX wheel and has V brakes.
 The power assist is a 24 volt 3/4 hp gearmotor from an old floor scrubber I got to take home from work. 165 rpm was nice for using bicycle chain and sprockets I had laying around.  Motor speed is controlled by 40 amp 24 volt motor speed controller and twist throttle. The cycleanalyst lets me keep an eye on the watts, amps, amp/hours, volts, and speed in real time. And at the end of the trip I can check the watt-hour-miles.
Two 55ah AGM batteries power all that plus nice bright LEDs inside of vintage bike lights.
 Most of the cables and wires are threaded through the frame tubes.

 It has more than met my needs of hauling my family and goods on local trips or my self to work when I am late or lazy. So far the top speed is barely over 20 mph (flying solo), which is fast for something big, heavy and lacking suspension.
  The most I have carried at once is three adults, two kids, a toddler and a dog. With that load the top speed was barely over 12 mph, which seems to be the sweet cruising speed.
 Having five gears to choose from on the powered wheel makes it quite versatile. It is nice to be able to carry people and or whatever at a relaxed cruising speed, or go faster with a lighter load and still keep the watt meter under a thousand. The controller seems to be limited to just under 1100 watts.
The needle on the fun meter however is always buried to the right.

Be the First to Share


    • Origami Speed Challenge

      Origami Speed Challenge
    • Tinkercad to Fusion 360 Challenge

      Tinkercad to Fusion 360 Challenge
    • Stick It Challenge

      Stick It Challenge



    8 years ago on Introduction

    I have not yet had it on a scale, but a realistic estimate is 200-300 lbs, about 100 of that is batteries and motor. The weight is not a problem for me, as I don't really have to pedal much with such a torquey motor & The steering is far so forward there is a mechanical advantage to it, ?(does that make sense?). Its really easy to operate once you get your head around it.
    Longest trip with load, maybe 15 miles, There was still power to use, but we were home.


    8 years ago on Introduction

    Is the first thing I have to say because you manage to be building a quite similar sidecar to the one I have been dreaming, sketching and designing for some time already =)

    Just a shame your project is heavy, by the way which is the longest distance you did with your family or some "heavy" cargo??


    9 years ago on Introduction

    "How heavy is this beast?" was the first thing that popped into my mind when I looked at the pictures...
    Very nice build! A bit rough, but I really like it. Cruising with this bike with the whole "family load" will definitely turn many heads!
