How to Control 8 Leds Using Arduino Uno

Introduction: How to Control 8 Leds Using Arduino Uno

About: I was 13 when I made this account so please don't make fun of my username

hey guys this is my first arduino project  plz  comment how u feel.

Step 1: Things U Need

As this is easy project for beginner's so parts are also simple
Parts:
1- Arduino uno or any other board will work
1-Beardboard
9- jumper wires or wires will also do
8 -leds any color u like i used 3 red, 3 green and 2 blue
8- 1k resistors

Step 2: Placing the Leds and Wiring

In this step u have to place the leds on the bread board i have kept the positive  wire on the right side .
Next wire them as shown in

Step 3: Uploading the Code

int ledPins[] = {2,3,4,5,6,7,8,9};
int delayTime = 100; void setup() { for(int i = 0; i < 8; i++) pinMode(ledPins[i],OUTPUT);

}

void loop() { digitalWrite(ledPins[0], HIGH);

delay(delayTime);

digitalWrite(ledPins[1], HIGH);

delay(delayTime);

digitalWrite(ledPins[2], HIGH);

delay(delayTime);

digitalWrite(ledPins[3], HIGH);

delay(delayTime);

digitalWrite(ledPins[4], HIGH);

delay(delayTime);

digitalWrite(ledPins[5], HIGH);

delay(delayTime);

digitalWrite(ledPins[6], HIGH);

delay(delayTime);

digitalWrite(ledPins[7], HIGH);

delay(delayTime);

//Turns Each LED Off

digitalWrite(ledPins[7], LOW);

delay(delayTime);

digitalWrite(ledPins[6], LOW);

delay(delayTime);

digitalWrite(ledPins[5], LOW);

delay(delayTime);

digitalWrite(ledPins[4], LOW);

delay(delayTime);

digitalWrite(ledPins[3], LOW);

delay(delayTime);

digitalWrite(ledPins[2], LOW);

delay(delayTime);

digitalWrite(ledPins[1], LOW);

delay(delayTime);

digitalWrite(ledPins[0], LOW);

delay(delayTime);

}
